KOIOS 500W Electric Food Processor Chopper User Manual

1. Introducció

Thank you for choosing the KOIOS 500W Electric Food Processor Chopper. This powerful and versatile appliance is designed to simplify your food preparation tasks, offering efficient chopping, mincing, and pureeing capabilities. With its dual bowls and robust motor, it provides a convenient and neat kitchen experience. Please read this manual thoroughly before first use to ensure safe and optimal operation.

2. Instruccions de seguretat importants

Quan utilitzeu aparells elèctrics, sempre s'han de seguir les precaucions bàsiques de seguretat per reduir el risc d'incendi, descàrrega elèctrica i/o lesions a les persones, incloses les següents:

• Llegiu atentament totes les instruccions abans d'utilitzar l'aparell.
• No submergiu la unitat del motor en aigua ni altres líquids. Netegeu-la només amb aigua.amp tela.
• Desendolleu sempre l'aparell de la presa de corrent abans de muntar-lo, desmuntar-lo o netejar-lo.
• Mantingueu les mans i els estris allunyats de les fulles en moviment durant el funcionament per evitar lesions.
• The blades are extremely sharp. Handle with extreme care, especially when removing or attaching them, and during cleaning. Always use the blade guards when storing.
• Ensure the bowl and lid are properly assembled and secured before operating the motor.
• Do not process extremely hard foods such as frozen fruits, ice, or un-shelled nuts, as this may damage the blades or motor.
• Do not operate the appliance continuously for more than 30 seconds to prevent motor overheating. Allow a short break between cycles.
• This appliance is equipped with built-in overheating protection, which will automatically shut off power in case of excessive heat. If this occurs, unplug the unit and allow it to cool down before resuming use.
• Always place the appliance on a stable, flat, and dry surface. The non-slip rubber ring helps keep the food chopper in place during operation.
• És necessària una supervisió estreta quan qualsevol aparell és utilitzat per o a prop dels nens.
• No utilitzeu accessoris no recomanats o venuts pel fabricant.
• No utilitzeu l'aparell a l'exterior.
• No deixeu que el cable pengi de la vora d'una taula o taulell, ni toqui superfícies calentes.
• No feu servir cap aparell amb un cable o un endoll danyats, o després que l'aparell funcioni malament o s'hagi caigut o s'hagi danyat de cap manera.

3. Components del producte

The KOIOS 500W Electric Food Processor Chopper comes with the following parts:

•

  Figure 3.1: All included components of the KOIOS Food Processor.

  This image displays all the parts included in the packaging. From left to right, top to bottom: the 500W Power Pod (motor unit), a Glass Bowl, two 4 S-shaped Bi-Level Blades, a Stainless Steel Bowl, a Translucent Lid, two Non-slip Base Rings, the User Manual, and eight Blade Protectors.

• 500W Motor Unit: The main power unit that drives the blades.
• 8-Cup Glass Bowl: A transparent bowl for processing food, allowing visual monitoring.
• 8-Cup Stainless Steel Bowl: An alternative durable bowl for processing food.
• Bi-Level S-shaped Blades (2 sets): Sharp stainless steel blades for efficient chopping and mincing. Each set includes two blades.
• Translucent Lid: Covers the bowl during operation.
• Non-slip Base Rings (2): Rubber rings that fit under the bowls to provide stability.
• Blade Protectors: Covers for the sharp blades for safe storage.
• Manual d'usuari: This instruction booklet.

4. Muntatge i muntatge

Follow these steps to assemble your food processor before use:

1. Components nets: Before first use, wash the glass bowl, stainless steel bowl, blades, and lid in warm, soapy water. Rinse thoroughly and dry. The bowls, blades, and lid are dishwasher safe (except the motor unit).
2. Place Non-slip Ring: Place one of the non-slip rubber rings onto the bottom of your chosen bowl (glass or stainless steel). Ensure it is securely fitted.
3. Posició del bol: Place the assembled bowl on a stable, flat, and dry surface.
4. Inserir fulles: Carefully remove the blade protectors from the S-shaped blades. Hold the blade assembly by the plastic shaft and carefully place it onto the center pin inside the bowl. Ensure it sits firmly.
5. Afegir ingredients: Add your ingredients into the bowl. Do not overfill the bowl; ensure ingredients are below the maximum fill line.
6. Col·locar la tapa: Place the translucent lid onto the bowl, aligning the opening in the lid with the top of the blade shaft.
7. Attach Motor Unit: Place the motor unit on top of the lid, aligning the motor's drive shaft with the top of the blade shaft. The motor unit will sit loosely on top and does not "lock" into place, but it should be stable.
8. Connectar l'alimentació: Plug the power cord into a standard electrical outlet. Your food processor is now ready for operation.

Figure 4.1: Fully assembled KOIOS Food Processor ready for use.

This image shows the main unit assembled with the glass bowl, lid, and motor unit. The blades are inside the bowl, and the non-slip ring is visible at the base of the bowl. A separate stainless steel bowl is shown in the background, indicating the dual bowl feature.

5. Instruccions de funcionament

The KOIOS food processor features two speed settings for various processing needs:

•

  Figure 5.1: Two Speeds Pulse Control for different food types.

  This image visually explains the two speed settings. Speed I (smooth cutting) is recommended for soft foods such as onions, avocados, and chilies. Speed II (turbo chopping) is recommended for harder foods like meat, carrots, and nuts. The motor unit has two distinct buttons for these speeds.
• Speed I (Smooth Cutting): Press and hold the 'I' button on the top of the motor unit for a slower, smoother cutting action. This speed is ideal for soft ingredients like onions, avocados, and chilies, or for achieving a coarser chop.
• Speed II (Turbo Chopping): Press and hold the 'II' button for a faster, more powerful chopping action. This speed is suitable for harder ingredients such as meat, carrots, and nuts, or for achieving a finer chop or puree.

Consells generals d'operació:

• Pulse Action: For best results and to prevent over-processing, use short pulses by pressing and releasing the desired speed button. This gives you greater control over the texture.
• Temps de processament: Do not operate the appliance for more than 30 seconds continuously. If more processing is needed, allow the motor to rest for a few seconds before continuing.
• Mida de l'ingredient: For optimal performance, cut larger ingredients into smaller, uniform pieces (e.g., less than an inch square for vegetables) before placing them in the bowl.
• Dual Bowls: The inclusion of both a glass and a stainless steel bowl allows you to process different food types without mixing flavors, or to prepare multiple ingredients sequentially.
•

  Figure 5.2: Utilizing two bowls for different cooking needs.

  This image highlights the benefit of having two separate bowls. One scenario shows preparing baby food (puree) in one bowl, while another shows chopping meat in the stainless steel bowl, emphasizing the ability to avoid flavor cross-contamination.
• Afilat de la fulla: The stainless steel blades are very sharp, ensuring effortless cutting. Always handle them with care.
•

  Figure 5.3: Detail of the Effortless Cutting Blades.

  Aquesta imatge ofereix un detall view of the food-grade 304 SUS blades, highlighting their sharp design which contributes to efficient and effortless cutting of various ingredients.

6. Cura i Manteniment

Proper cleaning and maintenance will ensure the longevity and optimal performance of your KOIOS food processor.

Neteja:

1. Desconnectar: Always unplug the motor unit from the power outlet before cleaning.
2. Desmuntar: Carefully remove the motor unit, lid, blades, and bowl.
3. Unitat motora neta: Netegeu la unitat del motor amb l'anunciamp drap. NO submergiu la unitat del motor en aigua ni en cap altre líquid.
4. Rentar les peces desmuntables: The bowls, blades, and lid are detachable and can be cleaned in a dishwasher. Alternatively, wash them by hand in warm, soapy water. Rinse thoroughly and dry immediately.
5. Cura de la fulla: Exercise extreme caution when handling the blades due to their sharpness. Use a brush to clean them if necessary. Always place blade protectors back on the blades before storing.
6.

   Figure 6.1: Dishwasher Safe Components.

   This image demonstrates that the bowls, lid, and blades (excluding the motor unit) are safe for cleaning in a dishwasher, simplifying the cleanup process.

Emmagatzematge:

• Assegureu-vos que totes les peces estiguin completament seques abans d'emmagatzemar-les.
• Store the food processor in a cool, dry place, away from direct sunlight and out of reach of children.
• Always store blades with their protective covers on.

7. Solució De Problemes

If you encounter any issues with your KOIOS food processor, please refer to the following table for common problems and solutions:

8. Especificacions del producte

9. Garantia i atenció al client

KOIOS is committed to providing high-quality products and excellent customer service.

Aquest producte ve amb Lifetime technical support and 24-hour quality service. If you have any questions, concerns, or require assistance with your KOIOS 500W Electric Food Processor Chopper, please do not hesitate to contact our customer support team.
