EDUP Mini USB WiFi 6 Adapter Bluetooth 5.3 Dongle

1. Introducció

Thank you for choosing the EDUP Mini USB WiFi 6 Adapter Bluetooth 5.3 Dongle. This device provides ultra-fast dual-band Wi-Fi 6 (802.11ax) connectivity and Bluetooth 5.3 capabilities for your Windows 11/10 desktop or laptop PC. It is designed to offer stable, high-speed data transfer and low-energy connectivity, enhancing your network and peripheral experience.

This manual will guide you through the installation, operation, and maintenance of your new adapter, ensuring optimal performance.

2. Informació de seguretat

• Keep the device away from water, fire, excessive humidity, or hot environments.
• No intenteu desmuntar, reparar o modificar el dispositiu.
• Feu servir el dispositiu dins dels rangs de temperatura i humitat de funcionament especificats.
• Ensure proper ventilation around the device when in use.

3. Contingut del paquet

Si us plau, reviseu atentament el contingut del paquet. Si falta algun article o hi ha algun dany, poseu-vos en contacte amb el vostre distribuïdor.

• 1 x USB Bluetooth WiFi Adapter
• 1 x manual d'usuari

4. Producte acabatview

The EDUP Mini USB WiFi 6 Adapter is a compact and portable device designed for seamless integration with your computer. Its small form factor allows it to remain discreetly plugged into a USB port.

Figure 4.1: EDUP Mini USB WiFi 6 Adapter Bluetooth 5.3 Dongle

This image shows the compact black USB adapter with the EDUP logo and a blue indicator light. It features a standard USB-A connector.

Figura 4.2: Característiques clauview

This graphic highlights the adapter's main features: AX900, 900Mbps, USB 2.0 interface, Bluetooth 5.3, Wi-Fi 6, 2.4G/5G Dual Band, 802.11AX standard, Windows 10/11 compatibility, and easy driver installation.

Figure 4.3: Convenient and Portable Design

This image illustrates the adapter's small dimensions (20mm width, 44mm length) when plugged into a laptop, emphasizing its portability.

5. Guia de configuració

5.1 Requisits del sistema

• Operating System: Windows 11 or Windows 10 (64-bit recommended).
• Available USB 2.0 or 3.0 port.

Figure 5.1: Supported Operating Systems

This image displays the logos for Windows 10 and Windows 11, indicating compatibility with these operating systems.

5.2 Instal·lació del controlador

The EDUP Mini USB WiFi 6 Adapter requires driver installation for full functionality. Drivers are provided on a U disk included with your purchase, or can be downloaded from the official EDUP weblloc.

1. Inseriu l'adaptador: Plug the EDUP Mini USB WiFi 6 Adapter into an available USB port on your desktop or laptop PC.
2. Instal·leu els controladors:
   • Option A (U Disk): Insert the provided U disk into a USB port. Navigate to the U disk drive in File Explorer and run the driver setup executable (e.g., "autorun.exe" or similar).
   • Option B (Online Download - Recommended for latest drivers):
     1. Obre el teu web browser and go to the EDUP weblloc: szedup.com/usb-adapters/EPAX910.html.
     2. Navigate to the "Download Center" or "Support" section.
     3. Locate and download the latest drivers for model EP-AX910 (or EP-AX900/910 Driver) compatible with Windows 10/11. The file will likely be a compressed ZIP file.
     4. Extraieu el ZIP descarregat file a una carpeta de l’ordinador.
     5. Run the setup executable (e.g., "setup.exe" or "autorun.exe") from the extracted folder and follow the on-screen instructions.
3. Instal·lació completa: Follow the prompts in the installation wizard. You may be asked to restart your computer after installation is complete.

Figure 5.2: Adapter Connected to a Mini PC

This image shows the compact EDUP USB WiFi 6 Adapter plugged into a USB port on a mini PC, illustrating its discreet integration.

6. Instruccions de funcionament

6.1 Connexió a Wi-Fi

Once the drivers are successfully installed, your computer will recognize the Wi-Fi capabilities of the adapter.

1. Click on the Wi-Fi icon in your system tray (usually in the bottom-right corner of your screen).
2. Seleccioneu la xarxa Wi-Fi desitjada de la llista de xarxes disponibles.
3. Introduïu la clau de seguretat de xarxa (contrasenya) si se us demana.
4. Click "Connect". Your computer should now be connected to the internet via the EDUP adapter.

Figure 6.1: Wi-Fi 6 Speed Capabilities

This image illustrates the potential Wi-Fi 6 speeds: up to 600 Mbps on the 5GHz band and up to 286 Mbps on the 2.4GHz band, offering faster performance compared to previous Wi-Fi generations.

6.2 Connexió de dispositius Bluetooth

The adapter also enables Bluetooth 5.3 connectivity for various peripherals.

1. Aneu a Configuració de Windows > Dispositius > Bluetooth i altres dispositius.
2. Assegureu-vos que el Bluetooth estigui activat.
3. Feu clic a "Afegeix Bluetooth o un altre dispositiu" i seleccioneu "Bluetooth".
4. Poseu el vostre dispositiu Bluetooth (per exemple, auriculars, teclat, ratolí) en mode d'emparellament.
5. Seleccioneu el dispositiu de la llista i seguiu les instruccions que apareixen a la pantalla per completar el procés d'emparellament.

Figura 6.2: Connectivitat Bluetooth 5.3

This diagram illustrates how the EDUP adapter facilitates connections to various Bluetooth devices, including keyboards, mice, printers, audio devices, and earphones, from a desktop, PC, or laptop.

Figure 6.3: Advanced Features

This image highlights key features such as WPA3 Network Protection for enhanced security, Bluetooth 5.3 for increased range and throughput, IEEE 802.11ax for higher data rates and lower latency, and the plug-and-play nature with certified drivers.

7. Manteniment

• Keep the adapter clean by wiping it with a soft, dry cloth.
• Avoid exposing the adapter to extreme temperatures or direct sunlight.
• When transporting a laptop, it is advisable to remove the dongle to prevent accidental damage.
• Periodically check the EDUP weblloc web per a controladors actualitzats per garantir un rendiment i una compatibilitat òptims.

8. Solució De Problemes

8.1 Adapter Not Detected or Not Working

• Comprova el port USB: Prova de connectar l'adaptador a un port USB diferent de l'ordinador.
• Instal·lació del controlador: Ensure that the drivers are correctly installed. If you used the U disk, consider downloading the latest drivers from the EDUP weblloc (szedup.com/usb-adapters/EPAX910.html) as they may be more up-to-date.
• Reinicieu l'ordinador: A system restart can often resolve detection issues after driver installation.
• Gestor de dispositius: Open Device Manager (search for it in Windows) and check if the adapter is listed under "Network adapters" and "Bluetooth". Look for any yellow exclamation marks, which indicate a driver issue. Right-click and select "Update driver" or "Uninstall device" and then reinstall the driver.

8.2 Problemes de connexió Wi-Fi

• Intensitat del senyal: Ensure you are within range of your Wi-Fi router.
• Contrasenya incorrecta: Comproveu dues vegades la contrasenya del Wi-Fi.
• Reinici de l'encaminador: Prova de reiniciar el teu encaminador Wi-Fi.
• Banda de xarxa: Confirm your router is broadcasting on 2.4GHz or 5GHz. The adapter supports both.

8.3 Bluetooth Pairing Problems

• Mode d'emparellament de dispositius: Ensure your Bluetooth device is in proper pairing mode. Refer to your device's manual.
• Distància: Keep the Bluetooth device close to the adapter during pairing.
• Interferència: Allunyeu-vos d'altres dispositius sense fil que puguin causar interferències.
• Elimina els emparellaments existents: If the device was previously paired with another computer or phone, unpair it first.

9. Especificacions

10. Garantia i Suport

EDUP provides a 3-year manufacturer replacement warranty for this product. Additionally, a 90-day no-questions-asked return policy is offered.

For any assistance, technical support, or warranty claims, please feel free to contact us via Amazon message. Our support team is ready to help you with any inquiries or issues you may encounter.
