Introducció
This user manual provides comprehensive instructions for the RCA 43-Inch FHD Smart Android TV, Model TC-LE43K-AN2401. Please read this manual thoroughly before operating your television to ensure proper use and to maximize your viewexperiència. Conserveu aquest manual com a referència futura.
Què hi ha a la caixa
En desempaquetar, comproveu que hi hagi tots els elements següents:
- RCA 43-Inch FHD Smart Android TV
- Cable d'alimentació
- Control remot
- Suport (2 peces)
- Manual d'usuari (aquest document)
Figura 1: Frontal view of the RCA 43-Inch FHD Smart Android TV. The TV features a frameless LED display and is shown with the RCA logo prominently displayed on the screen, surrounded by sports equipment graphics.
Configuració
Col·locació del suport
- Col·loqueu amb cura la pantalla del televisor amb la pantalla cap avall sobre una superfície suau i neta per evitar ratllades.
- Align the stand pieces with the mounting holes on the bottom of the TV.
- Fixeu les peces del suport amb els cargols proporcionats. Assegureu-vos que estiguin ben ajustades.
Potència de connexió
Connect the supplied power cable to the TV's power input and then to a wall outlet. The TV is designed for energy efficiency, consuming less than 75W during use and under 0.5W in standby mode.
Configuració inicial i connexió de xarxa
Upon first power-on, the TV will guide you through the initial setup process. This includes language selection, time zone, and network connection. The TV supports both Wi-Fi and Ethernet connectivity for seamless streaming and app downloads.
Figura 2: posterior view of the RCA 43-Inch FHD Smart Android TV, illustrating the back panel where the stand attaches and various ports are located.
Funcionament del televisor
Interfície d'Android TV
Your RCA Smart Android TV provides access to a wide range of entertainment options. The intuitive interface allows for easy navigation through built-in apps like Netflix, YouTube, and Prime Video. Thousands of additional apps are available on the Google Play Store.
Funcions de control remot
The included remote control allows you to power on/off, adjust volume, change channels, access smart features, and navigate menus. Refer to the remote control diagram in the quick start guide for specific button functions.
Integració de l'Assistent de Google
With Google Assistant built-in, you can use voice commands to search for content, control smart home devices, and get information. Simply press the Google Assistant button on your remote and speak your command.
Característiques clau
- Pantalla Full HD: Enjoy breathtaking visuals with 1920 x 1080 resolution. The 43-inch screen and 60 Hz refresh rate deliver smooth motion and vibrant colors.
- Suport HDR10: Experience enhanced contrast and color accuracy with HDR10 technology.
- Frameless LED Design: A modern, seamless look that enhances any room.
- Ample Viewangle: El 178° d'amplada viewing angle ensures perfect picture quality from various positions.
- Reproducció de mitjans USB: View photos, videos, and listen to music directly from a USB drive. Supported formats include JPEG and MP3.
Figure 3: Detail showing the ultra-slim bezels of the RCA TV, designed for a modern and immersive viewexperiència.
Figure 4: Visual representation emphasizing the Full HD (1920x1080) resolution for vibrant colors and crisp details.
Opcions de connectivitat
The RCA 43-Inch FHD Smart Android TV offers extensive connectivity to integrate with your existing devices:
- Ports HDMI: 3 HDMI ports for connecting gaming consoles, Blu-ray players, sound systems, and other HDMI-enabled devices.
- Entrades USB: 2 USB inputs for media playback from external storage devices.
- Audio/Video Connections: Multiple audio/video connections including RCA and Optical.
- Connectivitat sense fils: Wi-Fi i Bluetooth integrats per a l'accés a la xarxa i la connexió d'accessoris sense fil.
Figura 5: Detallada view of the TV's connectivity ports, including HDMI, USB, and various audio/video inputs, located on the side and rear for easy access.
Figure 6: Illustration of the TV's built-in Wi-Fi and Ethernet capabilities, enabling seamless internet connection for streaming and smart features.
Qualitat d'imatge i so
The RCA 43-Inch FHD Smart Android TV is designed to deliver a superior audiovisual experience:
- Contrast dinàmic: A dynamic contrast ratio of 1200:1 enhances depth and detail in every scene.
- Reducció de soroll 3D: Advanced 3D Noise Reduction technology ensures a clear and crisp picture.
- Rich Color Display: Enjoy a wide spectrum of colors for a more lifelike viewexperiència.
- Advanced Audio Performance: Paired with high-quality sound, this TV provides an immersive experience for all your media.
Figure 7: Visual highlighting the 1200:1 dynamic contrast ratio, contributing to vibrant colors and crisp details on the screen.
Eficiència energètica
This television is designed with energy conservation in mind:
- Consum d'energia: Less than 75W during operation.
- Mode d'espera: Consumes under 0.5W in standby mode.
- Consum anual d'energia: Approximately 1095 Kilowatt Hours Per Year, based on 4 hours of daily operation. Actual consumption may vary.
Figure 8: The Energy Guide label for the RCA 43-Inch FHD Smart Android TV, indicating its estimated annual energy cost and consumption.
Manteniment
Neteja de la pantalla
Per netejar la pantalla, netegeu-la suaument amb un drap suau i sense borrissol. Per a marques difícils, netegeu-la lleugerament.ampNetegeu el drap amb aigua o una solució netejadora de pantalles. Eviteu utilitzar productes químics agressius o materials abrasius.
Atenció General
Keep the TV in a well-ventilated area. Avoid exposing it to direct sunlight, extreme temperatures, or high humidity. Do not block ventilation openings.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| Sense poder | Cable d'alimentació no connectat; presa de corrent no funciona. | Ensure power cable is securely plugged in. Test the outlet with another device. |
| Sense imatge/so | Incorrect input source; loose HDMI/AV cables. | Verify correct input source. Check all cable connections. |
| Problemes de connexió Wi-Fi | Contrasenya incorrecta; problemes amb el router; televisor massa lluny del router. | Re-enter Wi-Fi password. Restart router. Move TV closer or use Ethernet. |
| Rendiment lent | Too many apps running; low internet speed. | Close unused apps. Check internet speed. Restart TV. |
If issues persist, please contact RCA customer service.
Especificacions
- Marca: RCA
- Número de model: TC-LE43K-AN2401
- Mida de la pantalla: 43 polzades (110 cm diagonal visible)
- Tecnologia de visualització: LED FHD
- Resolució: 1080p (1920 x 1080)
- Freqüència d'actualització: 60 Hz
- Relació d'aspecte: 16:9
- Contrast dinàmic: 1200:1
- Brillantor: 220 cd/m²
- Viewangle: 178°
- Connectivitat: 3 HDMI, 2 USB, RCA, Optical, Wi-Fi, Bluetooth
- Sistema operatiu: Android TV
- Característiques especials: HDR10, Google Assistant Built-in, Compatible with Alexa
- Consum d'energia: < 75W (Operating), < 0.5W (Standby)
- Pes de l'article: 17.94 lliures
- Dimensions del producte: 2.76 x 37.6 x 21.97 inches (TV only); 8.46"D x 37.6"W x 24.06"H (with stand)
Garantia i Suport
Your RCA 43-Inch FHD Smart Android TV comes with a 2 anys de garantia. This warranty covers manufacturing defects and ensures the product is built to last with high-quality materials.
For any inquiries, technical assistance, or warranty claims, please contact RCA's dedicated customer service. Support is available Monday to Friday from 9 AM to 5 PM PST.
Per a més informació, visiteu el Official RCA Store on Amazon.
