1. Informació important de seguretat
Please read all safety instructions carefully before operating the Hetoy Electric Motorcycle. Failure to follow these instructions may result in injury or damage to the product.
- Always ensure the battery is fully charged at least once per month, even during periods of non-use, to maintain battery health.
- Always wear appropriate safety gear, including a helmet, knee pads, and elbow pads, when riding.
- Supervise young riders at all times.
- No supereu la capacitat màxima de pes de 132 lliures.
- Avoid riding in unsafe conditions, such as heavy rain, snow, or on excessively steep inclines.
- Regularly inspect the motorcycle for any loose parts, damage, or wear before each use.
2. Producte acabatview
The Hetoy Electric Motorcycle for Kids is a high-performance dirt bike designed for young riders, offering a thrilling yet safe riding experience. It features a robust design, dual-speed modes, and a long-lasting battery.
Hetoy Electric Motorcycle for Kids in green, vieweditat des de la part frontal esquerra, mostraasing el seu disseny i les seves característiques.
Característiques principals:
- Powerful 24V 250W Brushless Motor: Ensures smooth and dependable performance.
- Modes de velocitat dual: Offers a safe yet exhilarating experience with speeds up to 7.5 MPH (Low) and 13.7 MPH (High).
- Long-lasting 24V 9AH Battery: Provides up to 60 minutes of continuous ride time and a range of up to 10 miles on a full charge.
- Construcció duradora: Crafted from aluminum alloy with a sleek paint finish, accommodating riders up to 132 lbs.
- Característiques de seguretat millorades: Includes a robust rear drum brake and 12-inch inflatable rubber-composite tires for superior traction and shock absorption.
- Llums LED integrades: For improved visibility.
- Comfortable Leather Seat: Provides a comfortable riding experience.
A young boy riding the Hetoy Electric Motorcycle, with icons illustrating key features like 300W motor power, 24V 9AH battery, L/H speed mode, 14 MPH top speed, 10 miles max range, and 140 lbs max load. A reminder to wear a helmet and protective gear is visible.
Two children, one on a green Hetoy Electric Motorcycle and another on a pink one, with a table detailing speed modes: High-Speed (8-14 years old, 40-60 mins battery, 13.7 MPH max speed) and Low-Speed (3-8 years old, 60-80 mins battery, 7.5 MPH max speed).
3. Muntatge i muntatge
The Hetoy Electric Motorcycle requires minimal assembly. Follow these general steps to prepare your motorcycle for its first ride:
- Desempaquetar components: Carefully remove all parts from the packaging. Verify all components listed in the packing list are present.
- Fixeu els manillars: Securely attach the handlebars to the main frame using the provided hardware. Ensure they are aligned and tightened properly.
- Instal·leu la roda davantera: Attach the front wheel, ensuring all nuts and bolts are securely fastened.
- Càrrega inicial de la bateria: Before first use, fully charge the battery for 8-10 hours. Refer to the 'Battery Management' section for charging instructions.
- Comprovació de seguretat: Before the first ride, perform a thorough safety check. Ensure all connections are secure, tires are properly inflated, and brakes are functioning correctly.
Diagram illustrating recommended rider height (2'9"-5'4") and key dimensions of the Hetoy Electric Motorcycle: Total Length (45.1"), Handlebar Height (29.7"), Wheelbase (12.5"), and Seat Height (15.9").
4. Instruccions de funcionament
4.1 Engegada/apagada
To power on the motorcycle, insert the key into the ignition and turn it to the 'ON' position. To power off, turn the key to the 'OFF' position and remove it.
4.2 modes de velocitat
The motorcycle features dual-speed modes to accommodate different rider skill levels and preferences:
- Mode de baixa velocitat: Ideal for younger riders (3-8 years old) or for learning. Provides a maximum speed of 7.5 MPH.
- Mode d'alta velocitat: Suitable for experienced riders (8-14 years old). Provides a maximum speed of 13.7 MPH.
Refer to the product's controls for switching between speed modes.
4.3 Gestió de la bateria
The motorcycle is equipped with an LCD battery indicator on the throttle to help you monitor the battery status. This display simplifies power management, showing remaining charge and estimated mileage.
Close-up of the Hetoy Electric Motorcycle's handlebars, showing the LCD battery indicator with green bars representing remaining charge and estimated mileage ranges (8-10 miles, 5-7.5 miles, 3-5 miles, <2.5 miles).
Image showing the LCD power display on the handlebars of the Hetoy Electric Motorcycle, with green bars indicating battery status and corresponding mileage ranges.
4.4 Riding on Different Terrains
The 12-inch inflatable rubber-composite tires are designed to provide superior traction and shock absorption, allowing the motorcycle to adapt to various challenging road conditions.
Close-up of the inflatable rubber-composite tire of the Hetoy Electric Motorcycle, with small images showing various terrains it can adapt to: glass road, sand road, mud road, and brick road.
Image highlighting the 13-inch large size wear-resistant rubber wheels of the Hetoy Electric Motorcycle, with background images of grass, cobblestone, sand, and asphalt roads to show terrain adaptability.
4.5 Sistema de frenada
The motorcycle is equipped with a child-friendly robust rear drum brake for easy and secure stopping. Always apply the brake smoothly and gradually.
Detailed close-up of the rear wheel and drum brake mechanism of the Hetoy Electric Motorcycle, emphasizing the safety feature.
Diagram illustrating the rear drum brake system of the Hetoy Electric Motorcycle, highlighting its function in improving driving safety and controllability.
4.6 Headlight Operation
The integrated IPX5 LED headlight provides illumination for riding in low-light conditions. Activate the headlight using the designated switch on the handlebars.
Illustration of the IPX5 LED headlight on the Hetoy Electric Motorcycle, illuminating a dark, rugged landscape.
Close-up of the flexible handlebar of the Hetoy Electric Motorcycle, showing the brake levers and throttle.
Close-up image of the genuine leather cushion seat of the Hetoy Electric Motorcycle, showing its textured surface.
5. Manteniment
Regular maintenance ensures the longevity and safe operation of your Hetoy Electric Motorcycle.
- Cura de la bateria: Charge the battery fully after each use. If storing for extended periods, charge at least once a month. Do not allow the battery to fully discharge for prolonged times.
- Neteja: Wipe down the motorcycle with a damp cloth after use. Avoid using harsh chemicals or abrasive cleaners. Do not spray water directly onto electrical components.
- Pressió dels pneumàtics: Check tire pressure regularly and inflate to the recommended PSI (refer to tire sidewall for details).
- Inspecció de frens: Periodically check the rear drum brake for proper function and wear. Adjust or replace as needed.
- Inspecció general: Before each ride, check for loose bolts, damaged parts, or unusual noises. Tighten any loose fasteners.
6. Solució De Problemes
This section addresses common issues you might encounter with your Hetoy Electric Motorcycle.
| Problema | Causa possible | Solució |
|---|---|---|
| Motorcycle does not turn on. | Battery is low or dead; Key not fully inserted/turned; Loose electrical connection. | Charge the battery; Ensure key is fully inserted and turned to 'ON'; Check all electrical connections. |
| Motorcycle runs slowly or lacks power. | Low battery charge; Overweight rider; Riding on difficult terrain; Tire pressure too low. | Fully charge the battery; Ensure rider is within weight limit; Ride on appropriate surfaces; Inflate tires to correct pressure. |
| Els frens no són efectius. | Brake cable needs adjustment; Brake pads are worn. | Adjust the brake cable tension; Inspect and replace brake pads if worn. |
| Sorolls inusuals durant el funcionament. | Loose components; Debris in moving parts; Motor issue. | Inspect for and tighten any loose parts; Clear any debris; If noise persists, contact customer support. |
7. Especificacions
Detailed technical specifications for the Hetoy Electric Motorcycle.
| Característica | Especificació |
|---|---|
| Dimensions del producte | 45.1 x 25 x 29.7 polzades |
| Pes de l'article | 50.7 lliures |
| Potència del motor | 24V 250W (Brushless) |
| Bateria | 24 V 9 Ah |
| Velocitat màxima | Up to 14 MPH (Dual Speed Modes: 7.5 MPH & 13.7 MPH) |
| Interval màxim | Fins a 10 milles |
| Continuous Ride Time | Fins a 60 minuts |
| Capacitat de càrrega màxima | 132 lliures |
| Edat recomanada | 3 - 13 anys |
| Mida del pneumàtic | 12-inch inflatable rubber-composite tires |
| Sistema de fre | Fre de tambor posterior |
| Far | IPX5 LED Headlight |
| Número de model | 9rmgXPMSxe76WxGsiuZmKwQLNr46 |
| ASIN | B0DFPFDYJV |
| Data de llançament | 30 d'agost de 2024 |
| Fabricant | Hetoy |
8. Garantia i Suport
Hetoy stands behind the quality of its products. For specific warranty details, please refer to the warranty card included with your purchase or visit the official Hetoy weblloc.
If you encounter any issues or have questions regarding your Hetoy Electric Motorcycle, please contact our customer support team:
- Correu electrònic: support@hetoy.com (Example)
- Telèfon: 1-800-XXX-XXXX (Ex.ample)
- Weblloc: Visit the Hetoy Store on Amazon
Please have your model number (9rmgXPMSxe76WxGsiuZmKwQLNr46) and purchase date ready when contacting support.
