Introducció
Thank you for choosing the Akicon Bathroom Exhaust Fan with Humidity Switch and 3CCT LED Light. This manual provides essential information for the safe installation, operation, and maintenance of your new exhaust fan. Please read these instructions thoroughly before installation and retain them for future reference.
Image: The Akicon Bathroom Exhaust Fan with its integrated LED light and the accompanying humidity sensor switch.
Informació de seguretat
ADVERTIMENT: Per reduir el risc d'incendi, descàrrega elèctrica o lesions a les persones, observeu el següent:
- Always disconnect power at the service panel before wiring or servicing this unit. Ensure the main power supply is turned off.
- Installation and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction codes.
- A neutral wire is required for the humidity switch to function correctly.
- Aquesta unitat està pensada només per a ús general de ventilació. No l'utilitzeu per a l'extracció de materials i vapors perillosos o explosius.
- Duct work must be installed to the outside.
- No col·loqueu mai un interruptor on es pugui accedir des d'una banyera o dutxa.
Característiques del producte
- Flux d'aire ajustable: Selectable airflow settings of 50, 80, or 100 Cubic Feet per Minute (CFM) to suit various bathroom sizes and ventilation needs.
- Funcionament silenciós: Operates at a low sound level, below 1.2 sones, ensuring a quiet bathroom environment.
- Motor de corrent continu eficient energèticament: Equipped with a DC motor for powerful performance and reduced energy consumption. Features a soft start and stop mechanism for motor protection.
- Integrated 3CCT LED Light: Features a 15W main LED light with three color temperature options (2700K Warm White, 4000K Natural White, 5500K Day White).
- Funció de llum nocturna: Includes a 7W 2700K night light for soft illumination.
- Humidity Sensor Switch: Automatically detects room humidity levels and activates the fan when humidity exceeds a preset threshold, turning off once levels normalize.
- Adjustable Humidity and Timer Settings: The humidity sensor and timer offer 5 levels each (Humidity: 90%, 80%, 70%, 60%, 50%; Timer: 5, 15, 30, 45, 60 minutes) for customized ventilation control.
- Anulació manual: Allows for manual operation of the fan and light, bypassing the humidity sensor if desired.
Visual Features Overview
Image: Illustration showing the three selectable color temperatures for the LED light: 2700K Warm White, 4000K Natural White, and 5500K Day White.
Image: Diagrams illustrating recommended room sizes (Small, Medium, Large) for 50, 80, and 100 CFM airflow settings, with a detail of the CFM selection switch.
Image: Graphic depicting the exhaust fan's DC motor effectively removing vapor, mold, odor, and smoke from the bathroom environment.
Imatge: Detallada view of the humidity switch, highlighting its LED indicator, humidity sensor, fan switch, LED light switch, and night light switch.
Instal·lació
Installation should be performed by a qualified electrician in compliance with all local and national electrical codes. Ensure power is disconnected at the circuit breaker before beginning installation.
Esquema de cablejat
Image: A detailed wiring diagram showing connections for the humidity switch to the junction box, including lines for night lamp, lighting LED, fan, and neutral wire. Grounding instructions for plastic and metal junction boxes are also provided.
- Desconnexió d'alimentació: Always cut off power at the main circuit breaker before attempting any wiring.
- Fil neutre: A neutral wire is essential for the proper operation of the humidity switch.
- Posada a terra: Ensure proper grounding. If the junction box is plastic, follow the dashed green line for grounding. If metal, follow the solid green line.
- Conductes: Connect the fan's exhaust port to appropriate ductwork leading to the outside.
- Muntatge: The fan is designed for flush mount installation. Secure the fan housing firmly to the ceiling joists or suitable support structure.
Humidity Switch Dimensions
Image: Technical drawing displaying the dimensions of the humidity switch, including its height (4-1/8"), width (3-1/4"), and depth (1-3/4" and 1/3"-1/10").
Instruccions de funcionament
The Akicon exhaust fan and light are controlled by the included humidity sensor switch. This switch offers both automatic and manual modes for optimal control.
Humidity Switch Functions
- Interruptor del ventilador: Press the fan button to manually turn the fan ON or OFF.
- Interruptor de llum LED: Press the light bulb button to cycle through the 3 CCT options (2700K, 4000K, 5500K) within 2 seconds.
- Interruptor de llum nocturna: Press the crescent moon button to turn the night light ON or OFF.
- Sensor d'humitat: The switch automatically detects humidity. When humidity exceeds the set level, the fan will activate.
- Temporitzador: The fan can be set to run for a specific duration (5, 15, 30, 45, 60 minutes) after manual activation or humidity-triggered operation.
Auto Mode vs. Manual Mode
Image: Diagram explaining the Auto Mode and Manual Mode operations of the humidity sensor switch, including how the fan responds to humidity levels and manual button presses.
- Mode automàtic: When the switch is in auto mode, the fan will operate when the humidity level exceeds the set value. It will stop approximately 5 minutes after the humidity drops below the set value.
- Mode manual: Pressing the fan button switches the fan to manual operation. If the fan is turned ON manually, it will switch to auto mode after running for a specified timer duration. If turned OFF manually, it will switch to auto mode after 10 minutes.
- Nota: If the timer is set to OFF, the fan will not switch to auto mode after manual light operation. If the humidity condition is set to OFF, the device will not enter auto mode.
Manteniment
Un manteniment regular garanteix un rendiment òptim i una llarga durada del ventilador d'extracció. Desconnecteu sempre l'alimentació abans de realitzar qualsevol manteniment.
- Neteja de la reixa: Periodically remove the grille and wash it with mild soap and water. Rinse thoroughly and dry before reattaching.
- Neteja de les aspes del ventilador: With power disconnected, gently wipe the fan blades with a damp cloth to remove dust and debris. Avoid bending the blades.
- Inspecció de conductes: Annually inspect the ductwork for any obstructions or damage. Ensure proper airflow.
- Light Cover: Clean the light cover with a soft, damp tela. No utilitzeu netejadors abrasius.
Resolució de problemes
If you experience issues with your Akicon exhaust fan, refer to the following common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| El ventilador no s'encén | Sense font d'alimentació Cablejat solt Humidity sensor not triggered | Comproveu l'interruptor Verify wiring connections (ensure power is off) Manually activate fan or adjust humidity threshold |
| El ventilador fa soroll | Muntatge solt Pales de ventilador brutes Obstruction in ductwork | Ensure fan housing is securely mounted Clean fan blades (power off) Check and clear ductwork |
| La llum no funciona | Sense font d'alimentació Cablejat solt Falla de llum LED | Comproveu l'interruptor Verify wiring connections (power off) Poseu-vos en contacte amb l'assistència al client per a la substitució |
| Humidity sensor not working | Sensor desactivat Configuració incorrecta Mal funcionament del sensor | Ensure humidity condition is not set to OFF Adjust humidity threshold settings Contacta amb l'assistència al client |
Si el problema persisteix després d'intentar aquestes solucions, poseu-vos en contacte amb el servei d'atenció al client d'Akicon.
Especificacions
| Característica | Detall |
|---|---|
| Marca | Akicon |
| Estil del model | Akicon Bathroom Exhaust Fan with Humidity Switch |
| Flux d'aire (CFM) | 50-80-100 (Selectable) |
| Sones | Per sota dels 1.2 |
| Tipus de motor | Motor de corrent continu |
| Main LED Light Power | 15W |
| LED Color Temperature (CCT) | 2700K / 4000K / 5500K (Seleccionable) |
| Potència de llum nocturna | 7W |
| Night Light Color Temperature | 2700K |
| Mètode de control | Touch (via Humidity Switch) |
| Tipus d'instal·lació | Muntatge d'escorredor |
| Tipus d'habitació | Bany |
Garantia i Suport
Akicon products are manufactured to high-quality standards and are backed by a limited warranty. For specific warranty details, please refer to the warranty card included with your product or visit the official Akicon weblloc.
For technical assistance, troubleshooting, or to inquire about replacement parts, please contact Akicon customer support:
- Weblloc: Akicon Official Store
- Correu electrònic: Consulteu l'embalatge del producte o weblloc per obtenir informació de contacte.
- Telèfon: Consulteu l'embalatge del producte o weblloc per obtenir informació de contacte.
