Saker Mini Chainsaw User Manual

Introducció

Thank you for choosing the Saker Mini Chainsaw. This portable electric chainsaw is designed for efficient cutting of tree branches, for use in courtyards, households, and gardens. Its compact size and cordless operation make it a versatile tool for various woodworking and pruning tasks. Please read this manual thoroughly before operation to ensure safe and effective use of your new tool.

Informació important de seguretat

WARNING: Always wear appropriate personal protective equipment (PPE) including safety goggles, gloves, and hearing protection when operating the chainsaw. Keep hands and body clear of the chain when the tool is in operation. Read all safety warnings and instructions.

• Seguretat de l'àrea de treball: Mantingueu la zona de treball neta i ben il·luminada. Les zones desordenades o fosques conviden als accidents. No feu servir eines elèctriques en atmosferes explosives, com ara en presència de líquids, gasos o pols inflamables.
• Seguretat elèctrica: Eviteu el contacte corporal amb superfícies connectades a terra. No exposeu les eines elèctriques a la pluja ni a condicions humides.
• Seguretat personal: Estigueu alerta, observeu el que feu i feu servir el sentit comú quan utilitzeu una eina elèctrica. No utilitzeu una eina elèctrica mentre esteu cansat o sota els efectes de drogues, alcohol o medicaments.
• Seguretat específica de la motoserra:
  • Always hold the chainsaw firmly with both hands when the motor is running.
  • Ensure the safety lock is engaged when not in use and before battery installation/removal.
  • No sobrepasseu. Mantenir un bon peu i un equilibri en tot moment.
  • Aneu amb compte amb el rebot. El rebot es pot produir quan la punta o el nas de la barra guia toca un objecte o quan la fusta s'acosta i pessiga la cadena de la serra durant el tall.
  • Only use the chainsaw for cutting wood. Do not use it for other purposes.

Always wear safety goggles and gloves for protection during operation.

Contingut del paquet

Upon opening your Saker Mini Chainsaw package, please verify that all the following components are included:

• 1 x Saker Mini Chainsaw (6 Inch)
• 1 x barra guia (instal·lada)
• 1 x Saw Chain (Installed) & 2 x Extra Saw Chains
• 2 bateries de ions de liti de 20 V i 1500 mAh
• 1 x carregador dels EUA
• 1 x Clau i tornavís
• 1 x Lube Bottle (empty, for chain oil)
• 1 x Parell d'ulleres de seguretat
• 1 x Pair of Work Gloves
• 1 x Caixa d'emmagatzematge

Contents of the Saker Mini Chainsaw package.

Configuració

1. Càrrega de la bateria

Before first use, fully charge both lithium-ion batteries. Connect the charger to a standard power outlet and insert the battery. The indicator light on the charger will show the charging status. A full charge typically takes approximately two hours.

The 20V MAX 1.5Ah Lithium-Ion battery features fast charging and multiple protection circuits.

2. Chain and Guide Bar Installation (if not pre-installed)

Your chainsaw may come with the chain and guide bar pre-installed. If not, follow these steps:

1. Assegureu-vos que la bateria estigui treta de la motoserra.
2. Loosen the side cover nuts using the provided wrench and remove the side cover.
3. Place the chain around the guide bar, ensuring the cutting teeth are facing the correct direction (refer to the arrow on the guide bar).
4. Fit the chain onto the sprocket and align the guide bar with its mounting studs.
5. Torneu a col·locar la coberta lateral i estrenyeu les femelles a mà.
6. Adjust chain tension: The chain should be snug against the guide bar but still able to be pulled freely by hand. Use the tensioning screw (if present) or slightly loosen/tighten the side cover nuts to adjust.
7. Estrenyeu completament les femelles de la coberta lateral.

3. Lubricació

Fill the provided lube bottle with appropriate chain oil (not included). Apply a small amount of oil to the chain and guide bar before each use to ensure smooth operation and extend chain life.

Instruccions de funcionament

1. Llista de comprovació prèvia a l'operació

• Assegureu-vos que la bateria estigui completament carregada i ben inserida.
• Check chain tension and ensure it is properly lubricated.
• Verify all nuts and bolts are tight.
• Wear all necessary PPE: safety goggles, gloves, and hearing protection.
• Clear the work area of any obstructions.

2. Engegar la motoserra

To start the chainsaw, first press and hold the safety lock button, then squeeze the trigger switch. The chainsaw will begin to operate. Release the trigger to stop the chainsaw.

Key features for safe and comfortable operation: anti-splash baffle, efficient heat dissipation, safety lock, and comfortable handle.

3. Tècniques de tall

• Agafeu fermament la motoserra amb les dues mans.
• Allow the chain to reach full speed before engaging with the material.
• Apply light, consistent pressure. Do not force the saw through the wood.
• For branches, cut from the top down to avoid pinching. For larger pieces, make a relief cut on the underside first.
• Be mindful of the cutting surface length (6 inches) and the total guide bar length (9 inches) to avoid over-stressing the tool.

The Saker Mini Chainsaw is suitable for various cutting tasks including branches, bamboo, and general woodworking.

The 6-inch cuttable surface allows for cutting thicker materials.

Manteniment

1. Esmolat de la cadena

A sharp chain is essential for safe and efficient cutting. Sharpen the chain regularly or replace it when dull. Refer to the chain manufacturer's instructions for proper sharpening techniques or consult a professional.

2. Neteja

• Després de cada ús, traieu la bateria i netegeu la motoserra.
• Use a brush or compressed air to remove sawdust and debris from the guide bar, chain, and motor housing.
• Netegeu l'exterior amb un anunciamp tela. No utilitzeu productes químics durs.

3. Cura de la bateria

• Emmagatzemeu les bateries en un lloc fresc i sec, lluny de la llum solar directa i de temperatures extremes.
• If not using the chainsaw for an extended period, fully charge the battery before storage to maintain battery health.
• No exposeu les bateries a l'aigua o al foc.

Resolució de problemes

Especificacions

The pure copper motor ensures high efficiency and durability.

Garantia i Suport

Saker is confident in the quality of its products. If you encounter any quality problems with your mini cordless chainsaw during daily use, or have any questions regarding its operation or maintenance, please do not hesitate to contact Saker customer service. We are always available to assist you.

For support, please refer to the contact information provided with your purchase or visit the official Saker weblloc.
