USX MOUNT Full Motion TV Wall Mount XML925 User Manual

1. Introducció

This manual provides detailed instructions for the safe and proper installation, operation, and maintenance of your USX MOUNT Full Motion TV Wall Mount, model XML925. This mount is designed to securely hold televisions ranging from 42 to 97 inches and weighing up to 150 lbs (68 kg). It offers full motion capabilities including tilt, swivel, and extension for optimal viewangles d'ajust.

2. Informació de seguretat

WARNING: Failure to read and follow all instructions may result in personal injury, property damage, or voiding of your warranty. If you have any questions, please contact USX MOUNT customer service.

• Ensure the mounting surface can safely support the combined weight of the mount and your TV.
• This product is designed for installation on wood studs (12"/16"/18"/24"), solid concrete walls, or brick walls. DO NOT mount on drywall alone.
• Always use a stud finder to locate the center of wood studs.
• For concrete or brick walls, use appropriate concrete anchors (if not included, contact USX MOUNT for assistance).
• No supereu la capacitat màxima de pes de 150 lliures (68 kg).
• Assegureu-vos que tots els cargols estiguin ben ajustats, però no els estrenyeu massa.
• Professional installation is recommended if you are unsure about any steps.

3. Parts Included Overview

Before installation, verify that all components are present and undamaged. Refer to the image below for a visual guide to the included parts.

Imatge: Més deview of USX MOUNT XML925 TV Wall Mount components.

• Unitat de placa de paret
• Suports per a TV (2 unitats)
• Hardware Bag (various screws, washers, spacers, concrete anchors, Allen key, open-end wrench)
• Plantilla de muntatge
• Nivell de bombolla
• Brides de cable (3 peces)
• Manual d'instruccions

4. Instal·lació

Pas 1: connecteu els suports al televisor

Ensure your TV's VESA pattern is compatible with the mount (Min: 200x100mm, Max: 600x400mm). Select the appropriate screws, washers, and spacers from the hardware bag. Attach the TV brackets to the back of your television. Ensure all four screws enter the VESA hole before tightening. Do not overtighten.

Image: Supported VESA patterns for TV attachment.

Pas 2: enganxeu la placa de paret a la paret

Determine your wall type (wood stud, solid concrete, or brick) and follow the corresponding instructions. Use the provided mounting template and bubble level to mark pilot hole locations accurately.

Image: Mounting options for different wall types (concrete, wood studs, brick).

2A. Wood Stud Installation

• Use a stud finder to locate the edges and center of your wood studs.
• Position the mounting template at your desired height, aligning the holes with your stud center line.
• Drill pilot holes using a 7/32 inch (5.5mm) diameter drill bit to a depth of 2.5 inches (64mm).
• Install the wall plate using four lag bolts. Tighten the lag bolts only until they are pulled firmly against the wall plate. Do not overtighten.

2B. Solid Concrete or Brick Wall Installation

• Position the mounting template at your desired height and mark the hole locations.
• Drill four pilot holes using a 3/8 inch (10mm) diameter masonry drill bit to a depth of 2.5 inches (64mm).
• Insert concrete anchors into the pilot holes.
• Install the wall plate using four lag bolts. Tighten the lag bolts only until they are pulled firmly against the wall plate. Do not overtighten.

Step 3: Wall Plate Installation Integrity Test

After securing the wall plate, firmly pull on the mount to ensure it is tightly and securely fastened to the wall. This test helps confirm the stability of your installation.

Step 4: Hang and Secure TV to Wall Plate

Carefully lift the TV (with brackets attached) and hook it onto the wall plate. Ensure the TV is properly seated. Secure the TV to the wall plate by wrapping clips around the extension arms and tightening them using bolts.

5. Funcionament

Your USX MOUNT Full Motion TV Wall Mount offers versatile adjustments for optimal viewing.

Ajustaments

• Angle d'inclinació: Adjust the TV tilt from +5° to -15° to reduce glare and find the perfect vertical viewing angle. Loosen the tilting bolts, adjust, and then re-tighten.
• Angle de gir: Swivel the TV up to ±45° left or right to view from different seating positions.
• Ajust de nivellació: Correct any slight misalignments after installation with a ±4° leveling adjustment. This is typically done via screws on the TV plate.
• Extensió i retracció: Extend the TV up to 16.61 inches (422mm) from the wall or retract it to a low profile de 2.52 polzades (64 mm).

Image: Demonstrates the mount's extension, retraction, and tilt capabilities.

Image: Illustrates the TV mount's swivel function for flexible viewing.

6. Manteniment

• Reviseu periòdicament tots els cargols i connexions per assegurar-vos que estiguin ben ajustats i segurs.
• Netegeu el suport amb un drap suau i sec. Eviteu netejadors o dissolvents abrasius.
• If the mount's movement becomes stiff, apply a small amount of silicone-based lubricant to the pivot points.
• Use the included cable ties to manage TV cables neatly along the mount arms, preventing tangles and damage.

7. Solució De Problemes

• El televisor no està anivellat: Use the leveling adjustment screws on the TV plate to correct the horizontal alignment (±4°).
• La muntura se sent fluixa: Re-check all lag bolts securing the wall plate to the wall and all screws attaching the TV brackets to the TV. Ensure they are tightened firmly.
• Difficulty moving the TV: Ensure no cables are obstructing the movement. Check pivot points for any debris or stiffness; apply lubricant if necessary.
• Peces que falten: Refer to the parts list. If any parts are missing, contact USX MOUNT customer service.

8. Especificacions

Image: The mount's robust design supports TVs up to 150 lbs.

9. Garantia i Suport

USX MOUNT products are manufactured with quality and customer satisfaction in mind. For specific warranty details, please refer to the product packaging or contact USX MOUNT customer service. If you encounter any issues or have questions regarding your TV mount, please reach out to our support team for assistance.

Contact information can typically be found on the product packaging or the official USX MOUNT weblloc.
