1. Introducció
Welcome to the user manual for your new redbeat M2 11-inch Android 15 Gaming Tablet. This guide provides essential information for setting up, operating, maintaining, and troubleshooting your device. Please read this manual thoroughly to ensure optimal performance and longevity of your tablet.
Image: redbeat M2 Gaming Tablet with its protective case.
2. Què hi ha a la caixa
Upon unboxing your redbeat M2 tablet, verify that all the following items are included:
- Tauleta M2
- Estoig negre
- Cable tipus C
- Llibre d'instruccions
- Agulla de la targeta
Image: All items included in the redbeat M2 tablet package.
3. Configuració
Follow these steps to set up your redbeat M2 tablet for first-time use:
- Encès: Press and hold the power button located on the side of the tablet until the redbeat logo appears.
- Selecció d'idioma: Trieu l'idioma que preferiu de la llista.
- Connexió Wi-Fi: Connect to a Wi-Fi network by selecting your network and entering the password.
- Compte de Google: Sign in with your Google account or create a new one. This is necessary to download apps from the Google Play Store.
- Configuració de seguretat: Configura un bloqueig de pantalla (PIN, patró o contrasenya) per a la seguretat del dispositiu.
- Mode de lectura: Configure your preferred reading mode (chromatic or grayscale) for optimal viewcomoditat.
- Mode de navegació: Select your preferred navigation method (e.g., 3-button navigation or gesture navigation).
Video: A demonstration of the redbeat M2 tablet's initial setup and user interface.
4. Producte acabatview
The redbeat M2 tablet features a sleek, all-metal body with a thickness of 0.75mm and a weight of 511g, making it highly portable. Key physical components include:
- Botó d'encesa: Located on the side, used for powering on/off and screen lock.
- Botons de volum: Ajusta el volum de l'àudio.
- Port USB-C: Per a càrrega i transferència de dades.
- Presa d'auriculars de 3.5 mm: Per a la sortida d'àudio.
- Ranura per a targeta MicroSD: Per a emmagatzematge ampliable.
- Dual SIM Card Slot: Supports 2 Nano SIM cards for 4G LTE connectivity.
- Càmera frontal: Per a videotrucades i selfies.
- Càmera posterior: Per a fotos i vídeos d'alta resolució.
- Ponents: Four stereo speakers for immersive audio.
Image: The redbeat M2 tablet showcasing és Slim Profile and protective case.
Video: A brief demonstration of a tablet's ultra-thin metal body, similar to the redbeat M2.
5. Instruccions de funcionament
The redbeat M2 runs on the Android 15 operating system, offering a personalized and secure user experience. It is GMS certified, allowing full access to the Google Play Store for downloading your favorite applications.
Navegació bàsica:
- Llisca: Navigate through home screens, app drawers, and menus.
- Toca: Select items, open apps, or confirm actions.
- Pessiga per fer zoom: Ampliar o reduir el contingut de la pantalla.
- Three-Pointer Screenshot: Use a three-finger gesture to quickly capture a screenshot.
Video: Demonstration of the three-pointer screenshot gesture on an Android tablet.
6. Connectivitat
Stay connected with the redbeat M2's versatile connectivity options:
- 4G LTE Dual SIM: The tablet supports two Nano SIM cards, allowing you to make calls and access mobile data simultaneously. Compatible network frequencies include GSM: B2/3/5/8, WCDMA: B1/2/4/5/8, LTE: B1/2/3/4/7/8/12/17/20/28ab/40/41/38/66.
- Wi-Fi de doble banda: Supports 2.4G and 5G Wi-Fi for fast and stable internet access.
- Bluetooth 5.0: For efficient wireless connection to accessories like headphones and keyboards.
- GPS: Integrated GPS for navigation and location services.
Image: redbeat M2 tablet highlighting its 4G Global Connectivity and dual SIM support.
7. Pantalla i rendiment
Experience smooth performance and vibrant visuals:
- Processador: Powered by the Unisoc T616 octa-core processor, ensuring optimal performance for gaming, high-definition video playback, and graphics-intensive applications.
- RAM: 16GB RAM (8GB physical + 8GB extended memory) for seamless multitasking.
- Emmagatzematge: 256GB ROM, expandable up to 1TB with an SD/TF card (not included), providing ampespai per a aplicacions, contingut multimèdia i documents.
- Visualització: 11-inch 2K display with a resolution of 1915*1200, offering sharper images and richer colors.
Image: Key advantages and specifications of the redbeat M2 tablet.
8. Càmera
Capture your moments with the integrated cameras:
- Càmera posterior: 13MP for clear photos and videos.
- Càmera frontal: 5MP per a videotrucades i selfies.
9. Bateria i càrrega
The redbeat M2 is equipped with an 8000mAh large-capacity battery and supports 18W fast charging:
- Temps d'ús: Up to 12 hours of continuous TV watching or 10 hours of gaming on a full charge.
- Temps d'espera: Fins a 30 dies.
- Càrrega: Use the provided 18W fast charger and Type-C cable for quick recharging.
Image: Details on the 8000mAh battery and its benefits.
Video: A demonstration of a tablet's large battery capacity and reverse charging capabilities.
10. Manteniment
To ensure the longevity and optimal performance of your redbeat M2 tablet, follow these maintenance guidelines:
- Neteja: Feu servir un drap suau i sense borrissol per netejar la pantalla i la carcassa. Eviteu productes químics agressius.
- Actualitzacions de programari: Comproveu i instal·leu regularment si hi ha actualitzacions del sistema per aprofitar les darreres funcions, pegats de seguretat i millores de rendiment.
- Cura de la bateria: Eviteu les temperatures extremes. No deixeu que la bateria es descarregui completament amb freqüència.
- Gestió d'emmagatzematge: Netegeu periòdicament els innecessaris filei aplicacions per alliberar espai d'emmagatzematge i mantenir el rendiment.
11. Solució De Problemes
If you encounter issues with your redbeat M2 tablet, try the following solutions:
- El dispositiu no respon: Premeu i manteniu premut el botó d'engegada durant uns 10-15 segons per forçar un reinici.
- Problemes amb el Wi-Fi/Bluetooth: Toggle Wi-Fi or Bluetooth off and on. Restart your router if Wi-Fi problems persist.
- Bloqueig de l'aplicació: Clear the app's cache and data in Settings > Apps. If the issue continues, uninstall and reinstall the app.
- Rendiment lent: Tanqueu les aplicacions que no feu servir, esborreu la memòria cau i assegureu-vos que hi hagi prou espai d'emmagatzematge. Considereu un restabliment de fàbrica com a últim recurs (feu una còpia de seguretat de les vostres dades primer).
- Esgotament ràpid de la bateria: Reduce screen brightness, disable unnecessary features (GPS, Bluetooth, Wi-Fi when not in use), and identify power-hungry apps in battery settings.
12. Especificacions
| Característica | Especificació |
|---|---|
| Marca | redbeat |
| Nom del model | M2 |
| Sistema operatiu | Android 15 |
| Mida de la pantalla | 11 polzades |
| Resolució de pantalla | 1920 x 1200 píxels (2K) |
| Processador | Unisoc T616 Octa-Core (2 GHz) |
| RAM | 16GB (8GB + 8GB extended) |
| Emmagatzematge intern | 256 GB |
| Emmagatzematge ampliable | Up to 1TB (via MicroSD/TF card) |
| Capacitat de la bateria | 8000 mAh |
| Càrrega ràpida | 18W |
| Càmera posterior | 13MP |
| Càmera frontal | 5MP |
| Connectivitat | 4G LTE (Dual SIM), 2.4G/5G Wi-Fi, Bluetooth 5.0, GPS |
| Dimensions | 10.28 x 6.89 x 0.47 polzades |
| Pes de l'article | 1.54 lliures (aprox. 698 g) |
| Color | Black set |
13. Garantia i Suport
redbeat is committed to providing excellent customer service:
- Suport al client de per vida: redbeat offers lifetime customer service to assist with any queries or issues you may encounter.
- Garantia d'un any: The tablet includes a one-year warranty covering manufacturing defects, ensuring your investment is protected.
- Contacte amb l'assistència: You can contact support by clicking on the seller's name under the 'Add to cart' button on the product page and sending a message via 'Ask a question'. Alternatively, go to your Amazon account > order history > relevant order > contact the seller.
