Manual d'usuari de l'escalfador pla de ceràmica Ufesa Alpha Ceramic 2000W

1. Instruccions de seguretat

Please read all safety instructions carefully before using the Ufesa Alpha Ceramic heater. Failure to follow these instructions may result in electric shock, fire, or injury.

• Seguretat elèctrica: Assegureu-vos que el voltage indicated on the rating label matches your mains supply. Do not operate the heater with a damaged cord or plug. Do not immerse the heater in water or other liquids.
• Protecció contra el sobreescalfament: The heater is equipped with an automatic overheat protection system. If the heater overheats, it will automatically shut off. Unplug the unit, allow it to cool down for 30 minutes, and remove any obstructions before restarting.
• Col·locació: Always place the heater on a stable, flat, and heat-resistant surface. Maintain a safe distance from walls, furniture, curtains, and other flammable materials (at least 1 meter). Do not cover the heater.
• Ventilació: Ensure adequate ventilation around the heater. Do not block the air inlet or outlet grilles.
• Humitat: No utilitzeu l'escalfador en banys, bugaderies o llocs similars.amp indoor locations. Avoid direct contact with water or high humidity.
• Nens i animals de companyia: Keep the heater out of reach of children and pets. Do not leave the heater unattended when in operation.
• Moure la unitat: Always use the integrated carry handle when moving the heater. Ensure the unit is unplugged and cool before moving.
• Manteniment: Unplug the heater before cleaning or performing any maintenance.

2. Producte acabatview

The Ufesa Alpha Ceramic heater is a compact and efficient heating solution, featuring ceramic technology for rapid and even heat distribution. It includes an adjustable thermostat and multiple power settings, including a fan-only mode for year-round use.

Característiques principals:

• Potència de 2000 W: Provides quick and effective heating for small to medium-sized rooms.
• Element de calefacció de ceràmica: Ensures efficient and consistent heat without drying the air.
• 3 nivells de potència: Two heating modes (low and high) and a fan-only mode.
• Termostat ajustable: Allows precise temperature control for personalized comfort.
• Disseny compacte i portàtil: Flat design with an integrated carry handle for easy transport and space optimization.
• Protecció contra el sobreescalfament: Apagada automàtica per a una major seguretat.

Components:

1. Llum indicador d'alimentació
2. Thermostat Control Knob (MIN/MAX)
3. Function/Power Selector Knob (OFF, Fan, Low Heat, High Heat)
4. Reixa de sortida d'aire
5. Air Inlet Grille (rear)
6. Mànec de transport integrat

Figura 1: Frontal view of the Ufesa Alpha Ceramic heater, showing the main air outlet and brand logo.

Figura 2: lateral view illustrating the thermostat control knob (MIN/MAX) and the function/power selector knob (OFF, Fan, Low Heat, High Heat).

3. Configuració

1. Desembalar: Traieu amb cura l'escalfador del seu embalatge. Conserveu l'embalatge per a futurs emmagatzematges o transports.
2. Col·locació: Place the heater on a firm, level, and stable surface. Ensure it is at least 1 meter (3 feet) away from any walls, furniture, curtains, or other flammable materials. Do not place it directly under a power outlet.
3. Connexió d'alimentació: Ensure the heater is switched to the "OFF" position (0 on the function selector knob) before plugging it into a suitable electrical outlet.

4. Instruccions de funcionament

Follow these steps to operate your Ufesa Alpha Ceramic heater:

1. Encès: Plug the heater into a grounded electrical outlet. The power indicator light will illuminate when the unit is receiving power.
2. Select Function/Power Level: Use the Function/Power Selector Knob (refer to Figure 2) to choose your desired mode:
   • 0 (DESACTIVAT): Apaga la calefacció.
   • Només ventilador: Activa el ventilador sense calor, útil per a la circulació de l'aire.
   • I (Foc baix): Provides heating at a lower power output (e.g., 1000W).
   • II (Calor intensa): Provides heating at the maximum power output (2000W).
3. Ajustar el termòstat: Rotate the Thermostat Control Knob (refer to Figure 2) to your desired temperature setting.
   • Turn the knob clockwise towards "MAX" for higher temperatures.
   • Turn the knob counter-clockwise towards "MIN" for lower temperatures.
   • L'escalfador s'encendrà i s'apagarà per mantenir la temperatura establerta.
4. Apagar: To turn off the heater, rotate the Function/Power Selector Knob to the "0" (OFF) position. Unplug the heater from the wall outlet when not in use.

5. Manteniment

Una neteja regular i un emmagatzematge adequat garantiran la longevitat i el funcionament eficient del vostre escalfador.

• Neteja:
  1. Desendolleu sempre l'escalfador i deixeu-lo refredar completament abans de netejar-lo.
  2. Netegeu les superfícies exteriors amb un damp tela. No utilitzeu netejadors abrasius ni dissolvents.
  3. Use a vacuum cleaner with a brush attachment to gently clean dust from the air inlet and outlet grilles.
  4. Assegureu-vos que no entri aigua a l'interior de l'escalfador.
• Emmagatzematge:
  1. Quan no estigui en ús, guardeu l'escalfador en un lloc fresc i sec.
  2. Es recomana guardar l'escalfador en el seu embalatge original per protegir-lo de la pols i els danys.

Figura 3: posterior view of the heater, showing the air inlet grille. Keep this area clear of dust and obstructions for optimal performance.

6. Solució De Problemes

If you encounter issues with your Ufesa Alpha Ceramic heater, refer to the following table:

7. Especificacions

8. Garantia i Suport

For warranty information and customer support, please refer to the documentation included with your purchase or visit the official Ufesa weblloc web. Conserveu el comprovant de compra per a qualsevol reclamació de garantia.

Ufesa Official Weblloc: www.ufesa.es

For direct support, please contact Ufesa customer service through their weblloc web o les dades de contacte que figuren a l'embalatge del producte.
