1. Producte acabatview
The GIOTOHUN H1-3.2L Cat Water Fountain is designed to provide fresh, circulating water for your pets. It features a 3.2-liter capacity, a triple filtration system, and quiet operation to encourage healthy hydration habits.
A black and clear cat water fountain with a stainless steel faucet, showing the water level and a separate image of six white filters and three black sponge filters.
A cat is shown sleeping soundly in a pet bed next to the GIOTOHUN cat water fountain, emphasizing the product's quiet operation.
2. Contingut del paquet
Si us plau, verifiqueu que tots els components siguin presents al vostre paquet:
- Cat Water Fountain Unit (Base and Top)
- Bomba d'aigua
- Activated Carbon Filters (6 pieces)
- Sponge Filters (3 pieces)
- Adaptador d'alimentació
An image displaying the various filter components included with the fountain, such as activated carbon filters and sponge filters.
3. Instruccions de seguretat
- Aquest producte està destinat a només per a ús interior.
- Keep the fountain and power cord out of reach of children and pets when not in use or during cleaning.
- Use only the provided power adapter. Do not use other adapters.
- Do not immerse the power adapter or electrical plug in water or other liquids.
- Always unplug the fountain from the power outlet before cleaning, disassembling, or performing any maintenance.
- Regularly inspect the power cord for any damage or signs of pet chewing. Discontinue use if damaged.
- Assegureu-vos que la font estigui col·locada sobre una superfície estable i anivellada per evitar que es bolqui.
4. Guia de configuració
Follow these steps to assemble and set up your cat water fountain:
- Components d'esbandida: Thoroughly rinse the fountain base, top cover, water pump, and all filter components with clean water.
- Instal·lar la bomba: Place the water pump into the designated slot at the bottom of the fountain base. Ensure the power cord is routed through the cable groove to prevent pinching.
- Place Filters: Insert a sponge filter onto the pump intake. Place an activated carbon filter into its designated tray on the fountain's top cover.
- Omplir amb aigua: Fill the fountain base with clean water up to the 'MAX' line. The total capacity is 3.2 liters (108 oz). Do not overfill.
- Muntar la font: Carefully place the top cover onto the base, ensuring it is securely seated and the faucet aligns properly.
- Connectar l'alimentació: Plug the power adapter into a standard wall outlet. The fountain will begin operating automatically.
Nota: For the first use, soak the activated carbon filter in water for 3-5 minutes to remove any carbon dust before placing it in the fountain.
A person's hand pouring water from a pitcher into the clear base of the cat water fountain, demonstrating the ease of refilling. The base has 'MAX' and 'MIN' water level indicators.
5. Instruccions de funcionament
Once properly set up and plugged in, the GIOTOHUN H1-3.2L Cat Water Fountain will operate continuously, providing fresh, flowing water for your pet.
Water Flow Modes
The fountain offers two distinct water flow modes: a faucet mode and a bubbling fountain mode. These dynamic water flows are designed to attract pets and encourage them to drink more, which is beneficial for their kidney health.
A fluffy white cat is shown drinking water from the flowing faucet of the black GIOTOHUN cat water fountain, highlighting the faucet mode.
Funció de llum LED
The built-in LED light illuminates the water tank, allowing you to easily monitor the remaining water level without needing to open the fountain. The light also serves to attract pets to the fountain, making it easier for them to find and drink water, especially in low-light conditions or at night.
A ginger cat is shown approaching the illuminated GIOTOHUN cat water fountain in a dimly lit room, demonstrating the built-in LED light feature that helps attract pets and indicates water level.
6. Manteniment
Regular cleaning and filter replacement are essential for maintaining optimal water quality and extending the lifespan of your fountain and pump.
Neteja de la font
- Desconnectar: Always disconnect the power adapter from the wall outlet before cleaning.
- Desmuntar: Separate the top cover from the base. Remove the water pump and all filter components.
- Components nets: Wash the fountain base, top cover, and faucet with mild soap and water. Rinse all parts thoroughly to remove any soap residue.
- Neteja la bomba: Disassemble the pump by removing its cover and impeller cap. Carefully remove the impeller. Clean the impeller and the pump housing using a small brush to remove any hair, debris, or mineral buildup.
- Torneu a muntar: Reassemble the pump and then the entire fountain after all parts are clean.
Recomanació: Clean the entire fountain and pump every 2-4 weeks to prevent slime buildup and ensure proper function.
A visual guide illustrating how to clean the fountain's pump. Step 1 shows removing the pump cover and impeller cap. Step 2 shows removing the impeller. Step 3 shows cleaning the components with a brush. A 1.5W pump is also shown.
Substitució del filtre
The triple filtration system includes activated carbon filters and sponge filters. Regular replacement ensures your pet receives clean, fresh, and oxygen-rich water.
- Filtre de carbó activat: Replace every 2-4 weeks.
- Filtre d'esponja: Replace every 2-4 weeks, or as needed if visibly dirty.
An illustration detailing the triple filtration system, consisting of a carbon filter, cotton layer, and sponge filter, designed to provide clean water.
7. Solució De Problemes
Consulteu la taula següent per veure els problemes habituals i les seves solucions:
| Problema | Solució |
|---|---|
| Sense flux d'aigua | Check if the power adapter is securely plugged in. Ensure the water level is above the 'MIN' line. Clean the pump impeller for any blockages. |
| Soroll excessiu | Ensure the water level is sufficient (above 'MIN'). Clean the pump for any debris or mineral buildup. Verify the pump is properly seated in its slot. |
| L'aigua té mal gust o fa mala olor | Replace the activated carbon filter. Perform a thorough cleaning of all fountain components. |
| Slime or algae buildup | Increase the frequency of cleaning the fountain and pump. Ensure all parts are scrubbed thoroughly. |
8. Especificacions del producte
| Característica | Detall |
|---|---|
| Marca | GIOTOHUN |
| Número de model | H1-3.2L |
| Capacitat | 3.2 litres (108 oz) |
| Material | Plàstic |
| Pes de l'article | 0.69 quilograms (1.52 lliures) |
| Dimensions de l'article (L x A x A) | 9.13 x 9.02 x 4.61 polzades |
| Potència de la bomba | 1.5W |
| Nivell de soroll | ≤30dB |
9. Garantia i Suport
Informació de la garantia
The GIOTOHUN H1-3.2L Cat Water Fountain comes with a 2 any de garantia des de la data de compra, cobrint defectes de fabricació.
Atenció al client
If you encounter any problems with your product or require replacement parts, please contact GIOTOHUN customer service. Replacement parts, including filters and pumps, are available for purchase in our store.
