Greluna MGD010

Greluna Solar Pathway Lights Outdoor Instruction Manual

Model: MGD010

Brand: Greluna

1. Introducció

Thank you for choosing Greluna Solar Pathway Lights. These unique mushroom-shaped LED lights are designed to illuminate and decorate your garden, path, patio, driveway, and backyard. Featuring high-efficiency solar charging and automatic dusk-to-dawn operation, they provide an energy-saving and hassle-free lighting solution for your outdoor spaces. Built with durable, waterproof materials, these lights are designed to withstand various weather conditions.

2. Contingut del paquet

Si us plau, verifiqueu que tots els components siguin presents al vostre paquet:

3. Configuració i instal·lació

The Greluna Solar Pathway Lights are designed for effortless installation without the need for wiring or additional tools. Follow these simple steps:

  1. Desempaquetar components: Carefully remove all solar light units and ground stakes from the packaging.Components of Greluna solar light: mushroom top with solar panel, clear light housing, and ground stake.

    Imatge: Primer pla view of the solar light components, showing the mushroom-shaped light head with its integrated solar panel, the clear light housing, and the separate ground stake. This image also highlights the internal AAA battery compartment and the simple assembly process.

  2. Activa la llum: Before first use, ensure the internal battery is properly connected. Some units may have a pull tab or require a slight twist to activate the switch.
  3. Muntar la llum: Attach the mushroom-shaped light unit to the top of the ground stake. Ensure it is securely fastened.Diagram showing assembly steps: inserting battery, attaching light head to stake, and pushing into ground.

    Image: A four-panel diagram illustrating the assembly process. The first panel shows inserting the AAA battery, the second shows twisting the light head onto the stake, the third shows pushing the assembled light into the ground, and the fourth shows the light illuminated at night.

  4. Tria la ubicació: Seleccioneu una ubicació a l'aire lliure que rebi direct sunlight for 6-8 hours daily. This is crucial for optimal charging and performance. Avoid placing lights under trees, eaves, or other shaded areas that might block sunlight or artificial light sources at night, which can interfere with the automatic sensor.
  5. Inserir a terra: Gently push the assembled light, with the ground stake first, into the soil. If the ground is too hard, it is recommended to loosen the soil or dig a small hole first to avoid damaging the stake.Greluna solar light dimensions and tip for hard ground.

    Image: A visual representation of the Greluna solar light's height (9.45 inches) when fully assembled and inserted into the ground. A helpful tip is included, advising to dig a hole with a tool if the ground is too hard, accompanied by an illustration of a small shovel.

Once installed, the lights will automatically charge during the day and illuminate at night.

4. Instruccions de funcionament

The Greluna Solar Pathway Lights are designed for fully automatic operation:

5. Manteniment

To ensure optimal performance and longevity of your Greluna Solar Pathway Lights, follow these maintenance guidelines:

6. Solució De Problemes

If your Greluna Solar Pathway Lights are not functioning as expected, please refer to the following common issues and solutions:

ProblemaCausa possibleSolució
La llum no s'encén a la nit.
  • Insuficient llum solar per a la càrrega.
  • El panell solar està brut.
  • Battery is not activated or is depleted.
  • Light sensor is detecting ambient light.
  • Trasllada la llum a una zona amb 6-8 hores de llum solar directa.
  • Netegeu la superfície del panell solar.
  • Check if the battery pull tab is removed or if the battery needs replacement.
  • Ensure no strong artificial light (streetlights, porch lights) is shining on the solar panel at night.
La llum es manté encesa durant el dia.
  • El sensor de llum està obstruït o defectuós.
  • Clean the solar panel and surrounding area to ensure the sensor is clear.
  • If the problem persists, the unit may be faulty.
La llum és tènue o només roman encesa durant poc temps.
  • Càrrega insuficient.
  • Battery is old or weak.
  • Ensure the light receives full direct sunlight for 6-8 hours.
  • Replace the rechargeable AAA battery.

7. Especificacions

CaracterísticaDetall
MarcaGreluna
Número de modelMGD010
Tipus de font de llumLED
Font d'alimentacióEnergia solar
Bateria1.2V 250mAh AAA Rechargeable (included)
Temps de càrrega6-8 hores (raig solar directa)
Temps de treball8-10 hores (amb càrrega completa)
MaterialAcrilonitril butadiè estirè (ABS)
ColorBlanc càlid
Classificació impermeableIP44
Dimensions del producte7"L x 2"W x 2"H (approximate, when assembled)
Recompte d'unitats8.0 recompte

8. Garantia i Suport

Greluna products are manufactured with quality and performance in mind. For any questions, concerns, or warranty inquiries regarding your Greluna Solar Pathway Lights, please contact Greluna customer support through the retailer's platform or the official Greluna weblloc web. Si us plau, conserveu el comprovant de compra per a reclamacions de garantia.
