YSHTKS D1 Ultrasonic Electric Dental Scaler Instruction Manual

1. Introducció

Thank you for choosing the YSHTKS D1 Ultrasonic Electric Dental Scaler. This device is designed to assist in the removal of dental plaque, tartar, and stains from teeth using high-frequency vibration technology. Please read this manual thoroughly before use to ensure safe and effective operation.

2. Informació important de seguretat

Per a la vostra seguretat, tingueu en compte el següent:

• The plaque remover activates only when its tip makes contact with teeth or other hard surfaces. It will automatically stop vibrating upon touching soft tissues like gums or skin.
• Always ensure the device is fully charged before initial use.
• Before applying to teeth, it is recommended to test the device on a metal or ceramic object to familiarize yourself with its operation.
• This device is intended for personal oral hygiene. Consult a dental professional for severe dental conditions or if you have any concerns.

3. Contingut del paquet

The YSHTKS D1 Ultrasonic Electric Dental Scaler package includes:

• 1 x YSHTKS D1 Ultrasonic Electric Dental Scaler device
• 4 x Replaceable Cleaning Heads (various shapes for different cleaning needs)
• 1 x Dental Mirror
• 1 x Dental Pick/Probe
• 1 x Wrench for replacing heads
• 1 x cable de càrrega USB tipus C
• 1 x Manual d'usuari

4. Característiques del producte

The YSHTKS D1 Ultrasonic Electric Dental Scaler offers advanced features for effective oral care:

• High-Efficiency Vibration: Utilizes high-frequency vibration technology for efficient removal of dental plaque and tartar.
• Gums Protection: Features a smart safety mechanism that automatically stops vibration when the tip touches soft tissues, ensuring gum safety.
• 4 modes de velocitat: Offers four distinct intensity modes (Soft, Normal, Middle, Strong) to cater to various sensitivity levels and cleaning needs.
• 4 Replaceable Heads: Comes with multiple stainless steel heads, including pointed and flat designs, for comprehensive cleaning of different tooth surfaces and gum lines.
• Llum LED integrada: A built-in LED light enhances visibility during use, allowing for precise targeting of problem areas.
• Bateria recarregable: Equipped with a large-capacity lithium polymer battery, rechargeable via Type-C USB, providing extended use between charges.
• IPX6 Impermeable: Designed with an IPX6 waterproof rating, allowing for safe and easy cleaning under running water. Avoid full immersion.

5. Configuració

5.1 Càrrega inicial

Before first use, fully charge the device using the provided USB Type-C cable. Connect the cable to the charging port on the device and a compatible USB power source (e.g., PC, 5V adapter, power bank). The battery indicator will show charging status.

5.2 Attaching a Cleaning Head

Select the appropriate cleaning head for your needs. Use the provided wrench to securely attach or remove the cleaning heads. Ensure the head is firmly in place before use.

6. Instruccions de funcionament

6.1 Encès/Apagat

Manteniu premut el botó d'engegada durant uns segons per encendre o apagar el dispositiu.

6.2 Selecció d'un mode

Once powered on, short press the power button to cycle through the four intensity modes: Soft, Normal, Middle, and Strong. The selected mode will be indicated on the device's display.

6.3 Procediment de neteja

1. Select your desired cleaning mode. For first-time users or those with sensitive teeth, start with the 'Soft' or 'Normal' mode.
2. Position the tip of the cleaning head gently against the surface of your teeth where plaque or tartar is present. The device will begin to vibrate upon contact with a hard surface.
3. Move the device slowly and carefully along the tooth surface, focusing on areas with buildup. Use the dental mirror to access hard-to-reach areas and ensure thorough cleaning.
4. Avoid applying excessive pressure or prolonged contact on a single spot.
5. The integrated LED light will illuminate the cleaning area for better visibility.
6. After cleaning, rinse your mouth thoroughly with water.

7. Manteniment

7.1 Neteja del dispositiu

The YSHTKS D1 is IPX6 waterproof, allowing for easy cleaning. After each use, rinse the cleaning head and the device under running water. Ensure no debris remains on the tip or device body. Do not immerse the entire device in water.

7.2 Emmagatzematge

Store the device and its accessories in a clean, dry place, away from direct sunlight and extreme temperatures. Keep out of reach of children.

8. Solució De Problemes

• Device not vibrating: If the device is powered on but not vibrating, ensure the cleaning tip is in firm contact with a hard surface, such as a tooth. The device is designed to only vibrate when touching hard objects to protect soft tissues.
• Concern about gum damage: The device incorporates a safety feature that automatically ceases vibration when it comes into contact with soft tissues like gums. This design prevents accidental damage to your gums.
• Rendiment reduït: Ensure the device is fully charged. If performance remains low, check if the cleaning head is securely attached or if it needs replacement.

9. Especificacions

10. Garantia i Suport

For any questions, concerns, or support regarding your YSHTKS D1 Ultrasonic Electric Dental Scaler, please contact the manufacturer's customer service. Our professional support team is committed to responding within 24 hours to assist you.
