VOLANTEXRC F4U Corsair 4CH Brushless RC Plane Instruction Manual

1. Introducció i finalview

The VOLANTEXRC F4U Corsair is a 4-channel remote control airplane designed for both beginners and experienced pilots. It features a powerful brushless motor and a 6-axis gyro stabilization system, offering three distinct flight modes for progressive learning and advanced aerobatics.

• Xpilot Gyro Stabilizer System: Offers 3-level flight control assist (Beginner, Intermediate, Expert) for pilots of all skill levels.
• Motor sense escombretes: Provides enhanced power and durability compared to coreless motors.
• One-Button Aerobatics: Perform rolls and flips with a single button press.
• Característiques avançades: Includes one-key takeoff, one-key U-turn, low battery alarm, and over-range alarm for a safer and more enjoyable flight experience.
• Detalls de l'escala: Features a simulated dashboard, 3D pilot, 4-bladed propeller, and exquisite landing gear for a realistic appearance.
• Construcció duradora: Made from FLEEX foam for durability and flexibility.

Imatge: Més deview of VOLANTEXRC F4U Corsair features including Xpilot stabilization, brushless motor, 360-degree rotation, 4-channel control with aileron, propeller saver, and FLEEX foam construction.

2. Contingut del paquet

Assegureu-vos que tots els elements que s'enumeren a continuació estiguin presents al vostre paquet:

• Control remot
• Bateria (2 inclosa)
• Cable de càrrega
• Manual de producte
• Hélices addicionals

Image: The 'Ready to Fly' package contents, showing the F4U Corsair airplane, remote control, two batteries, charging cable, manual, and a spare propeller.

Video: An unboxing video demonstrating the contents of the F4U Corsair Brushless RC Plane package, including the aircraft, remote control, batteries, and accessories.

3. Informació de seguretat

For external use only. Always operate the RC plane in open, clear areas away from people, animals, and obstacles. Read the entire manual before operation.

4. Configuració

4.1 Muntatge

The F4U Corsair comes fully assembled and is ready to fly in approximately 1 minute. No complex assembly is required.

4.2 Instal·lació de la bateria

1. Install 4 AA batteries (not included) into the remote control.
2. Connect the flight battery (7.4V 400mAh LiPo) to the aircraft's power connector.
3. Securely place the battery inside the aircraft's battery compartment.

4.3 Transmitter Setup and Binding

After installing batteries in both the remote and the aircraft, ensure the remote control's indicator light stops flashing to confirm successful binding. Unlock the throttle by moving the throttle stick to its lowest position and then back up.

Image: The F4U Corsair RC plane, remote control, and accessories, illustrating the components for setup.

5. Instruccions de funcionament

5.1 Flight Modes (Xpilot Gyro Stabilizer)

The Xpilot gyro stabilizer system offers three flight modes:

• Mode principiant: Full assist for maximum stability, ideal for new pilots.
• Mode intermedi: Partial assist, allowing more control while maintaining some stability.
• Mode expert: Manual control with no assist, for experienced pilots to perform advanced maneuvers.

Image: Visual representation of the three flight modes (Full Assist, Soft Assist, No Assist) provided by the Xpilot stabilization system.

5.2 Controls bàsics

Use the remote control sticks to manage the aircraft's movement:

• Acceleració: Controls engine speed and altitude.
• Aleró: Controls rolling motion (left/right bank).
• Ascensor: Controla el to (nas amunt/avall).
• Timó: Controla el guinyat (nas esquerra/dreta).

5.3 One-Key Functions

The aircraft features several one-button operations for ease of use:

• Enlairament amb una sola clau: Press the button to automatically take off to a certain altitude.
• One-Key Aerobatics: Simply press a button to perform a flip or roll.
• One-Key U-Turn: The plane will automatically return in the opposite direction from its starting point.

Image: The F4U Corsair performing a one-key takeoff, ascending automatically after a simple button press.

Image: Multiple F4U Corsair planes performing aerobatic stunts in the sky, activated by a single button press.

Video: A demonstration of the Brushless 4CH Airplane-F4U in flight, showcasing its maneuverability and stability.

5.4 Flight Tips

• Outdoor Flying: Ideal for open outdoor spaces with minimal wind.
• Alarma de bateria baixa: The transmitter and receiver will beep when the aircraft battery is low.
• Over-Range Alarm: The transmitter and receiver will beep when the aircraft is at the edge of signal loss.
• Find My Aircraft: The aircraft beeps to show its location for easier search if it goes missing.

Image: Illustration of the low battery alarm feature, showing the remote control and a battery icon with a warning signal.

6. Manteniment

• Regularly check the propeller for damage and replace if necessary. The propeller saver design helps prevent damage during minor impacts.
• Inspect the landing gear for any bends or breaks.
• Keep the aircraft clean and free from dirt or debris.
• Store the aircraft and batteries in a cool, dry place away from direct sunlight.

Imatge: Primer pla view of the propeller saver mechanism, showing how the propeller detaches to prevent damage during impacts.

7. Solució De Problemes

• Aircraft not responding: Ensure both the remote control and aircraft batteries are charged and properly connected. Re-bind the remote control if necessary.
• Poor flight performance: Check for damaged propellers or control surfaces. Ensure the flight mode is appropriate for your skill level and wind conditions.
• Temps de vol curt: Ensure batteries are fully charged. Consider using fresh batteries or replacing old ones.

8. Especificacions

Image: The F4U Corsair RC plane with its product dimensions (19.69 x 3.94 x 15.75 inches) highlighted.

9. Garantia i Suport

Warranty information is not explicitly provided in the product details. For support, please refer to the contact information provided in the product packaging or visit the official VOLANTEXRC weblloc.
