Introducció
This manual provides essential information for the safe and efficient operation of your SOOPYK Self Cleaning Bottom Loading Water Cooler Dispenser. This appliance is designed to provide hot, cold, and room-temperature water from 3- or 5-gallon bottles.
Imatge: Frontal view of the SOOPYK water cooler dispenser with the bottom loading door open, showing a 5-gallon water bottle inside.
Informació de seguretat
Si us plau, llegiu atentament totes les instruccions abans d'utilitzar l'aparell per evitar lesions o danys. Conserveu aquest manual per a futures consultes.
- Assegureu-vos que l'aparell estigui col·locat sobre una superfície plana i estable.
- No feu servir l'aparell amb un cable o un endoll danyats.
- Keep children away from the hot water dispenser. The unit includes a child safety lock for the hot water spigot.
- No submergiu l'aparell, el cable o l'endoll en aigua o altres líquids.
- Desendolleu el dispensador abans de netejar-lo o fer-ne cap manteniment.
- Aquest aparell només és per a ús interior.
Característiques del producte
- Tres configuracions de temperatura: Provides hot, cold, and room-temperature water.
- Disseny de càrrega inferior: Accommodates 3- or 5-gallon water bottles without heavy lifting.
- Empty Bottle Alert: LED indicator notifies when the water bottle needs replacement.
- UV Self-Cleaning: Integrated UV light system helps maintain internal cleanliness and reduce contaminants.
- Stainless Steel Weld Tank: Construcció duradora per a un rendiment durador.
- Pany de seguretat infantil: Prevents accidental dispensing of hot water.
Configuració
- Desembalatge: Carefully remove the water cooler from its packaging. Place it upright on a flat, stable surface.
- Posicionament: Ensure there is adequate space around the unit for ventilation, typically at least 4 inches from walls.
- Instal·leu l'ampolla d'aigua: Open the bottom cabinet door. Slide a 3- or 5-gallon water bottle into the compartment. Ensure the water probe is securely inserted into the bottle. Close the cabinet door.
Image: Diagram illustrating the bottom loading process for a water bottle into the dispenser.
- Initial Priming: Before plugging in the unit, dispense water from all three spigots (hot, room, cold) until water flows steadily. This removes air from the tanks.
- Connexió d'alimentació: Connecteu el cable d'alimentació a una presa elèctrica amb connexió a terra.
- Activa la calefacció/refrigeració: Locate the switches on the back of the unit. The green switch controls the cold water function, and the red switch controls the hot water function. Turn them ON as desired.
Image: Close-up of the back panel of the water cooler, showing the green 'ON/OFF' switch for cold water and the red 'ON/OFF' switch for hot water.
- Wait for Temperature: Allow approximately 15-30 minutes for the water to reach optimal hot and cold temperatures.
Instruccions de funcionament
Distribució d'aigua
The dispenser offers three temperature options: hot, cold, and room temperature.
Image: Graphic showing three icons representing hot (red wavy lines), room (yellow bottle), and cold (blue snowflake) water temperatures.
- Aigua freda: Place your cup under the cold water spigot and press the corresponding button.
- Aigua a temperatura ambient: Place your cup under the room temperature water spigot and press the corresponding button.
- Aigua calenta: This spigot is equipped with a child safety lock. To dispense hot water, slide the safety lock mechanism while simultaneously pressing the hot water button.
Bloqueig de seguretat infantil
The child safety lock on the hot water spigot requires a two-step action to dispense hot water, preventing accidental burns.
Image: Close-up of the dispenser's control panel showing LED indicators for Hot, Empty, and Cold water, along with a detailed view of the child safety lock mechanism on the hot water button.
Empty Bottle Alert
The LED display includes an 'EMPTY' indicator light. This light will illuminate when the water bottle in the bottom compartment is low or empty, signaling that it needs to be replaced.
Manteniment
UV Self-Cleaning Feature
The water cooler is equipped with a UV self-cleaning system. The UV light operates continuously when the machine is plugged in, helping to prevent the growth of biofilm and other natural contaminants within the water tanks and lines. This automatic process minimizes maintenance requirements and contributes to improved water taste.
Image: Cutaway diagram of the water cooler, highlighting the internal UV-infused cleaning technology with purple light radiating within the water tank area.
Imatge: Primer pla intern view of the water cooler's tank, showing the UV light component circled in red.
Neteja general
- Exterior: Netegeu les superfícies exteriors amb un damp tela. No utilitzeu netejadors abrasius ni dissolvents.
- Safata de degoteig: La safata de degoteig s'ha de buidar i netejar regularment per evitar el desbordament i mantenir la higiene.
- Bobines del condensador: Periodically clean the condenser coils on the back of the unit with a soft brush or vacuum cleaner to ensure efficient operation.
Resolució de problemes
If you encounter any issues with your water cooler, please refer to the following common problems and solutions:
| Problema | Causa possible | Solució |
|---|---|---|
| No hi ha distribució d'aigua | Empty water bottle; airlock in system; pump malfunction. | Replace bottle; prime the system by dispensing from all spigots; contact support. |
| Aigua no prou calenta/freda | Hot/cold switch off; insufficient time to reach temperature; poor ventilation. | Ensure switches are ON; allow more time; check for proper ventilation around the unit. |
| Fuites d'aigua | Improperly seated water bottle; damaged bottle; loose connections. | Re-seat bottle; check bottle for cracks; inspect connections. |
| Empty Bottle Alert is on, but bottle is full | Sensor issue; bottle not properly seated. | Ensure bottle is correctly installed and probe is fully inserted. |
Si el problema persisteix després d'intentar aquestes solucions, poseu-vos en contacte amb l'atenció al client.
Especificacions
- Model: BY1185
- Color: Plata
- Material: Acer inoxidable
- Dimensions del producte: 13.8 "P x 12.2" W x 40.7" H
- Pes de l'article: 34 lliures
- Tipus d'instal·lació: Autònom
- Font d'alimentació: Elèctric amb cable
- Voltage: 115V~
- Freqüència nominal: 60 Hz
- Potència de calefacció: 500W
- Cooling Power/Current: 85W/0.8A
- Temperatura de l'aigua calenta: ≥90 °C (≥194 °F)
- Temperatura de l'aigua freda: ≤10°C (≤50°F)
- Temperatura ambiental: ST
- Refrigerant: R600a, 20 g
- Humitat relativa: ≤90%
- Protection of Anti-Electric-Shock: I
Image: Diagram illustrating the width (12.2 in), height (40.8 in), and depth (14.0 in) of the SOOPYK water cooler dispenser.
Garantia i suport
This SOOPYK water cooler dispenser is backed by a garantia d'un any from the date of purchase. Additionally, a 30-day return policy is in effect.
For any problems, questions, or concerns regarding your product, please contact SOOPYK customer support. Refer to your purchase documentation or the SOOPYK official weblloc per obtenir dades de contacte.
