1. Introducció
This manual provides essential information for the safe and efficient operation of your new Midea 1.7 Cu. Ft. 30-inch Over-the-Range Microwave, Model MMO17S3AST. Please read these instructions thoroughly before installation and use, and retain them for future reference.
2. Instruccions de seguretat importants
Per reduir el risc d'incendi, descàrrega elèctrica, lesions a persones o exposició a un excés d'energia de microones quan feu servir l'aparell, seguiu les precaucions bàsiques, com ara les següents:
- Llegiu totes les instruccions abans d'utilitzar l'aparell.
- Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found in this section.
- This appliance must be grounded. Connect only to properly grounded outlets. See "GROUNDING INSTRUCTIONS" in this manual.
- Instal·leu o localitzeu aquest aparell només d'acord amb les instruccions d'instal·lació proporcionades.
- No escalfeu ous sencers ni recipients tancats, ja que poden explotar.
- Maintain the appliance and its ventilation openings free from obstructions.
- No feu servir aquest aparell si té un cable o un endoll danyats, si no funciona correctament o si s'ha fet malbé o s'ha caigut.
- Only qualified service personnel should service this appliance. Contact an authorized service facility for examination, repair, or adjustment.
3. Contingut del paquet
Verifiqueu que tots els elements que s'enumeren a continuació siguin presents al vostre paquet:
- Midea Over-the-Range Microwave Unit
- Safata giratòria de vidre
- Anell de plat giratori
- Placa de muntatge
- Plantilla de gabinet superior
- Plantilla de paret
- Hardware Bag (screws, bolts, washers)
- Adaptador d’escapament
- Manual d'usuari
4. Instal·lació i configuració
4.1 Abans de començar
- Ensure the installation area has a dedicated 120V, 60Hz, 15 or 20 Amp presa de corrent elèctrica a terra.
- Confirm that the cabinet opening dimensions are suitable for a 30-inch over-the-range microwave.
- The microwave must be installed above a cooking surface.
4.2 Mounting the Microwave
Installation typically involves securing a mounting plate to the wall studs and then attaching the microwave to the plate and the upper cabinet. Detailed templates are provided to assist with drilling pilot holes for proper alignment. Professional installation is recommended for safety and optimal performance.
Image: Midea over-the-range microwave installed above a stovetop with pots, demonstrating its placement in a kitchen.
Imatge: Lateral view of the Midea over-the-range microwave installed, showing its sleek profile and integration with kitchen cabinetry.
5. Instruccions de funcionament
5.1 Tauler de control acabatview
The microwave features an intuitive touch control panel for easy operation. Refer to the image below for key control panel elements.
Imatge: Frontal view of the Midea over-the-range microwave, highlighting the control panel with digital display and various function buttons.
5.2 Funcionament bàsic del microones
- Col·loqueu el menjar en un recipient apte per a microones al plat giratori.
- Tanqueu la porta del microones amb seguretat.
- Introduïu el temps de cocció desitjat amb els teclats numèrics.
- Press the 'POWER LEVEL' button to adjust power if needed (default is 100%). Use number pads to select power level (1-10).
- Press 'START' to begin cooking.
- To stop cooking, press 'STOP/Clear'.
5.3 menús de cuina automàtica
The microwave includes 19 pre-programmed auto cook menus for common food items, simplifying cooking. Select the desired food category and quantity, then press 'START'.
Image: Close-up of the Midea microwave's control panel displaying various auto cook menu options like popcorn, potato, vegetables, and more.
5.4 Melt/Soften Functions
Utilize the dedicated 'MELT/SOFTEN' pad for precise melting or softening of ingredients. Press the button multiple times to cycle through options such as Melt Butter, Melt Chocolate, Soften Ice Cream, and Soften Cream Cheese.
Imatge: Detallada view of the Midea microwave's control panel, illustrating the Melt/Soften pad and its corresponding settings for butter, chocolate, ice cream, and cream cheese.
5.5 Fan and Light Operation
The microwave is equipped with a 2-speed 300 CFM fan to help remove smoke and odors from your cooking area, and LED cooktop lighting to illuminate your stovetop. Press the 'FAN' button to cycle through fan speeds (High, Low, Off) and the 'LIGHT' button to turn the cooktop light on or off.
Image: A Midea over-the-range microwave with its cooktop light illuminated, showing steam being drawn away by the fan from pots on the stovetop below.
6. Manteniment i Neteja
6.1 Neteja interior
The microwave interior features an Ez Clean Diamondback Coating for easy cleaning. Wipe the interior with a damp cloth and mild soap after each use. For stubborn stains, a microwave-safe cleaner can be used. Do not use abrasive cleaners or scouring pads.
6.2 Neteja exterior
Clean the stainless steel exterior with a soft cloth and a mild detergent or a stainless steel cleaner. Avoid harsh chemicals that may damage the finish.
6.3 Manteniment del filtre
The grease filters located on the underside of the microwave should be cleaned regularly (monthly or as needed) to maintain proper ventilation. Remove the filters, wash them in hot water with detergent, rinse thoroughly, and allow them to dry completely before reinstalling.
7. Solució De Problemes
Abans de contactar amb el servei d'atenció al client, review els següents problemes comuns i les seves solucions:
| Problema | Causa possible | Solució |
|---|---|---|
| El microones no s'engega | Door not closed properly; Power outage; Fuse blown/circuit breaker tripped. | Ensure door is latched; Check household fuse/circuit breaker; Contact an electrician if issue persists. |
| El menjar no s'escalfa uniformement | Food not stirred/rotated; Incorrect power level/cook time; Turntable not rotating. | Stir/rotate food during cooking; Adjust power/time; Ensure turntable is correctly placed and clean. |
| Excés de vapor dins del forn | Alt contingut d'humitat en els aliments. | This is normal for foods with high moisture. Ensure proper ventilation is maintained. |
| El ventilador no funciona | Fan setting is off; Obstruction in fan. | Press the 'FAN' button to turn on; Check for and remove any obstructions. |
8. Especificacions
Technical Data for Midea MMO17S3AST Microwave
| Característica | Valor |
|---|---|
| Marca | Midea |
| Número de model | MMO17S3AST |
| Capacitat | 1.7 peus cúbics |
| Tipus d'instal·lació | Abast de gamma |
| Wattage | 1000 watts |
| Voltage | 120 volts (CA) |
| Tipus de controlador | Toca |
| Entrada de la interfície humana | Pantalla tàctil |
| Pes de l'article | 50.6 lliures |
| Dimensions del producte | 33.4 x 19.6 x 20.6 polzades |
| Nombre de nivells de potència | 10 |
| Mètode de calefacció | Radiació de microones |
| Tipus de material interior | Acer inoxidable |
| Funció de descongelació | Descongelació automàtica |
| Velocitat del ventilador | 2-Speed (300 CFM) |
| Revestiment interior | Ez Clean Diamondback Coating |
| Il·luminació | Il·luminació LED de la placa de cuina |
| La tecnologia de sensors | Sensor d'humitat |
9. Garantia i Suport
9.1 Garantia del producte
Midea products are manufactured to high-quality standards and are warranted against defects in materials or workmanship. Specific warranty terms and duration may vary. Please refer to the warranty card included with your product or visit the official Midea weblloc per obtenir informació detallada sobre la garantia.
9.2 Atenció al client
For technical assistance, troubleshooting beyond this manual, or to inquire about service, please contact Midea customer support. You can find contact information on the official Midea website or by referring to the documentation included with your appliance. For more information about Midea products, visit the Botiga Midea.
