1. Introducció
Thank you for choosing the Ossuret Android 13 Car Radio. This manual provides essential information for the installation, operation, and maintenance of your new car radio. Please read it thoroughly before use to ensure proper functionality and safety.
This car radio is designed for Opel Corsa D models manufactured between 2007 and 2012. It features an 8-core processor, 4G+64G memory, a 9-inch QLED touchscreen, and supports advanced connectivity options like Apple CarPlay, Android Auto, Bluetooth, WiFi, and 4G LTE. It also includes an integrated DSP for enhanced audio quality and RDS for radio information.
2. Compatibilitat del vehicle
This car radio is specifically designed for the following vehicle model:
- Marca: Opel
- Model: Corsa d
- Anys: 2007, 2008, 2009, 2010, 2011, 2012
Nota important: Years are for reference only. Please confirm the center console of your vehicle matches the compatible designs shown below before installation.
Imatge: Examples of compatible and incompatible Opel Corsa D center console designs. The image shows three different car dashboards. The first two, with standard radio slots, are marked as compatible. The third, with a different display layout, is marked as incompatible. This helps users verify if their vehicle's dashboard matches the required configuration for installation.
3. Configuració i instal·lació
Professional installation is recommended for this car radio. Ensure the vehicle's battery is disconnected before beginning installation to prevent electrical damage.
3.1. Components inclosos
Verifiqueu que tots els components siguin presents al paquet:
- Main Head Unit (Car Radio)
- Cable USB
- RCA Wiring Harness
- Antena GPS
- Antena 4G
- Mounting Frame (if applicable)
3.2. Basic Installation Steps (General Guide)
- Eliminar la unitat antiga: Carefully remove the existing car radio and its surrounding trim from the dashboard.
- Connecteu el cablejat: Connect the provided wiring harness to the vehicle's existing wiring. Ensure all connections are secure.
- Connecteu les antenes: Connect the GPS antenna and 4G antenna to the designated ports on the new head unit. Position the antennas for optimal signal reception.
- Insert SIM Card (for 4G LTE): If using 4G LTE, insert your SIM card into the designated slot on the device before powering on the unit.
- Munta la nova unitat: Secure the new Ossuret car radio into the dashboard opening. Ensure it is properly seated and fastened.
- Torneu a connectar la bateria: Torneu a connectar la bateria del vehicle.
- Encesa inicial: Turn on the vehicle's ignition and power on the car radio. Follow any on-screen prompts for initial setup.
For detailed vehicle-specific installation instructions, consult a professional installer or refer to your vehicle's service manual.
4. Instruccions de funcionament
4.1. Encendre/apagar
The unit typically powers on with the vehicle's ignition. To manually power off or restart, press and hold the power button (location may vary, refer to the unit's physical layout).
4.2. Interfície de pantalla tàctil
The 9-inch QLED touchscreen provides a responsive interface for all functions. Navigate through menus and applications by tapping and swiping.
4.3. Apple CarPlay i Android Auto
This unit supports wireless Apple CarPlay and both wireless and wired Android Auto. Connect your smartphone via WiFi, Bluetooth, or USB cable to access phone functions directly on the car radio screen.
- Connexió sense fil: Enable Bluetooth and Wi-Fi on your smartphone. Pair your phone with the car radio via Bluetooth, then follow the on-screen prompts to establish the CarPlay/Android Auto connection.
- Wired Connection (Android Auto only): Connect your Android phone to the car radio's USB port using a high-quality USB cable.
Image: The car radio display showing the Apple CarPlay and Android Auto interfaces, with icons for phone, music, maps, and podcasts. A smartphone is shown next to the display, illustrating wireless connectivity. This image demonstrates how smartphone integration works.
4.4. Navegació GPS
The integrated GPS module allows for online navigation. Ensure the GPS antenna is properly installed for accurate positioning. You can use pre-installed navigation apps or download others from the Google Play Store.
4.5. 4G LTE & WiFi Connectivity
The unit supports 4G LTE network connectivity via a SIM card (insert before powering on) and has an integrated WiFi module. Connect to the internet for online navigation, streaming music, and other online services.
4.6. DSP (Digital Sound Processor)
The built-in DSP (BU32107EFV) allows you to adjust sound effects and reduce car noise for an improved audio experience. Access DSP settings through the audio menu on the touchscreen.
Image: The car radio display showing the Digital Sound Processor (DSP) interface with an equalizer and sound field settings. This illustrates the audio customization options available to the user.
4.7. Funció de pantalla dividida
Utilitzeu la funció de pantalla dividida per executar dues aplicacions simultàniament, com ara la navegació i la reproducció de música.
Image: The car radio display in split-screen mode, showing a navigation map on one side and a music player on the other. This demonstrates the multitasking capability of the unit.
4.8. Imatge dins d'imatge (PIP)
The Picture-in-Picture function allows you to watch video in a small, resizable window while using other applications.
Image: The car radio display showing a video playing in a small, adjustable window (Picture-in-Picture mode) while another application is active in the background. This highlights the video playback flexibility.
4.9. Control del volant
The unit supports steering wheel controls, allowing you to manage music, volume, and other functions safely without distraction. Configuration may be required in the system settings.
4.10. Mode dia i nit
The system includes a day and night mode that automatically or manually adjusts screen brightness and color schemes for optimal visibility in varying light conditions.
Image: A split-screen comparison showing the car radio interface in day mode (bright background) and night mode (dark background), demonstrating how the display adapts for different lighting conditions.
5. Especificacions
| Propietat | Detall |
|---|---|
| Marca | Ossuret |
| Nom del model | Autoradio for OPEL Corsa D (2007-2012) |
| Sistema operatiu | Android 13 |
| Processador | 8-Core (Octa Core 1.8GHz*8) |
| Memòria (RAM + ROM) | 4 GB de RAM + 64 GB d'emmagatzematge |
| Mida de la pantalla | 9 polzades |
| Tipus de pantalla | Pantalla tàctil QLED |
| Resolució | 1280*720 |
| Connectivitat | Bluetooth, USB, WiFi, 4G LTE |
| Característiques especials | Apple CarPlay (Wireless), Android Auto (Wireless & Wired), Built-in DSP (BU32107EFV), Day and Night Mode, GPS Navigation, RDS (AM/FM Radio) |
| Dispositius compatibles | Smartphone |
| Mode de sortida d'àudio | estèreo |
| Components inclosos | USB Cable, RCA Wiring Harness, GPS Antenna, 4G Antenna |
| Dimensions del producte | 41.79 x 30.6 x 13.1 cm |
| Pes del producte | 2 kg |
6. Manteniment
6.1. Neteja de pantalles
Feu servir un drap suau i sense borrissol per netejar suaument la pantalla tàctil. Per a taques difícils, fregueu lleugeramentampNetegeu el drap amb aigua o un netejador de pantalles. Eviteu productes químics agressius o materials abrasius.
6.2. Actualitzacions de programari
Periodically check for software updates through the system settings. Updates can improve performance, add new features, and enhance security. Ensure a stable internet connection during updates.
6.3. Atenció general
Avoid exposing the unit to extreme temperatures, direct sunlight for prolonged periods, or excessive moisture. Ensure proper ventilation around the unit.
7. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| La unitat no s'encén. | Connexió d'alimentació fluixa, fusible fundit, problema amb la bateria del vehicle. | Check all power connections. Inspect vehicle fuses. Ensure vehicle battery is charged. Consult a professional installer. |
| Sense so. | Volum massa baix, font d'àudio incorrecta, cables d'altaveu solts. | Increase volume. Select correct audio source. Check speaker wire connections. |
| El senyal GPS és feble o inexacte. | GPS antenna improperly placed or disconnected. | Ensure GPS antenna is securely connected and placed in an area with clear sky view. |
| El CarPlay/Android Auto no es connecta. | Bluetooth/WiFi off, incorrect pairing, faulty USB cable, phone software issue. | Ensure Bluetooth and WiFi are enabled on phone and unit. Re-pair devices. Try a different USB cable. Restart phone and unit. |
| La pantalla tàctil no respon. | Error temporal de programari, danys a la pantalla. | Restart the unit. If issue persists, contact customer support. |
| 4G LTE not working. | SIM card not inserted correctly, no signal, data plan issue. | Ensure SIM card is correctly inserted (before power on). Check for 4G signal strength. Verify data plan with your provider. |
8. Garantia i Suport
Ossuret products are designed for quality and reliability. For warranty information, please refer to the warranty card included with your product or visit the official Ossuret weblloc.
If you encounter any issues not covered in this manual or require technical assistance, please contact Ossuret customer support:
- Weblloc: www.ossuret.com (placeholder, actual URL no proporcionat)
- Correu electrònic: support@ossuret.com (placeholder, actual email not provided)
- Telèfon: Refer to your regional Ossuret support contact information.
Please have your product model and purchase details ready when contacting support.
