1. Introducció
Thank you for choosing the Raddy PT-5 TN Wireless Pool Thermometer. This device provides accurate water temperature readings for your pool, spa, or pond, along with indoor temperature and humidity monitoring. Its dual power options and robust waterproof design ensure reliable performance. Please read this manual thoroughly before use to ensure proper setup and operation.
2. Què hi ha a la caixa
En desembalar-lo, comproveu que tots els components que s'enumeren a continuació hi són presents i en bon estat:
- PT-5 Pool Thermometer (Floating Unit)
- Display Console (Indoor Unit)
- Cable de càrrega USB-C
- Manual d'usuari
Figure 2.1: Package Contents of the Raddy PT-5 TN Thermometer.
3. Característiques
- Versatile Digital Display: Intuitive indoor screen showing outdoor water temperature, indoor temperature, and humidity. Includes low battery indicator and one-touch °C/°F switching. Note: The pool thermometer displays temperature in °F only.
- Opcions d'alimentació dual: The floating pool thermometer features a built-in 1200mAh rechargeable lithium battery, supporting both solar and USB-C charging for continuous, low-maintenance operation.
- IPX8 Impermeable: Engineered with dual sealing rings and integrated molding for true waterproof performance, suitable for full submersion.
- Comoditat sense fil: Reliable long-range wireless sensor transmits data up to 300ft (91 meters) in open areas to the indoor display.
- Multi-Scene Compatibility: Ideal for swimming pools, hot tubs, spas, aquariums, ice baths, thermal baths, koi ponds, and garden ponds.
Figure 3.1: IPX8 Waterproof Design of the Floating Unit.
Figure 3.2: Wireless Transmission Range.
4. Configuració
- Desempaquetar components: Traieu amb cura tots els articles de l'embalatge.
- Install Batteries in Display Console: The indoor display console requires 2 x LR03 size AAA batteries (not included). Open the battery compartment on the back of the unit and insert the batteries, observing correct polarity.
- Charge Floating Unit: The floating thermometer has a built-in 1200mAh rechargeable lithium battery. For initial use, it is recommended to fully charge the unit via the provided USB-C charging cable. The USB-C port is located under a waterproof rubber plug. Alternatively, place the unit in direct sunlight for several hours to utilize solar charging.
- Pairing (Automatic): The floating unit and display console are designed to pair automatically once both are powered on. Ensure both units are within range.
- Placement of Floating Unit: Place the floating thermometer in your pool, spa, or pond. To prevent it from floating away or entering a skimmer, you can use the included string to tether it to a fixed object, such as a rock or pool ladder.
- Placement of Display Console: Position the display console indoors in a location where you can easily view the readings. Ensure it is within the wireless transmission range of the floating unit.
Figure 4.1: Raddy PT-5 TN Floating Thermometer and Display Console.
5. Instruccions de funcionament
5.1. Funcions de la consola de visualització
- Visualització de l'hora: The console shows the current time in either 12-hour or 24-hour format.
- Temperatura i humitat interiors: Displays the ambient temperature and humidity of the indoor environment.
- Outdoor Water Temperature: Shows the temperature of the water from the floating unit. Note: The floating unit measures temperature in °F only.
- °C/°F Switching: Use the dedicated button on the display console to switch between Celsius and Fahrenheit for indoor temperature readings.
- Il·luminació de fons: Tap the top of the display console to activate the backlight for improved visibility in low light conditions.
- Despertador i funció de repetició: The console includes an alarm clock function with a snooze feature. Be mindful that accidentally touching the sensor on the top edge can toggle the alarm.
- Indicador de bateria baixa: An icon on the display will indicate when the batteries in either unit are low.
Figure 5.1: Display Console with Alarm Clock and Snooze Function.
5.2. Floating Unit Operation
- Encès/apagat: Press and hold the power button on the floating unit for approximately 3 seconds to turn it on or off.
- Lectura de temperatura: The floating unit will display the water temperature directly on its small screen. This reading is transmitted wirelessly to the indoor display console.
Figure 5.2: Multi-Scene Compatibility.
6. Manteniment
- Neteja: Regularly wipe both units with a soft, damp drap. Eviteu productes de neteja o dissolvents abrasius.
- Segell impermeable: Ensure the USB-C charging port's rubber plug on the floating unit is securely closed when not charging to maintain its IPX8 waterproof rating.
- Battery Replacement (Display Console): Replace the AAA batteries in the display console when the low battery indicator appears.
- Charging (Floating Unit): Keep the solar panel clean for efficient charging. If prolonged cloudy weather occurs, use the USB-C cable to charge the unit.
- Emmagatzematge: During off-season or prolonged non-use, store both units in a cool, dry place away from direct sunlight and extreme temperatures.
7. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| No reading on display console | Units out of range, low batteries, or pairing issue. | Move units closer, replace/charge batteries, or power cycle both units to re-establish connection. |
| Lectura de temperatura inexacta | Floating unit not fully submerged or placed in an area with inconsistent temperature (e.g., direct sunlight on sensor). | Ensure floating unit is fully submerged and away from direct heat sources. Allow time for temperature stabilization. |
| Alarm sounds unexpectedly | Accidental activation of alarm function on display console. | Refer to the user manual for specific instructions on disabling or setting the alarm. Avoid prolonged contact with the touch-sensitive area. |
| Floating unit not charging via solar | Insufficient sunlight or dirty solar panel. | Ensure the solar panel is clean and exposed to direct sunlight. Use the USB-C cable for charging if sunlight is consistently low. |
8. Especificacions
- Nom del model: PT5-TN
- Floating Unit Power: Built-in 1200mAh rechargeable lithium battery (Solar & USB-C charging)
- Display Console Power: 2 x LR03 size AAA batteries (not included)
- Waterproof Rating (Floating Unit): IPX8
- Freqüència de transmissió sense fil: RF de 433.92 MHz
- Interval de transmissió sense fil: Up to 300ft (91 meters) in open areas
- Temperature Measurement Range (Outdoor): -40 °C (-40 °F) a 70 °C (158 °F)
- Temperature Measurement Range (Indoor): -9.9 °C (14.2 °F) a 50 °C (122 °F)
- Humidity Range (Indoor): 20% de HR a 95% de HR
- Tipus de visualització: Digital
- Color: Green (Floating Unit), White (Display Console)
- Material: Plàstic
9. Garantia i Suport
Specific warranty details and direct customer support contact information were not provided in the product data. Please refer to the packaging or the manufacturer's official website for the most up-to-date warranty policy and support channels.
