1. Introducció
Thank you for choosing the Gritin G1328 Rechargeable Neck Reading Light. This device is designed to provide comfortable, hands-free illumination for various activities such as reading, crafting, or repairing. Please read this manual carefully before use to ensure proper operation and to maximize the product's lifespan.
2. Instruccions de seguretat
- No desmunteu, repareu o modifiqueu el producte.
- Keep away from water, fire, and high temperatures.
- Do not look directly into the light source to avoid eye strain.
- Use the provided USB-C cable for charging. Do not use damaged cables or chargers.
- Mantenir fora de l'abast dels nens.
3. Contingut del paquet
- Gritin G1328 Neck Reading Light
- Cable de càrrega USB-C (1 metre)
- Manual d'usuari
4. Producte acabatview
The Gritin G1328 features a flexible, ergonomic design with adjustable light heads and intuitive controls.
Imatge 4.1: Acabatview of the Gritin G1328 Neck Reading Light. The image displays the light in its U-shaped configuration, highlighting the flexible arms and the control panel located on the neckband. The light sources are at the ends of the arms.
Components:
- Braços flexibles: Bendable arms allow for precise light positioning.
- Capçals de llum LED: Located at the end of each arm, providing illumination.
- Botó d'encesa: Controls power on/off and timer function.
- Botó d'ajust de brillantor: Ajusta la intensitat de la llum.
- Botó de temperatura de color: Changes light color mode.
- Port de càrrega USB-C: Per recarregar la bateria interna.
- Indicadors d'alimentació: Four LEDs indicating battery level.
5. Configuració
5.1 Càrrega inicial
- Connect the provided USB-C cable to the charging port on the neck light.
- Connecteu l'altre extrem del cable a un adaptador de corrent USB (no inclòs) o al port USB d'un ordinador.
- The power indicator lights will illuminate to show charging status. All four lights will be solid when fully charged.
- Una càrrega completa sol trigar entre 2 i 3 hores.
5.2 Wearing the Light
Place the neck light around your neck with the light heads positioned in front of you. The ergonomic design ensures a comfortable fit.
Imatge 5.1: A person wearing the Gritin G1328 Neck Reading Light while reading a book. The light is comfortably draped around the neck, with the flexible arms bent to direct light onto the book, illustrating hands-free operation.
Adjust the flexible arms to direct the light precisely where needed. The arms can be bent and twisted to achieve optimal illumination angles.
Imatge 5.2: Un primer pla view of the flexible arms of the Gritin G1328 Neck Reading Light. The image demonstrates the bendable nature of the arms, allowing users to adjust the light direction as needed for various tasks.
6. Instruccions de funcionament
6.1 Encès/Apagat
- Premeu el botó Botó d'engegada (⑂) once to turn the light on.
- Premeu el botó Botó d'engegada (⑂) again to turn the light off.
6.2 Ajust de la brillantor
The light offers two dimming modes: 5-level dimming and stepless dimming.
- Regulació de 5 nivells: Premeu breument Botó d'ajust de brillantor (☰) to cycle through 5 preset brightness levels (10%, 25%, 50%, 75%, 100%).
- Atenuació continuada: Premeu llargament el botó Botó d'ajust de brillantor (☰) to smoothly adjust the brightness from 0% to 100%. Release the button when the desired brightness is reached.
Imatge 6.1: An instructional graphic detailing the brightness adjustment features of the Gritin G1328. It shows five distinct brightness levels (10% to 100%) activated by short presses, and a continuous dimming range (0% to 100%) achieved by a long press of the brightness button.
6.3 Canvi de la temperatura de color
The light offers 4 color temperature options:
- Amber Light (2000K): Ideal for reducing blue light exposure, promoting better sleep.
- Blanc càlid (3000K): A cozy, inviting light for general reading.
- Natural White (4500K): A balanced light, suitable for various tasks.
- White (6000K): Bright, clear light for detailed work.
Premeu breument Botó de temperatura de color (☀) to cycle through the 4 color modes.
Imatge 6.2: An illustration demonstrating the four available color temperatures of the Gritin G1328 Neck Reading Light: Amber (1800K), Warm Light (3000K), Natural Light (4500K), and Cold Light (6000K). Each color is shown illuminating a book, with the color temperature switching button highlighted.
6.4 30-Minute Smart Timer
The light includes a 30-minute auto shut-off timer.
- To activate the timer, long press the Botó d'engegada (⑂) while the light is on.
- A green indicator light will illuminate to confirm the timer is active.
- The light will automatically turn off after 30 minutes.
Imatge 6.3: A person relaxing on a couch, using the Gritin G1328 Neck Reading Light. An inset graphic highlights the power button and a green indicator light, signifying that the 30-minute smart timer function is active.
6.5 Funció de memòria
The light features a memory function that automatically recalls your last used brightness and color temperature settings when turned back on.
7. Manteniment
7.1 Neteja
Netegeu el dispositiu amb un drap suau i sec. No utilitzeu productes de neteja abrasius ni submergiu el dispositiu en aigua.
7.2 Emmagatzematge
Store the light in a cool, dry place away from direct sunlight when not in use for extended periods.
7.3 Cura de la bateria
To prolong battery life, charge the device at least once every three months if not used regularly.
8. Solució De Problemes
| Problema | Causa possible | Solució |
|---|---|---|
| La llum no s’encén. | La bateria està esgotada. | Carregueu el dispositiu amb el cable USB-C. |
| La llum parpelleja o és tènue. | Bateria baixa. | Recarrega el dispositiu. |
| Cannot change brightness/color. | Botons no premuts correctament. | Ensure a firm press. Refer to operating instructions for short/long press functions. |
| Timer not activating. | El botó d'engegada no s'ha premut durant molt de temps. | Long press the power button for 3 seconds to activate the timer. |
9. Especificacions
Imatge 9.1: A visual representation of the Gritin G1328 Neck Reading Light's dimensions (13.3cm/5.23in depth, 22cm/8.66in width) and weight (122g/4.3oz), illustrating its compact and lightweight design.
| Característica | Detall |
|---|---|
| Número de model | G1328 |
| Dimensions | 8.66" de profunditat x 5.23" d'amplada x 0.87" d'alçada (22 x 13.3 x 2.2 cm) |
| Pes de l'article | 4.3 unces (122 g) |
| Lamp Tipus | LED |
| Tipus de font de llum | LED |
| Temperatures de color | Amber (2000K), Warm White (3000K), Natural White (4500K), White (6000K) |
| Nivells de brillantor | 5 preset levels (10%-100%), Stepless dimming (0%-100%) |
| Capacitat de la bateria | Polímer de liti de 1000 mAh |
| Port de càrrega | USB-C |
| Temps de càrrega | 2-3 hores |
| Temps d'execució | 80+ hours (at lowest brightness setting) |
| Característiques especials | Dimmable, Eye-caring, Rechargeable, Hands-free, Lightweight, Comfortable, 30-min Timer, Memory Function |
| Material | Acrilonitril butadiè estirè, silicona |
Imatge 9.2: An infographic highlighting key specifications of the Gritin G1328 Neck Reading Light, including its 1000mAh battery capacity, USB-C charging capability, and an impressive 80+ hours of runtime on a single charge.
10. Garantia i Suport
Gritin products are designed and manufactured to high-quality standards. For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official Gritin weblloc.
Weblloc: Gritin Official Store
