Introducció
This manual provides detailed instructions for the installation, operation, and maintenance of your DEWENWILS PTW04 Outdoor WiFi Pool Pump Timer. This heavy-duty timer box is designed for controlling pool pumps, water heaters, and other high-power outdoor appliances, offering versatile scheduling and smart control capabilities.
Característiques clau
- Versatile Timer Modes: Offers programmable, countdown, random, and astronomical modes to optimize energy usage.
- Remote & Voice Control: Compatible with DEWENWILS and Smart Life apps, Alexa, and Google Assistant for convenient control.
- Cablejat fàcil: Simplified wiring system with an intuitive rotary dial interface for straightforward installation.
- Heavy-Duty & Weatherproof: Rated for 40A, 3HP, 240VAC operation, with flame-retardant PC housing and IP44 waterproof rating for outdoor durability. Operates reliably from -40°F to 140°F.
- Àmplia compatibilitat: Ideal for water heaters, filters, spas, irrigation systems, and landscape lighting. ETL certified for safety.
Informació de seguretat
ADVERTIMENT: Risk of Electric Shock. If wiring compartment insulator is not installed properly, inform the electrician if it is missing.
PRECAUCIÓ: Before wiring and servicing, power to this time switch and the equipment it controls must be turned off at the main panel. Replace this insulator after wiring.
TYPE 3R RAINTIGHT ENCLOSURE: Grounding between metallic conduit is not provided by this enclosure. Grounding type bushings and jumper wire to control unit must be installed in accordance with the National Code Requirements.
- Not for Water Immersion.
- For supply connections, use copper wire AWG 8-18 suitable for 90°C (194°F).
- Use listed wiring connector for grounding terminals.
- Tanqueu sempre la porta després de l'ús.
Contingut del paquet
Upon unboxing your DEWENWILS Pool Pump Timer, please ensure all the following items are present:
- DEWENWILS Outdoor WiFi Pool Pump Timer Box (Model PTW04)
- Manual d'instruccions
- Maquinari de muntatge (cargols, ancoratges)
- Jumper wires (if applicable for specific wiring configurations)
- Waterproof wire connectors/grommets
Configuració i instal·lació
1. Mounting the Timer Box
The timer box is designed for outdoor use and can be mounted on a wall or post near your pool equipment. Ensure the mounting location is secure and allows for proper wiring access.
Image: The DEWENWILS Outdoor WiFi Pool Pump Timer box, gray in color, is shown mounted on an exterior wall next to a swimming pool. It highlights its high power capabilities (40A, 3HP, 240VAC) and ETL listing, indicating its suitability for heavy-duty outdoor appliances.
2. Instruccions de cablejat
IMPORTANT: All wiring should be performed by a qualified electrician with the power turned off at the main panel to prevent electric shock. Refer to the wiring diagrams provided inside the timer box lid and in the instruction manual for specific configurations.
Imatge: Un primer pla view of the DEWENWILS Pool Pump Timer's internal wiring compartment. It shows clearly labeled terminals for Load1, Line1, Load2, and Line2, along with a simplified wiring design to connect a single 240VAC load. This image emphasizes the ease of wiring and installation.
The timer features an innovative wiring design that simplifies the installation process compared to traditional timer boxes. Ensure all connections are secure and waterproofed using the provided connectors.
Image: A clear wiring diagram illustrating how to connect a single 240VAC load to the DEWENWILS Pool Pump Timer. It shows connections for Power L1, Load L1, Load L2, and Power L2, indicating a straightforward setup for one appliance.
Image: A wiring diagram demonstrating how to connect a hot water heater to the DEWENWILS Pool Pump Timer. It details the 120VAC connections for the hot water tank and the 240VAC (Dual Phase) connections from the circuit breaker box to the timer's load and line terminals.
3. Descàrrega i configuració de l'aplicació
Download the DEWENWILS or Smart Life app from your smartphone's app store. Create an account and follow the in-app instructions to add your device.
Imatge: Un obert view of the DEWENWILS Pool Pump Timer, highlighting its internal components. Labels point to the Wi-Fi antenna, power indicator, power & programming load indicator, Wi-Fi indicator, IP44 weatherproof rating, knockouts, and terminal blocks, providing a clear overview de les característiques del dispositiu.
Scan the QR code on the timer box lid or in the manual to quickly find the app. Ensure your smartphone is connected to a 2.4GHz Wi-Fi network (5GHz networks are not supported).
For a visual guide on app setup, please refer to the video below:
Video: This video provides a step-by-step guide on how to set up the DEWENWILS Digital Pool Pump Timer using the companion app. It covers the initial pairing process and basic scheduling functions.
4. Reinicialització del dispositiu
If you encounter issues during pairing or need to reset the device, locate the reset button inside the timer box. Use a non-conductive tool (like a toothpick) to press and hold the reset button for 5 seconds until the Wi-Fi indicator light blinks rapidly.
For a visual guide on resetting the device, please refer to the video below:
Video: This video demonstrates the reset steps for the DEWENWILS Smart Box. It shows how to locate and press the reset button to initiate the pairing mode or clear existing settings.
Instruccions de funcionament
1. Control manual
The timer box features a manual ON/OFF button for direct control of the connected appliance without using the app. Press the button once to toggle the power state.
2. Control d'aplicacions
Once paired with the DEWENWILS or Smart Life app, you can control your pool pump timer from anywhere with an internet connection. The app allows you to:
- Turn the device ON/OFF remotely.
- Set up various timer modes: programmable schedules, countdowns, random operation, and astronomical timing (sunrise/sunset).
- Monitor the device status.
Image: A smartphone screen displays the DEWENWILS app interface for scheduling and controlling the pool pump timer. Below, a couple is shown interacting with a Google Assistant device, demonstrating voice control capabilities. This image highlights the convenience of remote and voice control.
Image: This image illustrates various scheduling possibilities for pool equipment using the DEWENWILS Digital Pool Timer. Examples include turning the pool pump on at 10 AM, an outdoor spa off at 4 PM, and landscape lights on at 6 PM, showcasing the timer's automation capabilities.
3. Control per veu
Integrate your DEWENWILS timer with Amazon Alexa or Google Assistant for hands-free control. Once linked, you can use simple voice commands to turn your connected appliances on or off.
Image: A woman is shown in a modern outdoor setting, using voice commands to control her pool timer with an Alexa device. The text emphasizes the ease of using simple voice commands with Alexa and Google Assistant to manage connected devices.
Manteniment
The DEWENWILS PTW04 timer is designed for minimal maintenance due to its durable and weatherproof construction.
- Inspecció periòdica: Periodically check the timer box for any signs of damage, wear, or loose connections.
- Neteja: Netegeu l'exterior amb anunciamp drap segons calgui. No utilitzeu productes químics agressius.
- Protecció meteorològica: The IP44 rating ensures protection against splashing water and solid objects larger than 1mm. The flame-retardant PC housing is built to withstand temperatures from -40°F to 140°F.
Image: The DEWENWILS Pool Pump Timer is depicted in a split image, showing its resilience in both cold (-40°F) and hot (140°F) weather conditions. Icons highlight its IP44 waterproof rating, ETL listing, sturdy plastic box construction, and wide temperature operating range, emphasizing its weatherproof and heavy-duty design.
Resolució de problemes
- El dispositiu no es connecta a la Wi-Fi: Ensure your router is 2.4GHz. Reset the device and attempt pairing again. Check Wi-Fi signal strength at the timer's location.
- Problemes de control d'aplicacions: Verify your smartphone has an active internet connection. Ensure the app is updated to the latest version.
- El temporitzador no respon: Check the power indicator light on the device. Ensure the main power switch is ON. Try manual control to verify device functionality.
- Scheduling errors: Double-check your schedule settings in the app for correct times and days.
Especificacions
| Característica | Especificació |
|---|---|
| Número de model | PTW04 |
| Dimensions del producte | 4 x 6 x 7 polzades (4" de profunditat x 6" d'amplada x 7" d'alçada) |
| Pes de l'article | 1.83 lliures |
| Material | Policarbonat |
| Entrada Voltage | 240 VCA |
| Valoració actual | 40A |
| Potència (HP) | 3 CV |
| Compatibilitat Wi-Fi | Només 2.4 GHz |
| Classificació resistent a la intempèrie | IP44 |
| Temperatura de funcionament | -40 °F a 140 °F |
| Certificacions | Llistat per ETL |
Garantia i Suport
The DEWENWILS PTW04 Pool Pump Timer is ETL certified, ensuring it meets rigorous safety and performance standards. For warranty claims, technical support, or any product-related inquiries, please refer to the contact information provided in your product packaging or visit the official DEWENWILS weblloc.
For app-related support, you can also visit the Smart Life app's help section or their official support channels. The app can be downloaded from https://a.smart321.com/dewenwilssmartiot.
