ANRAN Q03-800 Million 8MP 4K Outdoor Solar Security Camera User Manual

1. Introducció

This manual provides detailed instructions for the installation, operation, and maintenance of your ANRAN Q03-800 Million 8MP 4K Outdoor Solar Security Camera. Please read this manual thoroughly before use to ensure proper functionality and to maximize the product's lifespan. This camera features 8-megapixel resolution, 4K equivalent video quality, 360-degree monitoring, PIR human detection, and solar charging capabilities.

2. Informació de seguretat

• Assegureu-vos que la càmera estigui instal·lada en un lloc estable per evitar que caigui.
• No exposeu la càmera a temperatures extremes fora del seu rang de funcionament (de -10 °C a 50 °C).
• Keep the camera away from strong magnetic fields or corrosive substances.
• No intenteu desmuntar ni modificar la càmera, ja que això anul·larà la garantia.
• Use only the provided accessories and power cables.

3. Contingut del paquet

Marqueu la casella per als elements següents:

• 1 x unitat de càmera
• 1 x Panell solar
• 1 x manual d'instruccions
• 1 x cable de càrrega tipus C
• 2 x Position Decal
• 7 x cargols

Image: All components included in the ANRAN Q03-800 Million package.

4. Configuració

4.1 Càrrega inicial

Upon arrival, fully charge the camera using a 5V1A charging cable before first use. This ensures optimal battery performance.

4.2 Muntatge de la càmera i del panell solar

The camera and solar panel are designed for easy, wire-free installation. The solar panel is detachable and adjustable up to 90 degrees, allowing you to position the camera in a shaded area while placing the solar panel in a location with ampla llum solar per a una càrrega eficient.

Image: A person easily mounting the ANRAN Q03-800 Million camera to a wall.

Image: The ANRAN Q03-800 Million camera and solar panel installed outdoors, demonstrating its IP66 waterproof rating and temperature resilience.

4.3 Instal·lació i connexió de l'aplicació

Download the dedicated app to your iOS or Android smartphone. The camera supports Bluetooth one-touch search for quick and easy connection to your 2.4GHz WiFi network. For optimal performance, install the camera within 10-15 meters of your router in a good network environment.

5. Funcionament

5.1 Video Quality and PTZ Control

The camera features an 8-megapixel CMOS sensor, providing 4K equivalent ultra-high definition video (4096x2160). This allows for clear identification of details such as faces and vehicle brands. The PTZ (Pan-Tilt-Zoom) function enables 355° pan and 90° tilt, providing 360-degree monitoring without blind spots.

Image: Close-up of the camera lens and a comparison of 4K image clarity, highlighting the detail captured.

5.2 PIR Human Detection and Alarm

Equipped with a PIR thermal sensor, the camera quickly detects human body temperature and movement. Upon detection, it automatically starts recording and sends real-time notifications to your smartphone. The camera also features a sound alarm and sensor light that activate simultaneously to deter intruders. You can set precise detection areas to minimize false alarms from non-threatening movements like passing vehicles.

Image: A person at a door interacting with someone through the camera's two-way audio feature, demonstrating AI human detection.

5.3 Modes de visió nocturna

The camera offers three night vision modes: Alarm, Full Color, and Infrared. These can be easily switched via the smartphone app. For residential areas, the infrared mode can be used to avoid disturbing neighbors with light or sound, providing quiet security.

Image: The camera's night vision capabilities, showing both infrared (black and white) and full-color night vision examples.

5.4 Two-Way Audio and Family Sharing

With a built-in microphone and speaker, the camera supports real-time two-way audio communication via the app. This allows you to speak with delivery personnel or visitors from anywhere. The camera also supports family sharing, allowing multiple users to view and operate the live feed simultaneously.

Image: Illustration of family members sharing access to the camera feed and the ability to monitor multiple cameras on a single screen.

5.5 Enregistrament i emmagatzematge

Recordings can be saved to a MicroSD card (up to 128GB, sold separately) or to the paid cloud storage service. Motion events are automatically overwritten, and recordings can be downloaded from the app. Note that 24-hour continuous recording is not supported.

Image: A family enjoying their yard, with a timeline below showing various recorded events, illustrating the camera's ability to capture and store important moments.

6. Manteniment

The ANRAN Q03-800 Million camera has an IP66 waterproof and dustproof rating, making it resilient against rain, wind, and dust. This ensures reliable operation in various outdoor weather conditions.

6.1 Neteja

Per mantenir un rendiment òptim, netegeu periòdicament la lent de la càmera i el panell solar amb un drap suau i sec.amp drap. Eviteu utilitzar productes de neteja abrasius o dissolvents que puguin danyar les superfícies.

6.2 Interval de temperatura

The camera is designed to operate within a temperature range of -10°C to 50°C. Ensure it is not exposed to temperatures outside this range for extended periods.

7. Solució De Problemes

• Sense energia: Ensure the camera is fully charged. Check the solar panel's position to ensure it receives adequate sunlight.
• Problemes de connexió: Verify your WiFi network is 2.4GHz. Ensure the camera is within the recommended range of your router (10-15m). Restart your router and the camera.
• Mala qualitat d'imatge: Netegeu la lent de la càmera. Assegureu-vos que no hi hagi obstruccions en el camp de visió de la càmera. view.
• Falses alarmes: Adjust the detection area settings in the app to exclude unnecessary movements.
• Sense gravació: Check if the MicroSD card is inserted correctly and has sufficient storage. Verify cloud storage subscription status if applicable.

If you encounter any issues not covered here, please contact customer support.

8. Especificacions

9. Garantia i Suport

ANRAN is committed to providing high-quality products. This product comes with a 2 any de garantia de qualitat. Our products have obtained Japanese PSE certification and technical compliance certification, ensuring safe use.

If you have any questions during consideration or use, or if you encounter any malfunctions, please feel free to contact us:

• Horari d'atenció telefònica: Monday - Friday, 10:00 - 13:00 and 14:30 - 19:30 (Japan Time)
• Suport per correu electrònic: 24-hour response
