VEVOR 1800W 2-in-1 Electric Hot Pot and Grill Instruction Manual

1. Introducció

Thank you for choosing the VEVOR 1800W 2-in-1 Electric Hot Pot and Grill. This versatile appliance is designed to provide a convenient and enjoyable cooking experience, combining the functions of a hot pot and a grill in a single unit. With its powerful 1800W heating element, dual temperature controls, and non-stick surface, it is ideal for family dining and gatherings of 2-8 people. Please read this manual thoroughly before use to ensure safe and optimal operation.

2. Instruccions de seguretat

To prevent personal injury or property damage, always follow basic safety precautions when using electrical appliances. Keep this manual for future reference.

• Llegeix totes les instruccions: Familiarize yourself with the appliance's features and operation before first use.
• Seguretat elèctrica: Assegureu-vos que el voltage rating on the appliance matches your local power supply. Do not use with damaged cords or plugs. Always plug into a grounded outlet.
• Eviteu el contacte amb l'aigua: Do not immerse the appliance, cord, or plug in water or other liquids. Keep electrical components dry.
• Superfícies calentes: Surfaces become hot during use. Use oven mitts or handles when moving or touching hot parts. Allow to cool completely before cleaning or storing.
• Nens i animals de companyia: Keep the appliance out of reach of children and pets. Close supervision is necessary when used near children.
• Ventilació adequada: Use in a well-ventilated area to prevent smoke accumulation, especially when grilling.
• Superfície estable: Place the appliance on a stable, heat-resistant surface away from flammable materials.
• Desconnecteu quan no estigui en ús: Always unplug the appliance from the outlet when not in use, before cleaning, and before adding or removing parts.
• No ompliu en excés: Do not exceed the maximum fill line for the hot pot section to prevent boiling over.
• Utilitzeu només accessoris recomanats: Using accessories not recommended by the manufacturer may cause hazards.

3. Contingut del paquet

Verifiqueu que tots els articles siguin presents i en bon estat en desempaquetar-los.

• 1 x VEVOR 2-in-1 Electric Hot Pot and Grill Unit
• 1 x cable d'alimentació
• 1 x Lid (Glass)
• 1 x Oil Box
• 1 x Manual d'usuari (Aquest document)

4. Característiques del producte

• 1800 W d'alta potència: Ensures rapid heating for both hot pot and grilling functions.
• Disseny 2 en 1: Combines a hot pot and a grill, allowing for simultaneous boiling and grilling.
• Gran capacitat: 2.5 L hot pot and a φ16.54 inch (φ420 mm) grill pan, suitable for 2-8 people.
• Independent Dual Temperature Control: Separate control knobs for the hot pot and grill, each with 2-level heating settings (65-200°C / 149-392°F) for precise cooking.
• Premium Non-stick Coating: Minimizes smoke and oil, facilitates easy food flipping, and simplifies cleaning. Features a raised texture on the grill surface.
• Convenient Oil Management: Integrated oil leakage outlets and a removable oil box for efficient excess oil discharge and easy cleaning.
• Protecció automàtica contra sobreescalfament: Millora la seguretat durant el funcionament.

5. Configuració

Seguiu aquests passos per a la configuració inicial:

1. Desembalar: Carefully remove all components from the packaging. Retain packaging for storage or return if necessary.
2. Inspeccionar: Comproveu si l'aparell presenta algun signe de danys. No l'utilitzeu si està danyat.
3. Neteja: Before first use, wipe the non-stick surfaces of the hot pot and grill with a damp cloth. Wash the lid and oil box with warm, soapy water, then rinse and dry thoroughly.
4. Col·locació: Place the unit on a stable, flat, heat-resistant surface. Ensure there is adequate ventilation around the appliance.
5. Connectar l'alimentació: Insert the detachable power cord securely into the appliance's power inlet. Then, plug the power cord into a grounded 110V AC electrical outlet.
6. Install Oil Box: Ensure the oil box is correctly inserted into its designated slot to collect excess oil during grilling.

6. Instruccions de funcionament

This appliance allows for independent operation of the hot pot and grill functions.

6.1 Hot Pot Operation

1. Fill Hot Pot: Pour your desired broth or water into the hot pot section. Do not exceed the maximum fill line.
2. Encès: Turn the left control knob (labeled 'Hot Pot') to your desired heat setting. The indicator light will illuminate.
3. Ajustar la temperatura: Select from the available heat levels to bring the liquid to a boil or maintain a simmer.
4. Afegir ingredients: Once the desired temperature is reached, add your hot pot ingredients (e.g., vegetables, meat, seafood) to the broth.
5. Use Lid: Place the glass lid over the hot pot section to speed up heating and retain heat.

6.2 Funcionament de la graella

1. Preheat Grill: Turn the right control knob (labeled 'Barbecue') to your desired heat setting. The indicator light will illuminate. Allow a few minutes for the grill surface to preheat.
2. Afegir menjar: Place your grilling ingredients (e.g., marinated meats, vegetables) directly onto the non-stick grill surface.
3. Monitor Oil: Ensure the oil box is in place to collect any excess oil that drains from the grill surface.
4. Ajustar la temperatura: Adjust the knob as needed to achieve optimal grilling results.

6.3 Simultaneous Use

Both the hot pot and grill can be used simultaneously. Adjust each control knob independently to manage the cooking temperatures for each section.

7. Manteniment i Neteja

Regular cleaning and maintenance will prolong the life of your appliance.

1. Desconnecta i refresca: Desendolleu sempre l'aparell de la presa de corrent i deixeu-lo refredar completament abans de netejar-lo.
2. Remove Oil Box: Carefully remove the oil box and discard any collected oil. Wash the oil box with warm, soapy water.
3. Clean Cooking Surfaces: Wipe the non-stick hot pot and grill surfaces with a soft sponge or cloth and warm, soapy water. For stubborn food residue, soak the area with warm water for a few minutes before wiping. Avoid abrasive cleaners or metal scouring pads, which can damage the non-stick coating.
4. Exterior net: Netegeu l'exterior de l'aparell amb anunciamp tela. No submergiu la unitat principal a l'aigua.
5. Tapa neta: Wash the glass lid with warm, soapy water and rinse thoroughly.
6. Assecar bé: Assegureu-vos que totes les peces estiguin completament seques abans de tornar a muntar o emmagatzemar.
7. Emmagatzematge: Guardeu l'aparell en un lloc sec, allunyat de la llum solar directa i de la humitat.

8. Solució De Problemes

If you encounter issues with your VEVOR 2-in-1 Electric Hot Pot and Grill, refer to the following common problems and solutions:

Si el problema persisteix després d'intentar aquestes solucions, poseu-vos en contacte amb el servei d'atenció al client de VEVOR.

9. Especificacions

Detailed technical specifications for the VEVOR 1800W 2-in-1 Electric Hot Pot and Grill.

• Número de model: 1800W 2-in-1
• Potència: 1800W
• Voltage: 110 volts (CA)
• Nombre de configuracions: 2 (for each hot pot/grill control)
• Control de temperatura: 65-200 °C / 149-392 °F
• Hot Pot Capacity: 2.5 L
• Mini Hot Pot Outer Dimensions: φ9.84 x 2.76 in (φ250 x 70 mm)
• Grill Pan Size: φ16.54 in (φ420 mm)
• Dimensions del producte: 16.34 x 16.34 x 6.3 inches (φ415 x 160 mm)
• Pes de l'article: 7.39 lliures (3.1 kg)
• Material exterior: Plàstic
• Materials interiors: Electrical Components + Cast Aluminum
• Color: Negre
• Característica especial: Non-stick Coating, Temperature Control
• UPC: 197988507451

10. Garantia i Suport

This VEVOR appliance comes with a limited warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical assistance, troubleshooting beyond this manual, or warranty claims, please contact VEVOR customer support through their official weblloc web o el venedor on es va comprar el producte.

VEVOR Oficial Weblloc: www.vevor.com
