Introducció
This manual provides detailed instructions for the safe and effective operation, maintenance, and troubleshooting of your Nitecore NWL30 Outdoor Lantern Work Light. Please read this manual thoroughly before using the product to ensure optimal performance and longevity.
Contingut del paquet
En desempaquetar, comproveu que tots els elements que s'enumeren a continuació hi siguin presents i estiguin en bon estat:
- Nitecore NWL30 Lantern
- Cable de càrrega USB-C
- Estoig d'emmagatzematge
Image: The Nitecore NWL30 lantern, its USB-C charging cable, and a Nitecore sticker, indicating the typical package contents.
Característiques clau
- Sortida d'alta brillantor: Features a maximum output of 3,000 lumens with a beam throw of up to 131 yards.
- Temperatura de color ajustable: Stepless adjustment from 6500K (Cool White) to 2700K (Warm Light) to suit various lighting needs.
- Versatile Red Light Modes: Includes constant-on and slow flashing red light modes for signaling or preserving night vision.
- Temps d'execució estès: Provides up to 130 hours of continuous light on its lowest white light setting and 80 hours on constant-on red light.
- Banc d'energia d'emergència: Equipped with USB-C (20W In/Out) and USB-A (18W Out) ports to charge external devices.
- Durador i resistent a la intempèrie: IP66 rated for splash and dust resistance, and boasts a 1-meter impact resistance.
- Opcions de muntatge flexibles: Features a magnetic base and a 1/4-inch screw hole for tripod compatibility.
Image: The NWL30 lantern casting a powerful 3000-lumen beam, reaching up to 131 yards, illuminating a dark path.
Image: The NWL30 lantern emitting a red light, suitable for maintaining night vision or as an emergency signal.
Image: The NWL30 lantern showcasing its 18000mAh high-capacity battery, capable of providing extended runtime for prolonged use.
Image: The NWL30 lantern demonstrating its power bank capability, charging a smartphone and another small device via its USB-C and USB-A output ports.
Image: A construction worker standing in the rain, illustrating the IP66 water and dust resistance of the NWL30 lantern, suitable for harsh outdoor conditions.
Image: A hand attaching the NWL30 lantern to a metal surface, demonstrating its magnetic stand for versatile placement.
Imatge: Un primer pla view of the NWL30's base, highlighting the universal 1/4-inch screw hole for tripod mounting.
Configuració i ús inicial
Charging the NWL30
Before first use, fully charge the NWL30. Connect the provided USB-C charging cable to the USB-C port on the lantern and to a power source (e.g., USB wall adapter, computer USB port). The power indicator lights will show charging progress. A full charge takes approximately 3.6 hours.
Instruccions de funcionament
Ajust d'encesa/apagada i brillantor
The NWL30 features intuitive dual knob operation:
- To turn on the lantern, rotate the left dial (brightness control) clockwise. It will start at 50 lumens.
- Continue rotating the left dial clockwise to gradually increase the brightness up to 3,000 lumens.
- To turn off the lantern, rotate the left dial counter-clockwise until you hear a click.
Ajust de temperatura de color
- To adjust the color temperature, rotate the right dial (color temperature control).
- Rotate clockwise for cooler white light (up to 6500K) and counter-clockwise for warmer white light (down to 2700K).
Imatge: La part superior view of the NWL30 lantern, illustrating its dual knob design for stepless adjustment of both brightness and color temperature.
Red Light Operation
- To activate the red light, press and hold the button marked with an 'R' on the top panel.
- Press the 'R' button again to switch between constant-on red light and slow flashing red light.
- To turn off the red light, press and hold the 'R' button.
Video: An official product video demonstrating the various features and operational aspects of the Nitecore NWL30 lantern, including its brightness, color temperature adjustment, and power bank function.
Funcionalitat del banc d'energia
The NWL30 can serve as an emergency power bank for your electronic devices. It features two output ports:
- Port USB-C: Provides 20W input/output, allowing for fast charging of the lantern itself and external devices.
- Port USB-A: Provides 18W output for charging other devices.
Simply connect your device to the appropriate USB port on the NWL30 using its charging cable.
Opcions de muntatge
The NWL30 offers flexible mounting solutions for hands-free operation:
- Base magnètica: The integrated magnetic base allows the lantern to be securely attached to any ferrous metal surface.
- Compatibilitat amb trípode: A standard 1/4-inch screw hole is located on the base, enabling attachment to tripods or other mounting accessories.
Manteniment
To ensure the longevity and optimal performance of your NWL30 lantern, follow these maintenance guidelines:
- Clean the surface of the lantern with a soft, damp tela. Eviteu utilitzar netejadors abrasius o dissolvents.
- Keep the USB ports clean and free from dust or debris. Ensure the rubber cover for the ports is securely closed when not in use to maintain IP66 rating.
- Store the lantern in a cool, dry place when not in use for extended periods.
- For accidental activation prevention during transport or storage, rotate the handle over the knobs and buttons.
Resolució de problemes
If you encounter issues with your NWL30, please refer to the following common troubleshooting steps:
- La llanterna no s'encén: Assegureu-vos que la bateria estigui carregada. Connecteu-la a una font d'alimentació i comproveu l'indicador de càrrega.
- Sortida de llum tènue: The battery might be low. Recharge the device. Also, ensure the brightness dial is turned to the desired level.
- External device not charging: Check the connection cable. Ensure the NWL30 has sufficient battery charge.
- Funcionament intermitent: Ensure the USB port cover is fully sealed to prevent water or dust ingress.
If problems persist, please contact Nitecore customer support for further assistance.
Especificacions
| Atribut | Valor |
|---|---|
| Marca | Nitecore |
| Número de model | NWL30 |
| Pes de l'article | 1.13 lliures |
| Dimensions del producte | 4.8 x 4.19 x 2.07 polzades |
| Color | Negre |
| Tipus de font de llum | Díode emissor de llum (LED) |
| Material | Alumini |
| Font d'alimentació | Alimentat per bateria (1 bateria no estàndard inclosa) |
| Brillantor | 3000 lumens |
| Nivell de resistència a l'aigua | IP66 (Resistent a l'aigua) |
| Resistència a l'impacte | 1 metres |
| Fabricant | Sysmax Innovations Co. |
Garantia i Suport
Nitecore products are backed by a warranty. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official Nitecore website. For technical support or service inquiries, please contact Nitecore customer service through their official channels.
Nitecore Official Weblloc: www.nitecore.com
