KOSCHEAL A6 Single-Axis Gimbal Selfie Stick User Manual

1. Introducció

Thank you for choosing the KOSCHEAL A6 Single-Axis Gimbal Selfie Stick. This versatile device combines a gimbal stabilizer, selfie stick, and tripod into one compact unit, designed to enhance your mobile photography and videography. With its advanced anti-shake technology, detachable fill light, and convenient Bluetooth remote control, the A6 allows you to capture stable, high-quality content with ease. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance.

Image 1.1: KOSCHEAL A6 Gimbal Selfie Stick, showcasing its main components including the phone clamp, extendable pole, tripod base, detachable remote, and fill light.

2. Producte acabatview

2.1 Contingut del paquet

• KOSCHEAL A6 Gimbal Selfie Stick
• Comandament a distància Bluetooth
• Llum de farciment desmuntable
• Cable de càrrega USB
• Manual d'usuari

2.2 Identificació de components

Familiarize yourself with the main parts of your KOSCHEAL A6 device:

1. Smartphone Clamp: Subjecta el teu telèfon intel·ligent de manera segura.
2. Gimbal Head: Provides 1-axis stabilization.
3. Pal extensible: Telescopic arm for selfie stick functionality.
4. Handle/Tripod Base: Serves as a grip and unfolds into a stable tripod.
5. Comandament Bluetooth: Detachable remote for wireless control.
6. Llum d'ompliment: Provides adjustable illumination for various lighting conditions.
7. Botó de canvi de mode: Toggles between gimbal and selfie stick modes.
8. Port de càrrega: USB Type-C port for charging the gimbal and fill light.

3. Configuració

3.1 Desplegament del dispositiu

• Gently pull the top smartphone clamp upwards to extend the pole.
• To use as a tripod, apply slight outward force from the center of the handle's base to unfold the three legs. Ensure they are fully extended for stability.

3.2 Connectar el telèfon intel·ligent

• Open the smartphone clamp and carefully insert your phone.
• Important: Before powering on the gimbal, ensure your smartphone is positioned precisely in the center of the clamp to maintain balance and prevent motor strain. The clamp is compatible with phones between 3.6cm and 8.7cm wide, with a maximum weight of 280g.

3.3 Emparellament del comandament a distància Bluetooth

1. Remove the Bluetooth remote control from its slot on the handle.
2. Press and hold the power button on the remote for a few seconds until the indicator light flashes, indicating it's in pairing mode.
3. Al teu telèfon intel·ligent, vés a la configuració de Bluetooth i busca els dispositius disponibles.
4. Select "KOSCHEAL A6" (or similar name) from the list to pair. The indicator light on the remote will stop flashing once successfully paired.
5. The remote is compatible with Android 4.4 and iOS 5.1 or higher.

Image 3.1: Detachable Bluetooth remote control for wireless operation.

4. Instruccions de funcionament

4.1 Engegada/apagada

• Gimbal Power: Press and hold the power button on the gimbal head for 2 seconds to turn it on. The indicator light will illuminate. Repeat to turn off.
• Alimentació remota: Press and hold the power button on the remote until the green LED lights up for a few seconds to turn on. Hold again until the LED flashes several times to turn off.

4.2 Switching Modes (Gimbal / Selfie Stick)

The KOSCHEAL A6 offers two primary modes:

• Mode Gimbal: Provides 1-axis stabilization to reduce camera shake. Best used when the telescopic pole is extended to 3 sections or less for optimal stability.
• Mode de pal de selfie: The gimbal function is locked, allowing you to use the device as a traditional selfie stick or tripod.

To switch between modes, use the dedicated mode switch button on the device. Refer to the diagram below for its location.

Image 4.1: Illustration of the mode switch mechanism, allowing users to easily toggle between selfie stick and gimbal stabilization modes.

4.3 Using the Detachable Fill Light

The A6 features front and rear fill lights to illuminate your subjects:

• Encès/apagat: Press and hold the power button on the fill light unit to turn it on or off.
• Canvia el mode de llum: Short press the power button to cycle through 3 light modes: Warm Light, Natural Light, and White Light.
• Ajusta la brillantor: Short press the brightness adjustment button to cycle through 9 brightness levels.

Image 4.2: Visual representation of the three light modes (Warm, Natural, White) available on the detachable fill light.

Image 4.3: Demonstrates the use of the built-in LED light to control ambiance and enhance night photography or videography.

4.4 Funcions de control remot

The Bluetooth remote allows for convenient wireless control:

• Shutter Button (Top):
  • Feu clic a: Takes a photo or starts/stops video recording.
  • Premda llarga (2 segons): Turns the device's power on/off.
• Mode Button (Middle):
  • Un sol clic: Switches between horizontal and vertical shooting orientation.
  • Feu doble clic: Activates "Dreamspace" mode (clockwise rotation).
  • Triple clic: Activates "Dreamspace" mode (counter-clockwise rotation).
• POV Button (Bottom):
  • Feu clic a: Activates Half-Track POV mode.
  • Feu clic de nou: Cancels POV mode.

To use the remote as a shutter for your smartphone camera, ensure your phone's camera settings allow the volume button to act as a shutter.

Image 4.4: Detailed explanation of the remote control buttons and their corresponding functions for photo, video, and gimbal mode adjustments.

4.5 Adjusting Angles and Orientation

The gimbal head allows for flexible angle adjustments:

• You can freely adjust the smartphone's angle for horizontal, vertical, or diagonal orientations using the button slides.
• The gimbal's 1-axis stabilization automatically maintains a level horizon.

5. Característiques

5.1 Anti-Shake 1-Axis Gimbal Stabilization

The KOSCHEAL A6 integrates a powerful motion gyroscope and high-precision motor control with unique anti-shake and auto-balancing technology. This ensures your smartphone remains stable, effectively eliminating blur and shake during photography and videography, even during movement. It's ideal for capturing smooth footage for vlogs, live streams, and action shots.

Image 5.1: Demonstrates the significant reduction in blur and shake when using the KOSCHEAL A6 stabilizer compared to unstabilized footage.

Image 5.2: Illustrates the professional-grade stability provided by the A6, canceling out shakes and maintaining smooth visuals even during active movements like walking or running.

5.2 3-in-1 Versatile Design

The A6 seamlessly transforms between three essential tools:

• Stick selfie: The 6-section telescopic aluminum alloy pole extends up to 79cm (31 inches), allowing you to capture wider angles and group shots.
• Trípode: The handle's base unfolds into a stable tripod, perfect for hands-free live streaming, video calls, time-lapses, or stable group photos.
• Gimbal Stabilizer: Provides smooth, anti-shake footage for dynamic shots.

Image 5.3: Shows the KOSCHEAL A6 in its three primary configurations: extended as a selfie stick, set up as a tripod, and held as a gimbal for stabilized shooting.

Image 5.4: Highlights the integrated design of the extendable arm and tripod, emphasizing ease of use without needing additional accessories.

5.3 Disseny compacte i portàtil

The A6 folds down to a compact 18cm (7 inches), making it extremely easy to carry in a bag or pocket. Its lightweight design (265g) ensures it's a convenient companion for all your adventures.

5.4 Modes de tret avançats

Beyond basic stabilization, the A6 supports various creative shooting modes:

• 360-degree Rotation (Dreamspace Mode): Achieve dynamic, cinematic rotation effects similar to those seen in movies.
• Mode panoràmic: Capture expansive panoramic shots.
• Track Shooting: Follow subjects smoothly.
• Mode de retrat: Optimized for vertical video and photography.
• Control de gestos: (Requires compatible smartphone app)

Image 5.5: Illustrates the 360-degree dynamic rotation feature, enabling users to create imaginative, 'Inception'-style video effects.

6. Manteniment

6.1 Càrrega

• Use the provided USB charging cable to charge the gimbal and fill light. Connect the cable to the Type-C charging port on the device and a standard USB power adapter (DC5V, 500mAh recommended).
• L'indicador lluminós mostrarà l'estat de càrrega i s'apagarà quan estigui completament carregat.
• The remote control uses a replaceable CR1632 button cell battery.

6.2 Neteja i emmagatzematge

• Netegeu el dispositiu amb un drap suau i sec. No utilitzeu productes químics agressius ni materials abrasius.
• Guardeu el dispositiu en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
• Assegureu-vos que el dispositiu estigui completament carregat abans d'emmagatzemar-lo a llarg termini per preservar la durada de la bateria.

7. Solució De Problemes

• Gimbal not stabilizing or vibrating:
  • Ensure the smartphone is perfectly centered in the clamp abans d’engegar el cardà.
  • Check if the phone's weight exceeds 280g.
  • Ensure the gimbal is in gimbal mode and not locked in selfie stick mode.
  • For optimal stabilization, use the gimbal mode when the telescopic pole is extended to 3 sections or less.
• El comandament a distància Bluetooth no es connecta:
  • Ensure the remote is charged or has a fresh CR1632 battery.
  • Turn off and on the remote, then re-attempt pairing with your smartphone.
  • Check your smartphone's Bluetooth settings and forget previous pairings if necessary.
• Fill light not working:
  • Ensure the fill light unit is charged.
  • Press and hold the power button on the light to turn it on.
• Inestabilitat del trípode:
  • Assegureu-vos que les potes del trípode estiguin completament esteses i col·locades sobre una superfície plana i estable.
  • Verify the smartphone is balanced in the clamp.

8. Especificacions

Image 8.1: Visual diagram detailing the dimensions and key specifications of the KOSCHEAL A6.

9. Garantia i Suport

KOSCHEAL products are designed for reliability and performance. For any questions, technical support, or warranty claims, please contact KOSCHEAL customer service through the retailer where you purchased the product. Please retain your proof of purchase for warranty purposes.
