AIKVSXER 20-Inch Low Profile Fandelier with APP Control User Manual

1. Introducció

This manual provides detailed instructions for the safe and efficient operation, installation, and maintenance of your AIKVSXER 20-Inch Low Profile Fandelier. Please read this manual thoroughly before installation and use, and retain it for future reference.

2. Informació de seguretat

Desconnecteu sempre l'alimentació a l'interruptor automàtic abans de la instal·lació o el manteniment.
Assegureu-vos que totes les connexions elèctriques compleixin els codis i les ordenances locals.
Do not use with local dimmers or fan switches not provided with the unit. Use only the included remote control or APP for adjustments.
Mount the fan securely to a ceiling joist or a suitable support structure capable of holding the fan's weight.
Keep hands and objects clear of the fan blades during operation.

3. Contingut del paquet

Verifiqueu que tots els components siguin presents i no estiguin danyats abans de començar la instal·lació.

AIKVSXER 20-Inch Low Profile Fandelier Unit
Control remot
Mounting Hardware (screws, wire nuts, hook)
Manual d'usuari

Package contents including the fan unit, remote control, and various hardware components.

Imatge: Més deview of the fan unit and included accessories, such as the remote control and installation hardware.

4. Especificacions

Característica	Detall
Nom del model	Ventilador de sostre modern
Número de model	KT-8225-500
Dimensions	19.7 cm de llargada x 19.7 cm d'amplada x 5.7 cm d'alçada
Pes de l'article	5.2 lliures
Voltage	110 Volts
Wattage	52 watts
Brillantor	2200 lumens
Temperatura de color	3000K (blanc càlid), 4500K (blanc natural), 6500K (blanc fred)
Velocitats del vent	6 velocitats
Tipus de motor	DC Motor (Reversible)
Mètode de control	Remote Control, APP Control (Bluetooth)
Material	Plastic (ABS Engineering Grade)
Nivell de soroll	<35dB (Ultra Quiet)

5. Configuració i instal·lació

Follow these steps to install your AIKVSXER Fandelier. It is recommended to have a second person assist during installation.

Prepareu la ubicació de muntatge: Remove your old ceiling fan or light fixture. Ensure the electrical box is securely mounted and capable of supporting the fan's weight. Pull the electrical wires through the opening.

Ceiling with an old fan removed, showing the electrical box and wires.

Image: The ceiling mounting point after removing the old fixture, showing exposed electrical wires.

Instal·leu el suport de muntatge: Attach the provided mounting bracket to the ceiling electrical box using the screws. Ensure it is tightly secured.

Close-up of a hand tightening the mounting bracket to the ceiling electrical box.

Image: A person securing the metal mounting bracket to the ceiling electrical box with a drill.

Connecteu els cables elèctrics: Carefully connect the fan's electrical wires to the household wiring according to the wiring diagram in the full instruction manual. Use the provided wire nuts to secure connections.
Muntar la unitat de ventilador: The fan features a new foldable modular design. Unfold the fan blades and ensure they are properly aligned.

Diagram showing the foldable modular design of the fan and how to unfold and install the blades.

Image: Visual guide demonstrating the unfolding and installation of the fan blades into the main unit.

Muntar el ventilador: Carefully lift the fan unit and attach it to the installed mounting bracket. Ensure all screws are tightened to secure the fan to the ceiling.

Installed AIKVSXER Fandelier on a ceiling, showing its compact size and flush mount design.

Image: The AIKVSXER Fandelier fully installed on a ceiling, demonstrating its low-profile i disseny integrat.

Wall Switch Compatibility: This fan is designed to be controlled by the included remote or APP. It is not compatible with standard local dimmers or fan switches. Use a regular ON/OFF wall switch for power control only.

Diagram illustrating compatible and incompatible wall switches for the fan's operation.

Image: A visual guide showing that only standard ON/OFF wall switches are compatible, while dimmer or fan control switches are not.

6. Instruccions de funcionament

6.1. Control de la llum

La llum LED integrada ofereix una il·luminació personalitzable:

3 Color Temperatures (3CCT): Switch between 3000K (Warm White for relaxing ambiance), 4500K (Natural White for general purpose lighting), and 6500K (Cool White for functional and professional lighting).
Brillantor regulable: Adjust the light intensity from 10% to 100% to suit your preference.
Mode de llum nocturna: A dedicated setting for a soft, low-intensity light, ideal for bedrooms.

Three rooms demonstrating the 3000K Warm White, 4500K Natural White, and 6500K Cool White light settings of the fan.

Image: Visual comparison of the three available color temperatures: Warm White, Natural White, and Cool White.

A slider showing the dimmable brightness range from 5% (Dark) to 100% (Bright).

Image: A graphical representation of the flexible dimmable brightness feature, ranging from 5% to 100%.

A child sleeping peacefully in a bedroom with the fan's night light mode activated, showing a quiet environment.

Image: The fan operating in Night Light Mode, providing a soft glow suitable for sleeping environments.

6.2. Control de velocitat del ventilador

The fan offers 6 wind speed settings, powered by an ultra-quiet DC motor (<35dB), ensuring minimal noise disturbance.

Velocitat 1-2: Gentle Breeze Wind, ideal for quiet environments like bedrooms.
Velocitat 3-4: Balanced Comfort, suitable for everyday use.
Velocitat 5-6: Turbo Boost, Powerful Cooling for maximum airflow.

Three panels illustrating different fan speeds: Gentle Breeze (Speed 1-2), Balanced Comfort (Speed 3-4), and Turbo Boost (Speed 5-6).

Image: A visual breakdown of the 6 wind speed settings and their recommended uses.

6.3. Reversible Motor

The reversible DC motor allows for year-round use, optimizing air circulation for different seasons:

Summer (Downward Airflow): Creates a refreshing breeze for direct cooling.
Winter (Upward Airflow): Redistributes warm air to eliminate cold spots and enhance heating efficiency.

Diagram showing the reversible motor function with downward airflow for summer cooling and upward airflow for winter heat circulation.

Image: Illustration of the reversible motor's function for both summer cooling and winter heat circulation.

6.4. Funció de temporitzador

Set a 1-hour or 2-hour sleep timer for convenience, allowing the fan and light to turn off automatically.

A bedroom scene with a graphic overlay indicating a 1/2 hour timer setting for the fan.

Image: The fan's timer setting feature, showing options for 1 or 2 hours.

6.5. Control Methods: Remote and APP

Your fandelier can be controlled via the included remote control or a dedicated smartphone application (Bluetooth connectivity required).

Image showing the remote control with labeled buttons for light, fan speed, color temperature, night mode, and timer.

Image: The included remote control with its various functions clearly labeled.

Smartphone screen displaying the APP control interface for the fan, with a QR code for download.

Image: The smartphone APP interface for controlling the fan, including a QR code to download the app. Download the app here: http://www.mihuansemi.com/zhikong/

7. Manteniment

Regular maintenance ensures optimal performance and longevity of your fandelier.

Neteja: Utilitzeu un suau, damp cloth to wipe down the fan and light fixture. Do not use abrasive cleaners or solvents.
Neteja de fulles: The fan blades are made of durable plastic. Wipe them gently to remove dust.
Inspecció: Reviseu periòdicament totes les connexions i els elements de muntatge per assegurar-vos que es mantinguin segurs.

8. Solució De Problemes

If you encounter issues with your fandelier, refer to these common troubleshooting tips:

El ventilador no funciona: Check the power supply at the circuit breaker. Ensure all wiring connections are secure. Verify the remote control batteries are functional.
La llum no funciona: Check power supply. Ensure the light function is activated on the remote or APP.
Remote/APP Not Responding: Ensure Bluetooth is enabled on your device for APP control. Check remote control batteries. Re-pair the remote/APP if necessary (refer to full manual for pairing instructions).
Soroll excessiu: Ensure all mounting screws are tight. Check that the fan blades are free from obstructions.

9. Garantia i Suport

AIKVSXER stands behind the quality of its products.

Garantia: The motor is covered by a 5-year warranty, and the rest of the fan components are covered by a 2-year warranty.
Atenció al client: We offer 24-hour customer support. If you have any problems with installation or use, please feel free to contact us.
Contacte: For support, please visit the AIKVSXER store on Amazon or contact customer service via the details provided on the product packaging or official weblloc.
