Manual d'usuari de la central elèctrica portàtil OUKITEL P1000 Plus

1. Introducció

Thank you for choosing the OUKITEL P1000 Plus Portable Power Station. This device is designed to provide reliable power for various applications, including home backup, outdoor activities, and emergency situations. Featuring a 1024Wh LiFePO4 battery and 1800W AC output, it offers versatile charging options and smart control via a mobile application.

2. Instruccions de seguretat

• No desmunteu, no repareu ni modifiqueu la unitat.
• Keep the unit away from heat sources, fire, and water.
• Feu servir només cables i accessoris de càrrega originals o certificats.
• Guardeu la unitat en un lloc fresc i sec, allunyat de la llum solar directa.
• Assegureu-vos una ventilació adequada durant l'ús i la càrrega.
• Mantenir fora de l'abast dels nens i mascotes.
• If the product is left for a long time, please charge the product to 100% power every three months. When the battery level of the product is less than 20%, it is not recommended to store it for a long time.

3. Contingut del paquet

Verifiqueu que tots els elements estiguin inclosos al vostre paquet:

• 1x Estació d'alimentació portàtil OUKITEL P1000 Plus
• 2x 220W Solar Panel (if purchased as a bundle)
• 1 cable de càrrega de CA
• 1x Solar Charging Cable (MC4-XT60)
• 1x Guia de l'usuari

Image: OUKITEL P1000 Plus Portable Power Station and included accessories.

4. Producte acabatview

The OUKITEL P1000 Plus features a robust design with multiple input and output ports for various devices. The front panel includes a clear display for monitoring status, along with various AC, DC, and USB ports.

Imatge: Frontal view of the OUKITEL P1000 Plus Portable Power Station, highlighting the display and various output ports.

4.1. Ports and Features

• Preses de CA: 4 AC outlets (1800W total, 3600W peak) for household appliances.
• Ports USB-A: 2 USB-A ports (QC 18W Max, 5V 2.4A).
• Ports USB-C: 1 USB-C PD 100W, 1 USB-C PD 20W.
• Sortides de CC: 2 DC outputs (36W) and 1 120W DC car socket.
• Ports d'entrada: AC charging input, Solar charging input (PV IN 12-50V 7A).
• Llum LED: Built-in LED light with 3 modes (steady, SOS, flashing).
• Control intel·ligent d'aplicacions: Bluetooth and Wi-Fi connectivity for remote monitoring and control.

Image: Detailed diagram showing the various input and output ports of the OUKITEL P1000 Plus.

5. Configuració i càrrega

5.1. Configuració inicial

Before first use, fully charge the OUKITEL P1000 Plus. This ensures optimal battery performance and calibration.

5.2. Mètodes de càrrega

The P1000 Plus offers multiple charging options:

1. AC Fast Charging: Connect the AC charging cable to a standard wall outlet. The unit can charge from 0% to 80% in approximately 45 minutes, and 0% to 100% in 70 minutes, thanks to its 1200W AC fast charging capability.
2. Càrrega solar: Connect compatible solar panels (up to 500W max) using the provided solar charging cable. The unit can reach full charge in approximately 2.3 hours with 500W solar input.
3. Càrrega combinada (CA + Solar): For the fastest charging, combine AC and solar input up to 1700W. This can fully charge the unit in just 45 minutes.

Image: Visual representation of AC, solar, and combined charging methods and their respective charging times.

6. Funcionament

6.1. Encès / apagat

Press and hold the Power button to turn the unit on or off. The display will illuminate, showing the battery status and other relevant information.

6.2. Dispositius de connexió

Plug your devices into the appropriate AC, DC, or USB ports. Ensure that the total power consumption of your devices does not exceed the rated output of the power station (1800W continuous, 3600W peak).

Image: The OUKITEL P1000 Plus connected to various devices, demonstrating its 11 output ports.

6.3. Funció de sistema d'alimentació ininterrompuda (SAI)

The P1000 Plus can act as an Uninterruptible Power Supply (UPS). When connected to a wall outlet and devices are plugged into its AC outputs, it can seamlessly switch to battery power within 10ms during a power outage. This protects sensitive electronics like PCs, network equipment, and medical gear from data loss or interruption.

Image: The P1000 Plus providing seamless UPS backup power to a computer during a power outage.

6.4. Control intel·ligent d'aplicacions

Download the OUKITEL app to monitor and control your power station remotely via Bluetooth and Wi-Fi. The app allows you to check battery status, adjust charging modes, and manage functions directly from your smartphone.

Image: A user interacting with the OUKITEL smart app to monitor and control the power station.

6.5. Modes de llum LED

The built-in LED light has three modes: steady light, SOS, and flashing. These modes are useful for outdoor activities, emergency lighting, or as a signal light.

Image: The OUKITEL P1000 Plus providing illumination with its LED light during a campviatge.

7. Interfície de visualització

The digital display provides real-time information about the power station's status. Refer to the diagram below for an explanation of each indicator:

Image: Detailed explanation of the OUKITEL P1000 Plus display interface, showing various indicators like battery level, input/output wattage i icones d'estat.

1. Ús del temps/temps de càrrega
2. Protecció d'alta temperatura
3. Protecció de baixa temperatura
4. Estat del ventilador
5. Estat de potència
6. Mode UPS
7. Mode de càrrega fotovoltaica
8. Potència total d'entrada
9. Potència total de sortida
10. Sortida de l'encenedor (12V).
11. Sortida de CA
12. Sortida de CC (12 V).
13. silent mode
14. Mode de càrrega ràpida
15. Mode de càrrega lenta
16. Protecció de sobrecàrrega
17. Sortida USB
18. Sortida PD
19. Canvi de freqüència
20. WiFi/Bluetooth

8. Escenaris d'ús

The OUKITEL P1000 Plus is designed for diverse applications:

8.1. Outdoor Activities

Power your devices during camping, RV trips, and other outdoor adventures. It can run laptops, electric blankets, projectors, and drones for extended periods.

Image: The OUKITEL P1000 Plus powering devices during an outdoor campviatge.

8.2. Emergency Reserve

Provides critical backup power during natural disasters and power outages, ensuring essential devices remain operational.

Image: The OUKITEL P1000 Plus providing power during an emergency scenario.

8.3 Ús diari

Suitable for daily power needs, such as charging phones, running TVs, mini-fridges, and hair dryers.

Image: The OUKITEL P1000 Plus powering common household appliances for daily use.

9. Manteniment

9.1. Cura de la bateria

The P1000 Plus is equipped with a long-lasting LiFePO4 battery, offering up to 4000 charge cycles and a lifespan of up to 10 years. Its advanced Battery Management System (BMS) protects against overcurrent, overvoltage, and deep discharge. To prolong battery life, avoid completely draining the battery frequently.

Imatge: Interna view highlighting the LiFePO4 battery and Battery Management System (BMS) for durability and safety.

9.2. Emmagatzematge

When storing the unit for extended periods, ensure it is charged to at least 50% and stored in a cool, dry environment. Recharge the unit every three months to maintain battery health.

9.3. Neteja

Feu servir un drap sec i suau per netejar l'exterior de la central elèctrica. No utilitzeu netejadors líquids ni submergiu la unitat en aigua.

10. Solució De Problemes

• La unitat no s'encén: Ensure the battery is charged. If not, connect to an AC outlet or solar panel.
• Dispositius que no es carreguen: Check if the output ports are activated. Verify that the device's power consumption does not exceed the port's or unit's maximum output.
• Avís de sobrecàrrega: Disconnect some devices to reduce the load. The unit will automatically reset after a short period.
• Sobreescalfament: Ensure proper ventilation. If the unit overheats, it may temporarily shut down to protect components. Allow it to cool down before resuming use.
• Problemes de connectivitat de l'aplicació: Ensure Bluetooth and Wi-Fi are enabled on your smartphone and the power station. Restart both devices and try reconnecting.

11. Especificacions

12. Garantia i Suport

OUKITEL provides a 2-year warranty for the P1000 Plus Portable Power Station. For any issues or support, please contact OUKITEL Official US customer service. Free repairment is guaranteed within two years from the date of order. Water interference due to deliberate human factors is not covered under free repairment.

Per obtenir més ajuda, visiteu el OUKITEL Official Store or refer to the FAQs in your product documentation.

13. Vídeos de productes

Watch these official videos for more information on the OUKITEL P1000 Plus:
