JOYING Android 13 Car Stereo Head Unit

1. Introducció

This manual provides detailed instructions for the installation, operation, and maintenance of your JOYING Android 13 Car Stereo Head Unit (Model JY-HT145N8). This unit is designed to integrate seamlessly with Honda Civic models from 2016 to 2021, offering advanced features such as CarPlay, Android Auto, GPS navigation, and enhanced audio capabilities.

Please read this manual thoroughly before installation and use to ensure proper functionality and to prevent damage to the unit or your vehicle.

Imatge: Més deview of the JOYING Android 13 Car Stereo Head Unit highlighting key features.

2. Informació de seguretat

• Always ensure the vehicle's ignition is off before performing any installation or wiring.
• Disconnect the vehicle's battery to prevent electrical shorts or damage.
• Consult a professional installer if you are unsure about any steps.
• No feu servir la unitat de manera que us distregui de la conducció.
• Ensure all connections are secure to prevent intermittent issues or hazards.

3. Contingut del paquet

Verifiqueu que tots els elements que s'enumeren a continuació s'inclouen al vostre paquet:

• 9" radio x1
• Single Din Cage x1
• Left & Right Bracket x1
• Antena WiFi x1
• Antena GPS x1
• Antena 4G x2
• Micròfon extern x1
• USB cable x2
• AR Cable x1
• Screen Ribbon Cable x1
• Cable d'alimentació x1
• Manual d'usuari x1

Image: All components included in the JOYING Android 13 Car Stereo package.

4. Configuració i instal·lació

The JOYING head unit is designed for a plug-and-play installation, supporting factory reverse camera, steering wheel controls, USB, and lanewatch camera. Follow these general steps for installation:

1. Elimina els components originals del tauler de control: Carefully remove the side panel trims and the original radio unit from your vehicle's dashboard.
2. Connect Wiring Harnesses: Connect the provided wiring harnesses to the new head unit and your vehicle's existing connectors. Ensure all compatible plugs are securely connected. Some plugs may not be used depending on your vehicle's configuration.
3. Connecteu les antenes: Attach the WiFi, GPS, and 4G antennas to their respective ports on the head unit.
4. Connecteu els cables USB: Plug in the USB cables for data transfer and charging.
5. Connect Camera Inputs: Connect your reverse camera to the "CAM IN" port.
6. CAN Bus Setting: If your vehicle is equipped with a CAN bus, ensure the communication protocol (white button) on the head unit is set to the right side (CAN).
7. Radio Antenna Adapter: For sedan 4-door Honda Civic models, you may need to remove the rear passenger seat panel trim to access and bypass the HD radio box using the included green and gray cables.
8. Funcionalitat de prova: Before fully reassembling the dashboard, loosely fit the head unit and test all functions (power, audio, navigation, camera, steering wheel controls) to ensure everything is working correctly.
9. Remunta el tauler de control: Once all functions are verified, carefully reassemble the dashboard components.

Image: JOYING head unit seamlessly integrated into a Honda Civic dashboard.

Image: Purchase guide illustrating different wiring harnesses (A, B, C) based on OEM radio type.

Image: Important note on setting the CAN bus communication protocol.

Vídeos d'instal·lació:

5. Instruccions de funcionament

5.1 Funcions bàsiques

• Encès/apagat: The unit will typically power on with the vehicle's ignition. A fast boot feature allows it to start in 2 seconds after the initial 30-40 second boot.
• Control de volum: Use the physical volume knob or on-screen controls to adjust audio levels.
• Android OS Navigation: Navigate through the Android 13 interface using the touchscreen.

5.2 Característiques de connectivitat

• CarPlay i Android Auto: Connect your mobile phone via USB cable or Bluetooth to mirror apps, access navigation, make calls, and listen to music on the larger screen.
• Bluetooth 5.0: For hands-free calls and audio streaming.
• Built-in 4G Module: Insert a SIM card for internet access (does not support phone calls or SMS). Supports FDD-LTE: B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B38/B66/B71 and TDD-LTE: B41.
• Senyal WiFi: Independent WiFi antenna ensures stable 2.4GHz/5GHz internet access.
• Ports USB: Three USB ports are available for various connections.
• Ranura per a targetes Micro SD: For additional storage.

Image: Demonstration of Built-in CarPlay and Android Auto connectivity.

Image: Illustration of the upgraded WiFi signal with an independent antenna.

5.3 Navigation and Multimedia

• Navegació GPS: Precise GPS engines with included GPS antennas for accurate positioning and faster real-time navigation. Supports offline maps.
• Ràdio FM/AM: Built-in FM RDS tuner radio for selecting your favorite radio stations.
• DSP Sound: TDA7851 chip, 48-band graphic equalizer, and 4x50W max output power for high-quality sound. Supports aftermarket amplifiers via optical fiber and coaxial digital output.
• Split-screen Multitasking: Run two applications simultaneously on the screen.
• Sortida HDMI: Full digital image and sound-sending interface for projection screen display or on-screen display (1080P clear picture, zero delays). HDMI cable not included.

Image: High-quality sound enjoyment features including DSP chip and graphic equalizer.

Image: HDMI output for connecting external displays.

Image: Demonstration of split-screen multitasking on the head unit.

5.4 Personalization and Other Features

• Configuració personalitzada: Customize car boot logo, wallpapers, and changeable button colors. Adjustable screen brightness.
• Sistema de refrigeració: Dual heat sink design for superior heat dissipation and temperature control. Fan automatically turns on if CPU temperature or radio volume exceeds a warning value.
• Accessoris opcionals: Supports external OBD2 (for real-time data and trouble codes), AR Front Camera (records front road), and AR Rear Camera (switches automatically when reversing).

Image: Personalized settings for the head unit interface.

Image: Illustration of the upgraded dual heat sink cooling system.

Image: Optional accessories that can be integrated with the head unit.

6. Manteniment

• Neteja: Feu servir un drap suau i sec per netejar la pantalla i la unitat. Eviteu productes de neteja o dissolvents abrasius.
• Actualitzacions de programari: Periodically check for software updates via the system settings. Updates can improve performance and add new features.
• Control de temperatura: The dual heat sink design helps manage temperature. Ensure proper ventilation around the unit.

7. Solució De Problemes

Si teniu problemes, consulteu els següents consells habituals per a la resolució de problemes:

• Sense energia: Comproveu totes les connexions del cable d'alimentació. Assegureu-vos que el vehicle estigui engegat.
• Sense so: Verify audio cable connections (RR, RL for touring amp). Check volume levels and DSP settings.
• La càmera de marxa enrere no funciona: Ensure the "CAM IN" cable is properly connected. Check factory settings for reversing camera (Setting > Factory settings > Others > Prohibit reverse and set "Enable").
• Els comandaments del volant no funcionen: Check factory settings (Setting > Car > Factory settings > Canbus > Canbus Select and choose NO.21).
• Problemes amb el senyal GPS: Assegureu-vos que l'antena GPS estigui connectada correctament i que tingui una visió clara view del cel.
• Wi-Fi/4G Connectivity Problems: Check antenna connections and ensure correct SIM card insertion (for 4G). Verify network settings.
• Rendiment lent: Ensure the unit's cooling system is functioning. Close unnecessary background applications.

8. Especificacions

9. Garantia i Suport

9.1 Informació de la garantia

The JOYING Android 13 Car Stereo Head Unit comes with a 2 anys de garantiaSi us plau, conserveu el comprovant de compra per a reclamacions de garantia.

9.2 Suport al producte

For technical assistance, troubleshooting, or warranty inquiries, please contact JOYING customer support through the Amazon platform or visit the official JOYING website. Refer to the included warranty card for specific contact details.

Política de devolució: This product is eligible for a 30-day refund/replacement policy from the date of purchase, subject to Amazon's return guidelines.
