1. Introducció
The Kratos K13 is an AI-powered auto face tracking tripod designed for mobile phones. It features 360-degree rotation, gesture control, and operates without the need for a dedicated application. This device is suitable for hands-free video calls, live streaming, vlogging, and video recording, providing stable and dynamic camera movement.
Figure 1: Kratos K13 in use, demonstrating app-free operation.
2. Què hi ha a la caixa
- Kratos K13 AI Powered Auto Face Tracking Tripod
- Control remot
- Targeta de garantia
3. Producte acabatview
Característiques principals:
- Seguiment facial per IA: Automatically tracks your face or body with 360-degree rotation.
- No App Required: Operates independently without the need for Bluetooth pairing or a mobile application.
- 360° Rotatable Phone Holder: Allows for versatile camera mode selection, supporting both portrait and landscape orientations.
- Standard 1/4" Interface: Equipped with a 1/4-inch screw thread at the bottom for mounting on external tripods.
- Àmplia compatibilitat amb telèfons: The phone holder securely fits mobile phones ranging from 7 cm to 10.5 cm in width.
- Bateria recarregable incorporada: Features a 2200 mAh battery with a Type-C charging port, providing 8-9 hours of operation on a full charge.
- Smart Gesture Control: Use specific hand gestures to initiate and pause tracking.
- Detachable Remote: Inclou un comandament a distància per a un funcionament còmode.
Figure 2: Kratos K13 product components.
4. Configuració
4.1 Attaching Your Mobile Phone
- Gently expand the phone holder clamps.
- Insert your mobile phone into the holder, ensuring it is securely gripped. The holder accommodates phones between 7 cm and 10.5 cm wide.
- Adjust the phone's position for optimal balance and camera alignment.
Figure 3: Phone attachment and tripod compatibility.
4.2 Mounting on an External Tripod (Optional)
The Kratos K13 features a standard 1/4-inch screw thread at its base. To mount it on an external tripod:
- Align the 1/4-inch screw of your external tripod with the thread on the Kratos K13 base.
- Rotate the Kratos K13 clockwise until it is securely fastened to the tripod.
- Adjust the angle and height as needed using your external tripod's controls.
4.3 Configuració del control remot
The Kratos K13 includes a detachable remote control. To use the remote:
- Assegureu-vos que el comandament a distància tingui instal·lada una pila CR1632 que funcioni.
- Press and hold the button on the remote to power it on.
- The remote connects automatically to the Kratos K13.
Figure 4: Detachable remote control for the Kratos K13.
5. Instruccions de funcionament
5.1 Engegada/apagada
Press and hold the power button on the Kratos K13 unit for a few seconds to turn it on or off. An indicator light will confirm the power status.
5.2 Activating Auto Face Tracking
Once powered on, the Kratos K13 automatically enters tracking mode. Position yourself in front of the device, and it will begin to track your face or body, rotating 360 degrees to keep you in frame.
Figure 5: Auto tracking mode in action.
5.3 360-Degree Rotation
The Kratos K13 offers continuous 360-degree horizontal rotation. The phone holder can also be flipped 180 degrees to achieve various perspectives, including portrait and landscape orientations.
Figure 6: 360-degree rotation and holder adjustment.
5.4 Detachable Clip Functionality
The phone clip can be detached from the main unit, allowing for flexible use cases or easier storage.
Figure 7: Detachable phone clip.
6. Control de gestos
The Kratos K13 supports smart gesture control for convenient operation:
- "OK" Gesture: Make an "OK" hand gesture in front of the camera to initiate tracking or recording.
- Open Palm Gesture: Present an open palm hand gesture to the camera to pause tracking or recording.
Figure 8: Gesture control for starting and stopping tracking.
7. Càrrega
The Kratos K13 is equipped with a built-in 2200 mAh rechargeable battery. To charge the device:
- Connect the provided Type-C charging cable to the charging port on the Kratos K13.
- Connecteu l'altre extrem del cable a un adaptador de corrent USB adequat (no inclòs).
- The charging indicator light will illuminate during charging and turn off once the battery is fully charged.
A full charge typically provides 8-9 hours of continuous operation.
8. Manteniment
To ensure the longevity and optimal performance of your Kratos K13:
- Neteja: Netegeu el dispositiu amb un drap suau i sec. Eviteu utilitzar productes de neteja o dissolvents abrasius.
- Emmagatzematge: Guardeu el trípode en un lloc fresc i sec, allunyat de la llum solar directa i de temperatures extremes.
- Cura de la bateria: For prolonged storage, charge the battery to approximately 50% every three months to maintain battery health.
- Eviteu l'aigua: El dispositiu no és impermeable. Mantingueu-lo allunyat de l'aigua i de la humitat elevada.
9. Solució De Problemes
If you encounter issues with your Kratos K13, refer to the following common solutions:
- El dispositiu no s'encén: Assegureu-vos que la bateria estigui carregada. Connecteu el dispositiu a una font d'alimentació amb el cable tipus C.
- Tracking Not Working: Ensure you are within the optimal tracking range and lighting conditions. Make sure no obstructions are blocking the sensor. Re-attempt the gesture control.
- El control remot no respon: Check if the remote control battery (CR1632) needs replacement. Ensure the remote is powered on.
- El telèfon no encaixa correctament: Verify that your phone's width is between 7 cm and 10.5 cm. Adjust the phone carefully within the clamps.
Si els problemes persisteixen, poseu-vos en contacte amb l'atenció al client.
10. Especificacions
| Marca | Kratos |
| Model | K13 |
| Dimensions del producte | 30 x 5.5 x 5 cm |
| Pes de l'article | 200 g |
| Material | Alumini |
| Dispositius compatibles | Cellphone, iPhone (7 cm to 10.5 cm width) |
| Característica especial | Auto Face Tracking, Gesture Control, 360° Rotation, No App Needed |
| Capacitat de la bateria | 2200 mAh |
| Durada de la bateria | 8-9 hores (aprox.) |
| Port de càrrega | Tipus-C |
| Connector de trípode | Standard 1/4 inch screw thread |
11. Garantia i Suport
11.1 Informació de la garantia
The Kratos K13 AI Powered Auto Face Tracking Tripod comes with a 1 anys de garantia from the date of purchase. This warranty covers manufacturing defects and malfunctions under normal use. Please retain your purchase receipt for warranty claims.
11.2 Atenció al client
For technical assistance, warranty claims, or any other inquiries, please contact Kratos customer support:
- Telèfon: 81482 73270
- Correu electrònic: help@gokratos.com
Please provide your model number (K13) and a detailed description of the issue when contacting support.
