Manual d'usuari del carregador de cotxe retràctil Baseus 240W VR2 Max

1. Introducció

The Baseus 240W VR2 Max Retractable Car Charger is designed to provide efficient and versatile charging for multiple devices within a vehicle. This 4-in-1 charger features dual retractable USB-C cables, an additional USB-C port, and a USB-A port, offering a total power output of up to 240W. Its adjustable design ensures convenient access for all passengers.

2. Informació de seguretat

• Ensure the car charger is securely inserted into the vehicle's cigarette lighter socket.
• Do not expose the charger to extreme temperatures, direct sunlight, or moisture.
• Avoid pulling the retractable cables excessively or with sudden force to prevent damage.
• Mantenir fora de l'abast dels nens.
• If the product shows signs of damage or malfunction, discontinue use immediately.

3. Característiques del producte

• Sortida màxima de 240 W: Provides high-speed charging for laptops, tablets, and smartphones. Includes 105W USB-C1 cable, 105W USB-C2 cable, 33W USB-C3 port, and 30W USB-A port.
• Càrrega simultània: Capable of charging up to four devices concurrently with intelligent power allocation.
• Dual Retractable Cables: Two built-in 31.5-inch (80 cm) USB-C cables with magnetic storage for organized cable management. Tested for over 10,000 pulls and retractions.
• 450° Multi-Directional Adjustment: Features 180° vertical and 270° horizontal rotation for optimal positioning.
• Compatibilitat universal: Supports various fast charging protocols (PD2.0/3.0, PPS, QC2.0/QC3.0, FCP, AFC, HSCP, MTK1.0/2.0) for a wide range of devices including iPhone, Samsung, Google Pixel, Motorola, tablets, headphones, smartwatches, drones, and cameras.
• Protecció millorada: Incorporates 7-layer protection, flame-retardant shell material, and anti-slip clips for stable and safe operation.

Image: Four individuals in a car, each charging a device (laptop, tablet, smartphone) using the Baseus car charger, illustrating its multi-device charging capability.

Image: The Baseus car charger connected to a smartphone and a MacBook, highlighting its 240W maximum output and fast charging capabilities for various devices.

Image: A diagram illustrating the 450-degree dual-axis rotation feature of the Baseus car charger, showing 180 degrees vertical and 270 degrees horizontal adjustment.

4. Configuració

1. Inseriu al sòcol: Firmly insert the Baseus VR2 Max car charger into your vehicle's 12V/24V cigarette lighter socket. Ensure it is seated securely.
2. Indicador d'alimentació: Once properly connected, the LED light ring on the charger will illuminate, indicating it is powered on and ready for use.
3. Ajust de posició: Rotate the upper section of the charger to your desired angle (up to 180° vertically and 270° horizontally) for optimal accessibility.

5. Instruccions de funcionament

5.1 Extending and Retracting Cables

• Per estendre: Gently pull the USB-C cable to the desired length. It will lock into place.
• Per retractar-se: Pull the cable briefly and then release it. The cable will smoothly retract back into the charger.

Image: Visual guide demonstrating the proper method for extending the retractable USB-C cables to a desired length and retracting them by a brief pull and release.

5.2 Dispositius de càrrega

Connect your devices to the available ports or retractable cables. The charger intelligently distributes power based on the connected devices and their charging requirements.

Sortida d'un sol port:

• USB-C1 Cable: 105W Max
• USB-C2 Cable: 105W Max
• USB-C3 Port: 33W Max
• USB-A Port: 30W Max

Multiple Port Output (Examples):

• USB-C1 Cable + USB-C2 Cable: 65W + 45W
• USB-C1 Cable + USB-C3 Port: 67W + 33W
• USB-C1 Cable + USB-A Port: 67W + 30W
• USB-C2 Cable + USB-C3 Port: 67W + 33W
• USB-C2 Cable + USB-A Port: 67W + 30W
• USB-C3 Port + USB-A Port: 17W
• USB-C1 Cable + USB-C2 Cable + USB-C3 Port: 45W + 45W + 33W
• USB-C1 Cable + USB-C2 Cable + USB-A Port: 45W + 45W + 30W
• USB-C1 Cable + (USB-C3 + USB-A): 67W + 17W
• USB-C2 Cable + (USB-C3 + USB-A): 67W + 17W
• USB-C1 Cable + USB-C2 Cable + (USB-C3 + USB-A) Output: 45W + 45W + 17W Max

Image: A schematic showing the power output distribution across all four ports (two retractable USB-C cables, one USB-C port, one USB-A port) when charging simultaneously.

6. Especificacions

Image: A technical drawing illustrating the physical dimensions of the Baseus VR2 Max car charger, including its height, width, and depth.

7. Manteniment

• Clean the charger regularly with a soft, dry cloth. Do not use liquid cleaners or aerosols.
• Ensure the cigarette lighter socket is free of debris before inserting the charger.
• Guardeu el carregador en un lloc fresc i sec quan no l'utilitzeu.
• Avoid placing heavy objects on the charger or its cables.

8. Solució De Problemes

• El carregador no s'encén: Ensure the charger is fully inserted into the cigarette lighter socket. Check the vehicle's fuse for the cigarette lighter.
• El dispositiu no es carrega: Verify that the charging cable is securely connected to both the charger and the device. Ensure the device supports the charging protocol. Try a different port or cable.
• Càrrega lenta: Confirm that your device supports fast charging and that the cable used is capable of high power delivery. When multiple devices are connected, power is distributed, which may reduce individual port output. Refer to the 'Multiple Port Output' section for details.
• Cables not retracting smoothly: Ensure there are no obstructions. Gently pull the cable out completely and then release it to reset the retraction mechanism.

9. Garantia i Suport

Per obtenir informació sobre la garantia, assistència tècnica o consultes de servei, consulteu la pàgina oficial de Baseus. weblloc web o contacteu directament amb el servei d'atenció al client. Conserveu el rebut de compra per a reclamacions de garantia.
