Inefala 4+128GB Android 15 Car Stereo User Manual

Introducció

This manual provides comprehensive instructions for the installation, operation, and maintenance of your Inefala 4+128GB Android 15 Car Stereo. This unit is specifically designed for Peugeot 3008 models manufactured between 2009 and 2015, featuring a 9-inch In-Cell screen and advanced functionalities like wireless CarPlay, Android Auto, Mirror Link, GPS navigation, WiFi, Bluetooth 5.0, FM/RDS radio, equalizer, rear camera support, and steering wheel control integration. Please read this manual thoroughly before use to ensure proper functionality and safety.

Producte acabatview

The Inefala Car Stereo enhances your driving experience with its powerful Android 15 operating system, offering fast performance and a fluid interface. The 9-inch In-Cell screen provides a thinner, clearer, and more responsive display. Key features include:

• Sistema Android 15: Latest and most advanced operating system for vehicle devices.
• 4GB RAM + 128GB Storage: Powerful and stable performance with ampl'emmagatzematge.
• 9-inch In-Cell Screen: Thinner, clearer, and more responsive display with integrated touch sensors.
• CarPlay sense fil i Android Auto: Seamless smartphone integration for navigation, music, calls, and messages.
• Enllaç mirall: Display your smartphone screen on the car stereo via WiFi (for iOS and Android).
• Navegació GPS: Supports online and offline maps, with real-time road conditions.
• Connectivitat WiFi: High-speed internet access for app downloads, online shopping, and music streaming.
• Bluetooth 5.0: Wireless music streaming, hands-free calling, and file transferència.
• Ràdio FM/RDS: Supports 54 preset radio stations and online music transmission.
• 32-Band EQ DSP: Advanced sound tuning for an optimized audio experience.
• Rear Camera Support: Automatic display of the rear view when reversing (AHD camera included).
• Steering Wheel Controls (SWC): Integrate with existing vehicle controls for safe operation.
• Dual Screen & Picture-in-Picture: Run two applications simultaneously.
• UI Desktop Themes: Customizable interface with a large selection of wallpapers.

Configuració i instal·lació

This section outlines the general steps for installing your Inefala Car Stereo. Professional installation is recommended. Ensure the vehicle's power is disconnected before beginning installation.

Contingut del paquet

Verifiqueu que tots els components siguin presents al paquet:

• Peugeot 3008 Radio Unit
• Cable d'alimentació
• Caixa Canbus
• Cable RCA
• Antena GPS
• Cable d'entrada de la càmera posterior
• Càmera posterior AHD
• Micròfon extern
• 2 cables USB
• Cable adaptador USB
• Antena de ràdio
• 2 Accessoris
• Suports de suport
• Eines d'instal·lació

Image: Package List and Unit Dimensions. This image illustrates the various components included in the package and the dimensions of the 9-inch car stereo unit.

Cablejat i connexions

Refer to the wiring diagrams for correct connections. Ensure all cables are securely connected to prevent signal interference.

Image: Port Details. This diagram labels the various ports on the back of the car stereo unit and provides a detailed view of the RCA cable connections.

Rear Camera Wiring

Important: The reversing input must be plugged in even if the reversing camera is not used. Otherwise, your WiFi and Bluetooth signals may be affected.

1. Connect Cable 1 and Cable 5 to the positive pole of the car reversing light cable.
2. Connect Cable 2 to the negative pole of the car reversing light cable.
3. Connect Cable 3 and Cable 4 to the reverse trigger wire of the power cable. (No need to connect if this wire is not used. Pull it out and connect it if the last step doesn't work).

Image: Reversing Camera Wiring. This technical diagram shows the installation steps and wiring configuration for the backup camera system.

Configuració del control del volant (SWC)

• Without CANBUS box: Activation of steering wheel controls requires key learning in settings.
• With CANBUS box:
  1. Connect the 20-pin white port in the power cable to the Canbus itself, and the remaining 8-pin white port to the corresponding port on the back of the radio.
  2. Match the car model. CANBUS Matching Path: Settings -> Factory Setup (Password 1234) -> Can Settings.

Image: Steering Wheel Control Setup. This image displays the steering wheel and the corresponding on-screen menu for customizing control functions.

Efecte d'instal·lació

After installation, the product screen will be positioned higher than the center control frame, providing an elevated display effect.

Image: Installation Effect. This comparison shows the dashboard before and after the car stereo installation, highlighting the integrated look.

Instruccions de funcionament

CarPlay sense fil i Android Auto

Connect your smartphone to the car stereo via WiFi or Bluetooth to use Wireless CarPlay or Android Auto. This allows you to access navigation, make calls, send messages, and listen to music directly from your phone's interface on the car's screen. Note: For Huawei and some Samsung phones, Google Services and the Android Auto app must be supported and installed on the phone.

Image: Wireless CarPlay and Android Auto. This image highlights the various functions available through wireless smartphone integration, such as music, navigation, and communication.

Enllaç mirall

Mirror Link allows you to display your smartphone's screen directly onto the car stereo's display. This feature supports both iOS and Android devices, enabling you to view apps and content from your phone on the larger car screen.

Image: Mirror Link. This image demonstrates how a smartphone's display can be wirelessly or wired mirrored onto the car stereo screen.

GPS Navigation and WiFi

The unit supports both online and offline GPS navigation. You can download navigation apps via WiFi and receive real-time road condition updates to avoid traffic. High-speed internet access through WiFi also allows for app downloads, online streaming, and browsing.

Image: GPS Navigation. The car stereo displays a detailed map with navigation routes and points of interest.

Image: WiFi Function. This image illustrates the car stereo's ability to connect to WiFi, enabling online navigation and access to various applications.

Bluetooth 5.0 and FM/RDS Radio

Pair your device via Bluetooth 5.0 for wireless music streaming, hands-free calls, and file transfers. The FM/RDS radio supports 54 preset stations and allows for online music transmission, ensuring a quality audio experience.

Image: FM/RDS Radio and Bluetooth. This image displays the radio tuning interface and a hands-free Bluetooth call screen on the car stereo.

Control de veu

The system supports voice control, enhancing driving intelligence and security. Use voice commands to operate various functions, keeping your hands on the wheel and eyes on the road.

Dual Screen and UI Themes

Utilize the dual screen feature to run two applications simultaneously, such as navigation and music. Customize your interface with a wide selection of UI desktop themes and wallpapers to personalize your driving experience.

Image: In-Cell Touch Screen Features. This image highlights the high resolution of the In-Cell screen and its capabilities for split-screen multitasking and picture-in-picture viewing.

Image: UI Desktop Themes. This image showcases a selection of customizable desktop themes for the car stereo's user interface.

Manteniment

To ensure the longevity and optimal performance of your Inefala Car Stereo, follow these general maintenance guidelines:

• Neteja: Feu servir un drap suau i sec per netejar la pantalla i l'exterior. Eviteu productes de neteja o dissolvents abrasius.
• Actualitzacions de programari: Periodically check for software updates to ensure the system runs efficiently and has the latest features.
• Condicions ambientals: Eviteu exposar la unitat a temperatures extremes, a la llum solar directa durant períodes prolongats o a una humitat excessiva.
• Connexions de cable: Comproveu regularment totes les connexions dels cables per assegurar-vos que estiguin segures i lliures de danys.

Resolució de problemes

Si teniu problemes amb l'estèreo del vostre cotxe, consulteu els passos habituals següents per resoldre problemes:

• Sense energia: Check all power connections. Ensure the vehicle's ignition is on. Verify fuses.
• Sense so: Check speaker connections. Ensure volume is not muted or too low. Verify audio settings.
• Problemes de connexió Bluetooth: Ensure Bluetooth is enabled on both the stereo and your phone. Delete previous pairings and try reconnecting.
• Pèrdua de senyal GPS: Assegureu-vos que l'antena GPS estigui instal·lada correctament i que tingui una vista clara view del cel.
• Els comandaments del volant no funcionen: Recheck CANBUS connections or perform key learning in settings if no CANBUS is used.
• La pantalla no respon: Prova de reiniciar la unitat. Si el problema persisteix, pot ser necessari restablir les dades de fàbrica (nota: això esborrarà totes les dades de l'usuari).
• Problemes de WiFi: Ensure the WiFi antenna is connected. Check network settings and password.

Per a problemes persistents, poseu-vos en contacte amb l'atenció al client.

Especificacions

Garantia i Suport

Your Inefala Car Stereo comes with a standard manufacturer's warranty. For specific warranty terms and conditions, please refer to the documentation included with your purchase or contact Inefala customer support. For technical assistance, troubleshooting, or any product-related inquiries, please reach out to the seller or manufacturer directly. Keep your purchase receipt as proof of purchase for warranty claims.
