1. Introducció
This manual provides instructions for the assembly, operation, and maintenance of your HOMCOM Executive Office Chair, Model 921-880V00CW. This chair is designed for office use, featuring a high back, thick cushioning, adjustable height, reclining function, footrest, and rolling wheels for enhanced comfort and mobility.
Image 1.1: The HOMCOM Executive Office Chair in Cream White, featuring its plush design and integrated footrest.
2. Informació de seguretat
Please read all safety instructions before assembly and use. Retain this manual for future reference.
- Assembly is required. Ensure the chair is fully assembled according to the instructions before use.
- The maximum weight capacity for this chair is 265 pounds (120 kg). Do not exceed this limit.
- No us atureu a la cadira.
- Avoid placing heavy objects on the chair's backrest or armrests.
- Mantingueu les mans i els peus allunyats de les peces mòbils durant l'ajust.
- Feu servir la cadira sobre una superfície plana i estable.
3. Contingut del paquet
Verifiqueu que tots els components siguin presents abans de començar el muntatge. Si falta alguna peça o hi ha alguna peça danyada, poseu-vos en contacte amb el servei d'atenció al client.
- Respatller de la cadira
- Coixí de seient amb reposabraços
- Muntatge reposapeus
- Cilindre d'elevació de gas
- Base d’estrelles
- Rodes giratòries
- Mounting Hardware (Screws, Washers, Allen Wrench)
4. Instruccions de muntatge
Follow the manual step by step for proper assembly. It is recommended to have a second person assist with certain steps.
Guia pas a pas:
- Desembaleu tots els components i col·loqueu-los sobre una superfície neta i tova per evitar ratllades.
- Insert the casters into the holes at the end of each leg of the star base. Ensure they are securely seated.
- Col·loqueu el cilindre d'elevació de gas al forat central de la base en estrella.
- Attach the control mechanism to the underside of the seat cushion using the provided screws. Ensure the front of the mechanism faces the front of the seat.
- Fixeu els reposabraços al coixí del seient amb els cargols proporcionats.
- Attach the backrest to the seat cushion and armrests using the provided screws.
- Col·loqueu amb cura el seient i el respatller muntats sobre el cilindre d'elevació de gas.
- Install the footrest assembly into its designated slot under the seat.
- Test all functions to ensure proper operation and stability.
Image 4.1: Product dimensions for reference during assembly and placement.
5. Instruccions de funcionament
Your HOMCOM Executive Office Chair offers several adjustable features for personalized comfort.
5.1. Ajust d'alçada
To adjust the chair's height, pull the lever located under the seat upwards. While seated, lift your weight off the seat to raise the chair. To lower the chair, remain seated and pull the lever upwards. Release the lever to lock the height.
5.2. Funció reclinable
The chair offers three recline angles: 105° for working, 120° for watching, and 135° for relaxing. Use the lever on the side of the chair to adjust the backrest angle. Push the lever down to unlock and recline, then release to lock at the desired angle.
Image 5.1: Illustration of the chair's reclining function with various angles for different activities.
5.3. Footrest Operation
To extend the footrest, pull it out from underneath the seat. To retract, push it back in until it is fully stored. The footrest provides additional support when reclining.
Video 5.1: Demonstration of the chair's reclining and footrest features, highlighting its comfort and adjustability.
5.4. Gir i mobilitat
The chair features a 360° swivel seat and quiet PU wheels, allowing for fluid movement across various floor types without causing scratches. Ensure the wheels are clean and free of debris for optimal mobility.
Image 5.2: Close-up of the chair's PU wheels, designed for smooth movement and protection on various floor surfaces.
Image 5.3: Diagram illustrating the ergonomic support provided by the chair for neck, back, lumbar, and hip areas.
6. Manteniment i cura
To maintain the appearance and longevity of your chair, follow these care instructions:
- Neteja: Netegeu amb un anunciamp drap. Eviteu productes químics agressius o netejadors abrasius.
- Cura del teixit: The chair is made of 100% Polyester snow flannel fabric. Spot clean as needed.
- Inspecció: Reviseu periòdicament tots els cargols i perns per assegurar-vos que estiguin ben ajustats. Torneu a apretar-los si cal.
- Manteniment de rodes: Mantingueu les rodes lliures de cabells i deixalles per garantir un moviment suau.
Image 6.1: Detail of the elegant and skin-friendly snow flannel fabric used on the chair.
7. Solució De Problemes
Si teniu problemes amb la cadira, consulteu les solucions habituals següents:
- La cadira no ajusta l'alçada: Ensure the gas lift lever is fully engaged. Check if the gas lift cylinder is properly installed.
- Chair wobbles: Verify that all assembly screws are securely tightened. Ensure the chair is on a level surface.
- Rodes que no giren suaument: Check for debris (hair, lint) caught in the wheels and clean as necessary.
- Reclining mechanism stuck: Ensure no obstructions are preventing movement. Check the reclining lever for proper engagement.
Si els problemes persisteixen, poseu-vos en contacte amb l'assistència al client per obtenir ajuda.
8. Especificacions
| Característica | Detall |
|---|---|
| Marca | HOMCOM |
| Nom del model | Cadira d'oficina |
| Número de model | 921-880V00CW |
| Color | Blanc crema |
| Dimensions del producte | 30.3" de profunditat x 29.5" d'amplada x 46.5" d'alçada (77 x 75 x 118 cm) |
| Alçada del seient | Adjustable, up to 23.2 Inches |
| Profunditat del seient | 21.3 polzades (54 cm) |
| Longitud del seient | 19.7 polzades (50 cm) |
| Estil d'esquena | Solid High Back |
| Material | Snow Flannel (100% Polyester), Foam Fill |
| Material base | Reinforced Steel, Electroplated Five-Star Base |
| Característiques especials | Foot Rest, High Back, Reclining (3 positions), Rolling Wheels, Upholstered |
| Capacitat de pes | 265 lliures (120 kg) |
| Pes de l'article | 37 lliures (16.8 kg) |
| Muntatge obligatori | Sí |
9. Garantia i Suport
Per obtenir informació sobre la garantia o assistència tècnica, consulteu el lloc web oficial del fabricant. weblloc web o poseu-vos en contacte amb el seu departament d'atenció al client. Conserveu el rebut de compra com a comprovant de compra.
Fabricant: Aosom LLC
