Jackery HomePower 3600 Plus Portable Power Station User Manual

1. Introducció

This manual provides essential information for the safe and efficient operation of your Jackery HomePower 3600 Plus Portable Power Station. Please read this manual thoroughly before using the product and retain it for future reference. The Jackery HomePower 3600 Plus is a high-capacity portable power station designed to provide reliable power for home backup, emergencies, RV use, and various outdoor activities. It features a robust LFP battery and multiple charging options.

2. Instruccions de seguretat

Always follow basic safety precautions when using this product to reduce the risk of fire, electric shock, or injury. Failure to follow these instructions may result in serious injury or property damage.

• No desmunteu, no repareu ni modifiqueu la unitat.
• No col·loqueu la unitat a prop del foc ni l'exposeu a la calor.
• Do not use or store the unit in a bathroom or in an area exposed to water.
• Mantingueu la unitat lluny de nens i animals de companyia.
• Do not use the unit if it is damaged or has been modified.
• Assegureu-vos una ventilació adequada durant l'ús i la càrrega.
• Feu servir només els accessoris i cables de càrrega recomanats.
• Avoid dropping, hitting, or subjecting the unit to strong impacts.
• Guardeu la unitat en un lloc fresc i sec, allunyat de la llum solar directa.

3. Contingut del paquet

• Jackery HomePower 3600 Plus Portable Power Station
• 2 panells solars de 200 W
• Cable de càrrega de CA.
• Manual d'usuari

Nota: The HomePower 3600 Plus and solar panels are shipped separately and may arrive in separate packages.

4. Producte acabatview

The Jackery HomePower 3600 Plus is designed for versatility and durability, offering substantial power output and capacity for various applications.

• Essential Home Backup: Delivers 3600W AC output (7200W in parallel with another unit) with 3584Wh capacity, expandable up to 21kWh per unit or 43kWh with multiple units. Supports dual voltage (120V & 240V in parallel).
• Segur i durador: Features high-temperature resistant ceramic membrane LFP battery cells, offering 6,000 cycles for a 10-year lifespan. Reliable operation from -4 °F to 113 °F (-20 °C to 45 °C).
• Disseny ultraportàtil: Weighs 77.16 lbs (35 kg) and is 34% smaller and 29.3% lighter than comparable models. Includes wheels and a telescopic handle for easy transport.
• Ports de sortida múltiples: Equipped with 4 AC outputs (120V, 20A), 1 TT-30 RV Port (120V, 30A), 2 USB-C Ports (100W Max), and 2 USB-A Ports (18W Max).

5. Configuració

The Jackery HomePower 3600 Plus is designed for plug-and-play operation, requiring minimal setup.

1. Desembalatge: Carefully remove the power station and solar panels from their packaging.
2. Càrrec inicial: It is recommended to fully charge the power station before first use. Connect the AC Charging Cable to a wall outlet.
3. Connexió del panell solar: For solar charging, unfold the 200W solar panels and connect them to the DC input ports on the power station. Ensure panels are positioned to receive maximum sunlight.
4. Expansion Battery (Optional): If using expansion batteries, connect them to the DC Expansion Port on the power station.

6. Instruccions de funcionament

Using your Jackery HomePower 3600 Plus is straightforward.

6.1 Engegada/apagada

• Press the 'Power' button to turn the unit on. The digital display will illuminate.
• To turn off, press and hold the 'Power' button until the display turns off.

6.2 Opcions de càrrega

The HomePower 3600 Plus offers four charging methods:

• Hybrid AC+DC: Recharges from 0-100% in approximately 2 hours.
• Càrrega de CA: Recharges from 0-100% in approximately 2.5 hours via a standard wall outlet.
• Càrrega solar: Recharges from 0-100% in approximately 4 hours using solar panels.
• Generador de gas: Recharges from 0-100% in approximately 2.5 hours.

6.3 Connexió de dispositius

Simply plug your devices into the appropriate output ports (AC, USB-C, USB-A, RV) on the front panel. Ensure the power station is turned on and the specific output port is activated if it has a dedicated switch.

6.4 Funció de sistema d'alimentació ininterrompuda (SAI)

The HomePower 3600 Plus features a UPS function with a switching time of less than 10ms. This provides instant backup power for sensitive electronics like computers or medical equipment during power outages.

7. Manteniment

Proper maintenance ensures the longevity and optimal performance of your power station.

• Neteja: Use a dry, soft cloth to wipe the unit. Avoid using abrasive cleaners or solvents.
• Emmagatzematge: Store the unit in a cool, dry, and well-ventilated area. For long-term storage, ensure the unit is turned off to preserve charge. Recharge every 3-6 months to maintain battery health.
• Salut de la bateria: The LFP battery is designed for 6,000 cycles, retaining 70% capacity after this period, ensuring a 10+ year lifespan.

8. Solució De Problemes

Si teniu problemes, consulteu els passos habituals següents per a la resolució de problemes:

• La unitat no s'encén: Ensure the battery is charged. If completely depleted, connect to AC power for a few minutes before attempting to power on.
• Sense sortida dels ports: Check if the specific output port (AC, USB) is activated. Verify the device connected is functioning correctly and its power requirements do not exceed the port's limit.
• Càrrega lenta: Ensure all charging cables are securely connected. For solar charging, verify panels are clean and positioned for optimal sunlight exposure. Check for any error messages on the display.
• Protecció de sobrecàrrega: Si la unitat s'apaga a causa d'una sobrecàrrega, desconnecteu alguns dispositius i reinicieu la unitat.

9. Especificacions

10. Garantia i Suport

The Jackery HomePower 3600 Plus comes with a 5-year coverage period. Additionally, 4-Year Protection Plans are available for purchase to extend coverage.

For technical support, troubleshooting assistance, or warranty claims, please contact Jackery customer service. Refer to the official Jackery website or the included user manual for contact details.
