1. Introducció
This manual provides detailed instructions for the safe and effective operation of your Ourlife M40TR 5K WiFi Action Camera. Please read this manual thoroughly before using the device and retain it for future reference. This camera is designed to capture high-quality video and photos in various environments, including underwater, with features such as dual screens, Electronic Image Stabilization (EIS), and remote control capabilities.
2. Contingut del paquet
Verifiqueu que tots els elements que s'enumeren a continuació s'inclouen al vostre paquet. Si falta algun element o hi ha algun malmès, poseu-vos en contacte amb l'atenció al client.
- Ourlife M40TR Action Camera
- Carcassa impermeable
- Targeta de memòria de 32 GB
- Control remot sense fil 2.4G
- Cable USB
- Muntatge de manillar/pal
- Various Mounts (Mount1, Mount2, Mount3, Mount4, Mount5)
- Clip 1
- Embenats
- Coixinets adhesius 3M
- Cable de cable
- Manual d'usuari
Image: Ourlife M40TR Action Camera, waterproof housing, 32GB memory card, remote control, and various mounting accessories.
3. Producte acabatview
L'Ourlife M40TR features a compact design with dual screens for versatile shooting. The main screen is a 2-inch touchscreen, complemented by a 1.3-inch front display for easy selfies and vlogging. It supports 5K Ultra HD video recording and 50MP photos, enhanced by Electronic Image Stabilization (EIS) and a 170° ultra-wide-angle lens with 5X digital zoom.
Imatge: L'Ourlife M40TR Action Camera showcasing its dual color screens and 5K 30FPS capability.
Image: Icons illustrating key features: 5K Video, Dual Color Screen, EIS, 50MP Photos, Dashcam Mode, 170° Wide Angle Lens, Time Lapse, 100FT Waterproof, WiFi Connect, Remote.
4. Configuració
4.1. Instal·lació de la bateria
The camera uses a rechargeable Lithium Ion battery. Ensure the battery is fully charged before first use. To install the battery:
- Obriu la tapa del compartiment de la bateria a la part inferior de la càmera.
- Inseriu la bateria amb l'orientació correcta, fent coincidir els contactes.
- Tanqueu bé la tapa del compartiment de la bateria.
4.2. Instal·lació de la targeta SD
A 32GB Micro SD card is included. The camera supports Micro SD cards up to 256GB.
- Localitza la ranura per a targetes Micro SD al lateral de la càmera.
- Introduïu la targeta Micro SD amb els contactes mirant cap a la part frontal de la càmera fins que encaixi al seu lloc.
- Per treure-la, premeu suaument la targeta fins que surti.
4.3. Waterproof Case Usage
The included waterproof housing allows the camera to be used at depths of up to 30 meters (100 feet). Ensure the camera is securely placed inside the housing and the latch is firmly closed before submerging.
Video: Demonstration of the Ourlife M40TR Action Camera's waterproof capabilities, showing it submerged in water.
Imatge: L'Ourlife M40TR Action Camera in its waterproof housing, submerged in water with a diver in the background, illustrating its 30M (100FT) waterproof depth.
5. Instruccions de funcionament
5.1. Encendre/apagar
- To power on: Press and hold the Power/Mode button until the screen lights up.
- Per apagar: manteniu premut el botó d'engegada/mode fins que la pantalla s'apagui.
5.2. Dual Screen Operation
The camera features a 2-inch main touchscreen and a 1.3-inch front display. You can switch between the front and rear screens for different shooting perspectives.
- To switch screens: Press and hold the 'M' button on the side of the camera.
- Note: Only one screen is active at a time to conserve battery.
Imatge: L'Ourlife M40TR Action Camera displaying its dual screens, with the front screen showing a selfie view and the rear screen showing the main camera view.
5.3. Selecció de mode
The camera offers multiple shooting modes accessible via the touchscreen interface.
Video: A user navigating through the mode selection menu on the Ourlife M40TR Action Camera's touchscreen.
Els modes disponibles inclouen:
- Vídeo normal
- Vídeo lent
- Vídeo en bucle
- Vídeo Time Lapse
- Foto normal
- Foto amb temporitzador automàtic
- Fotos de ràfega
- Foto de lapse de temps
- Dashcam Mode
5.4. Video and Photo Resolution Settings
Adjust video and photo resolutions to suit your needs. Access these settings through the camera's menu.
Imatge: L'Ourlife M40TR Action Camera highlighting its 5K Ultra HD video display, supporting various resolutions including 4K 60fps/30fps, 2.7K 30fps, 1080P 60fps/30fps, and 720P 120fps/60fps/30fps.
Imatge: L'Ourlife M40TR Action Camera demonstrating its 50MP photo capability, with options for 50MP, 30MP, 24MP, 20MP, 12MP, and 8MP.
5.5. Estabilització electrònica d'imatge (EIS)
The built-in EIS technology helps to stabilize video footage, reducing blur and shakiness, especially during active movements.
Image: A split image showing the difference between EIS off (blurry) and EIS on (stable) during a cycling activity.
Image: Visual representation of EIS Anti-Shake Technology, ensuring crystal-clear photos and videos devoid of blurriness or ghosting.
5.6. Wide Angle & Zoom
The 170° ultra-wide-angle lens captures expansive scenes, and the 5X digital zoom allows for closer shots.
Image: A visual comparison of a 170° ultra-wide-angle shot of a surfer and a demonstration of 5X digital zoom on a lighthouse.
Image: A paraglider captured with the Ourlife M40TR Action Camera, illustrating the expansive 170° ultra-wide view angle.
5.7. Ús del control remot
The 2.4G wireless remote control allows you to operate the camera from up to 15 meters away, switching between video and photo modes with a single button.
Image: A cyclist using the 2.4GHz wireless remote control on their wrist to operate the Ourlife M40TR Action Camera, highlighting its 15m range.
5.8. Wi-Fi Connection & App
Connect your camera to the SupCam Pro app via Wi-Fi for live preview, remote control, and instant sharing of content.
Imatge: L'Ourlife M40TR Action Camera wirelessly connected to a smartphone, showing instant sharing of photos and videos to social media platforms.
Image: Step-by-step guide on how to connect the Ourlife M40TR Action Camera to Wi-Fi using the SupCam Pro App, including a QR code for app download. Download the SupCam Pro App: https://qr04.cn/Acp9lo
5.9. Transferència de dades
Transfer your photos and videos to your computer using Wi-Fi, USB cable, or a card reader.
Image: Visual guide demonstrating three methods for downloading pictures and videos from the Ourlife M40TR Action Camera to a computer: via Mobile App (Wi-Fi), USB Connection, and Card Reader.
6. Manteniment
6.1. Neteja
- Use a soft, lint-free cloth to clean the camera lens and screens.
- For the waterproof housing, rinse with fresh water after each use in saltwater and allow to air dry.
6.2. Emmagatzematge
- Guardeu la càmera en un lloc fresc i sec, allunyat de la llum solar directa.
- Traieu la bateria si la càmera no s'utilitzarà durant un període prolongat.
7. Solució De Problemes
If you encounter any issues with your Ourlife M40TR Action Camera, please refer to the following common solutions:
- La càmera no s'encén: Assegureu-vos que la bateria estigui completament carregada i inserida correctament.
- Error de la targeta SD: Format the SD card in the camera's settings menu. If the issue persists, try a different compatible SD card.
- Problemes de connexió Wi-Fi: Ensure the camera's Wi-Fi is enabled and you are within range. Restart both the camera and your smartphone.
- Poor video/photo quality: Check the selected resolution settings. Ensure the lens is clean and free from smudges.
- Water leakage in housing: Before each use, inspect the waterproof housing for any cracks or damage. Ensure the rubber seal is clean and properly seated.
Per a més ajuda, poseu-vos en contacte amb l'atenció al client.
8. Especificacions
| Característica | Detall |
|---|---|
| Nom de marca | Ourlsi |
| Número de model | AT-M40R |
| Resolució de captura de vídeo | 5K |
| Tecnologia del sensor fotogràfic | CMOS |
| Característiques especials | EIS, 170° Adjustable View Angle, Anti-Shake, Remote Control, Speakers, Time Lapse, Timer, Car Mode |
| Profunditat impermeable | Up to 30 meters (100FT) with waterproof case |
| Tecnologia de connectivitat | Wi-Fi, sense fil |
| Mida de la pantalla | 2 Inches (main), 1.3 Inches (front) |
| Tipus de memòria flash | Micro SD (admet fins a 256 GB) |
| Bateries | Necessita 1 bateria de ions de liti (inclosa) |
| Pes de l'article | 14.9 unces |
| Dimensions del paquet | 11.34 x 7.52 x 3.11 polzades |
9. Garantia i Suport
Ourlife offers the following support for your product:
- 30-day Guarantee & Refunds: For initial purchase satisfaction.
- 1-year Exchange: For product defects or malfunctions.
- 24-hour Official Support: Contacta per correu electrònic a info@ourlifesmart.com per a qualsevol pregunta o ajuda.
Image: Ourlife customer support details, including email address (info@ourlifesmart.com), 24-hour official support, 30-day guarantee & refunds, and 1-year exchange policy.
