Victoper A1200T Rechargeable LED Flashlight User Manual

1. Introducció

Thank you for choosing the Victoper A1200T Rechargeable LED Flashlight. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new flashlight. Please read this manual thoroughly before use and retain it for future reference.

2. Instruccions de seguretat

• Do not look directly into the LED light beam. The high intensity light can cause temporary vision impairment or permanent eye damage.
• Mantingueu la llanterna fora de l'abast dels nens.
• Do not disassemble the flashlight. This may void the warranty and could lead to damage or injury.
• Feu servir només el mètode de càrrega i el volum especificatstage (5V2A adapter recommended) to prevent damage to the battery or flashlight.
• Eviteu exposar la llanterna a temperatures extremes o a la llum solar directa durant períodes prolongats.
• Eliminar les bateries segons la normativa local.

3. Contingut del paquet

Si us plau, comproveu el paquet per veure si hi ha els elements següents:

• Victoper A1200T Rechargeable LED Flashlight (x2)
• Cable de càrrega USB (x2)
• Corretja de canell (preinstal·lada o inclosa per separat)
• Manual d'usuari

Image showing two Victoper A1200T rechargeable LED flashlights, each with a wrist strap, alongside two USB charging cables. The flashlights are black with a red band.

4. Producte acabatview

The Victoper A1200T is a high-performance, rechargeable LED flashlight designed for various outdoor and indoor applications. It features a durable aluminum body, multiple lighting modes, and an adjustable zoom function.

Característiques principals:

• Sortida de lumens alts: Provides powerful illumination.
• 5 modes d'il·luminació: Alt, mitjà, baix, estroboscòpic i SOS per a un ús versàtil.
• Funció de zoom: Adjusts from a wide floodlight to a focused spotlight.
• USB recarregable: Càrrega còmoda mitjançant cable USB.
• Impermeable IP65: Resistant to dust and water splashes.
• Construcció duradora: Made from aluminum alloy for longevity.

Graphic illustrating the Victoper A1200T flashlight's powerful beam, reaching up to 200 meters (656 feet). It also demonstrates the adjustable zoom feature, showing how to widen or narrow the light beam.

5. Configuració

Càrrega de la llanterna:

1. Locate the USB charging port on the flashlight. It is typically covered by a rubber flap for protection.
2. Open the rubber flap and insert the small end of the provided USB charging cable into the flashlight's port.
3. Connect the larger end of the USB cable to a compatible 5V2A USB power source (e.g., power bank, laptop, car charger, or wall adapter).
4. The indicator light near the charging port will illuminate vermell to indicate that the flashlight is charging.
5. Once fully charged, the indicator light will turn verd.
6. Disconnect the charging cable and securely close the rubber flap to maintain the flashlight's waterproof rating.

Note: Please use an adapter below 5V2A for charging to avoid failure to charge due to high-power adapters.

Diagram explaining the USB rechargeable feature of the Victoper A1200T flashlight. It shows the charging port, red indicator for charging, green for fully charged, and recommends using a 5V2A adapter with examples like power banks, laptops, car chargers, and wall adapters.

Image highlighting the built-in 1800mAh battery of the Victoper A1200T flashlight, providing up to 15 hours of continuous operation on a single charge.

6. Instruccions de funcionament

Encès/apagat i canvi de mode:

1. Per encendre la llanterna ON, press the power button located on the tail cap or side of the flashlight. It will typically start in High mode.
2. To cycle through the lighting modes (High → Medium → Low → Strobe → SOS), press the power button repeatedly while the flashlight is on.
3. Per encendre la llanterna OFF, press and hold the power button for approximately 5 seconds in any mode. Alternatively, if you cycle through all modes, the flashlight will turn off after the SOS mode.

Visual representation of the five distinct lighting modes available on the Victoper A1200T flashlight: High, Medium, Low, Strobe, and SOS. Each mode is depicted with a corresponding scenario.

Ajust del zoom:

The Victoper A1200T features an adjustable head for zooming. To adjust the beam:

• Gently push the head of the flashlight forward to narrow the beam into a focused spotlight.
• Pull the head of the flashlight backward to widen the beam into a broad floodlight.

7. Manteniment

Neteja:

• Netegeu el cos de la llanterna amb un drap suauamp tela. No utilitzeu netejadors abrasius ni dissolvents.
• Mantingueu la lent neta per a una sortida de llum òptima. Feu servir un drap de neteja de lents si cal.

Emmagatzematge:

• Guardeu la llanterna en un lloc fresc i sec, lluny de la llum solar directa i de temperatures extremes.
• For long-term storage, ensure the battery is partially charged (around 50%) to prolong its lifespan. Recharge every 3-6 months if not in use.

Illustration of the Victoper A1200T flashlight's IP65 waterproof rating, demonstrating its resilience in rainy and snowy conditions. The image also emphasizes its durable construction.

8. Solució De Problemes

9. Especificacions

Image displaying the compact dimensions of the Victoper A1200T flashlight (5.12 inches length, 1.38 inches width) and showcasing its versatility in different scenarios such as cycling, outdoor exploration, and reading.

10. Garantia i Suport

Victoper products are designed for reliability and performance. For any questions, technical support, or warranty claims, please contact our customer service team. Please have your purchase information and model number ready when contacting support.

For further assistance, please visit the official Victoper store or contact your retailer.
