Introducció
Thank you for choosing the VIKIO HOME 30-Inch Island Range Hood. This manual provides essential information for the safe installation, operation, and maintenance of your new kitchen appliance. Please read these instructions thoroughly before installation and use, and keep them for future reference.
This island range hood features a powerful 390 CFM dual-intake motor, 3-speed fan, touch and gesture controls, LED lighting, and convertible ducted/ductless ventilation options. Crafted from durable 430 brushed stainless steel, it is designed for longevity and efficient removal of smoke and odors, ensuring a cleaner and quieter kitchen environment.
Informació de seguretat
ADVERTÈNCIA: Per reduir el risc d'incendi, descàrrega elèctrica o lesions, observeu el següent:
- Els treballs d'instal·lació i el cablejat elèctric han de ser realitzats per persones qualificades d'acord amb tots els codis i estàndards aplicables, inclosa la construcció antiincendis.
- Sufficient air is needed for proper combustion and exhausting of gases through the chimney of fuel-burning equipment to prevent back-drafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Fire Protection Association (NFPA), and the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
- Quan talleu o perforeu la paret o el sostre, no danyeu el cablejat elèctric i altres serveis ocults.
- Els ventiladors per conductes s'han de ventilar sempre a l'exterior.
- No utilitzeu aquesta unitat amb cap dispositiu de control de velocitat d'estat sòlid.
- Per reduir el risc d'incendi, utilitzeu només conductes metàl·liques.
- No deixeu mai les unitats de superfície desateses a configuracions altes. Les ebullicions provoquen fum i vessaments de greix que poden encendre.
- Netegeu els ventiladors amb freqüència. No s'ha de deixar que s'acumuli greix al ventilador o al filtre.
- Utilitzeu la mida adequada de la paella. Utilitzeu sempre estris de cuina adequats a la mida de l'element de superfície.
Contingut del paquet
Verifiqueu que tots els components siguin presents i no estiguin danyats abans de continuar amb la instal·lació.
- Island Range Hood Unit
- Adjustable Chimney Cover (23.63"-38.5" adjustable height)
- 3 Stainless Steel Baffle Filters
- Installation Accessories (Mounting brackets, screws, expansion hangers, aluminum pipe for ducted setup)
- Manual d'usuari
Especificacions
| Característica | Especificació |
|---|---|
| Marca | CASA VIKIO |
| Informació del model | VK-RI31-30in |
| Dimensions del producte | 21.25 "P x 30" W x 6.31" H |
| Pes de l'article | 50.7 lliures |
| Material | 430 Acer inoxidable raspallat |
| Tipus de muntatge | Muntanya de l'illa |
| Capacitat de cabal d'aire | 390 peus cúbics per minut (CFM) |
| Nombre de velocitats | 3 |
| Nivell de soroll | Less than 40 Decibels (at high speed) |
| Tipus de controls | Touch, Gesture, Remote Control |
| Tipus de font de llum | LED (4x 2W 4000K soft white) |
| Tipus de filtre | Baffle (Dishwasher Safe) |
| Tipus de ventilació | Convertible (Ducted/Ductless) |
| Voltage | 120 Volts |
| Wattage | 130 watts-hora |
Configuració i instal·lació
Proper installation is crucial for the performance and safety of your island range hood. This model supports both ducted and ductless configurations. For ductless operation, charcoal filters (not included) are required.
Consideracions prèvies a la instal·lació:
- Ensure the ceiling can support the weight of the range hood.
- For ducted installation, ensure a 6-inch diameter duct opening is available in the ceiling.
- Verify the ceiling height is compatible with the adjustable chimney cover (23.63"-38.5").
- Ensure a power outlet is available at the installation location.
Passos d'instal·lació:
- Marcatge i perforació: Use the provided mounting template to mark the drilling points on the ceiling for the hanging rack base. Drill holes and insert expansion rubber/screws as per instructions.
- Assemble Hanging Rack: Attach the P1 expansion hangers to the ceiling cover using M4 screws.
- Fasten Ceiling Cover: Secure the assembled ceiling cover to the ceiling using expanding screws.
- Assemble P2 Expansion Hangers: Attach the P2 expansion hangers to the blower unit using M4 screws.
- Duct Connection (Ducted Option): Connect the aluminum pipe to the blower unit and route it through the ceiling opening. Ensure a secure connection to the exhaust pipe.
- Connexió d'alimentació: Plug the range hood into the prepared power socket. Ensure the power is off before connecting.
- Install Duct Covers: Embed the inner duct cover and fix it with M4 screws. Then, install the outer duct cover, ensuring it slides smoothly and covers the internal components.
- Install Baffle Filters: Insert the stainless steel baffle filters into their designated slots.
Image: Installation of the VIKIO HOME Island Range Hood, showing the main unit being mounted.
Image: Detailed dimensions of the VIKIO HOME Island Range Hood, crucial for planning installation space.
Guia de vídeo d'instal·lació:
Video: This video demonstrates the ceiling mount installation process for an island range hood. While it shows a 36-inch model, the general steps and principles apply to the 30-inch VIKIO HOME unit.
Instruccions de funcionament
Your VIKIO HOME Island Range Hood is equipped with an intuitive interactive panel, offering both touch and gesture controls for convenience.
Funcions del tauler de control:
- Encès/apagat: Premeu el botó d'encesa per encendre o apagar la unitat.
- Ajust de velocitat del ventilador: Use the '+' and '-' buttons on the touch panel to cycle through the 3 fan speeds (Low, Medium, High).
- Llums LED: Press the light button to turn the LED lights on or off. The four soft white LED lights illuminate your cooking area.
- Delay Shutdown: Activate the delay shutdown feature to allow the fan to continue operating for a set period after cooking, ensuring all residual odors are cleared.
Control de gestos:
The range hood features 4 sensing points for touchless gesture control. Wave your hand in front of the panel to activate or adjust certain functions, such as turning the fan on/off or changing speeds, without touching the surface.
Image: The smart control panel of the VIKIO HOME Island Range Hood, illustrating both gesture and touch control options for fan speed, lights, and delay shutdown.
Producte acabatview Vídeo:
Vídeo: Un breu resumview of the VIKIO HOME 30-Inch Island Range Hood, highlighting its features and design.
Manteniment i Neteja
Regular maintenance and cleaning will ensure optimal performance and longevity of your range hood.
Filtres deflectors:
The stainless steel baffle filters are designed to trap grease effectively. They are dishwasher-safe for easy cleaning. To remove, simply push the release tab and pull the filter down. Clean regularly (monthly or as needed depending on cooking frequency) to maintain airflow and prevent grease buildup.
Imatge: Primer pla view of the baffle filters in the VIKIO HOME Island Range Hood, demonstrating their design for grease separation and easy removal.
Neteja exterior:
Clean the exterior surfaces of the range hood with a soft cloth and a non-abrasive stainless steel cleaner. Avoid using harsh chemicals or abrasive pads that could scratch the finish.
Charcoal Filters (Ductless Option):
If using the range hood in a ductless configuration with charcoal filters, replace these filters every 3-6 months, or more frequently depending on usage, to ensure effective odor absorption.
Resolució de problemes
Abans de contactar amb l'atenció al client, consulteu els següents problemes i solucions habituals:
| Problema | Causa possible | Solució |
|---|---|---|
| El ventilador no funciona | Sense font d'alimentació | Check if the power cord is plugged in and the circuit breaker is on. |
| Mala succió | Clogged filters or improper ducting | Clean or replace filters. Ensure ductwork is clear and properly sealed. |
| Soroll excessiu | Loose parts or improper installation | Check for loose screws or components. Ensure the unit is securely mounted. |
| Els llums no funcionen | Bombeta LED o cablejat defectuós | Check light connections. If bulbs are replaceable, replace them. Contact support if issue persists. |
Garantia i suport
Your VIKIO HOME Island Range Hood is covered by a manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical assistance, replacement parts, or any other inquiries, please contact VIKIO HOME customer support.
Informació de contacte: Refer to your product packaging or the official VIKIO HOME weblloc web per obtenir les dades de contacte del servei d'atenció al client més actualitzades.
