Magcubic Smart Projector HY300GT Instruction Manual

Introducció

Thank you for choosing the Magcubic Smart Projector HY300GT. This portable projector offers a seamless smart entertainment experience with built-in Android 11, 2K support, and advanced features like automatic keystone correction and voice control. This manual provides essential information for setting up, operating, and maintaining your projector to ensure optimal performance.

Configuració

1. Unboxing i Inspecció Inicial

Traieu amb cura tots els components de l'embalatge. Assegureu-vos que tots els elements que s'enumeren a continuació siguin presents i no estiguin danyats.

• Magcubic Smart Projector HY300GT Unit
• Control remot
• Adaptador d'alimentació
• Manual d'instruccions

2. Potència de connexió

Connect the power adapter to the projector's power input port and then plug it into a power outlet. The projector does not have an internal battery and requires continuous power for operation.

Imatge: Part posterior view of the Magcubic HY300GT projector, highlighting the power input, HDMI, USB, and audio ports for connectivity.

3. Positioning the Projector

Place the projector on a stable, flat surface. The unique portable and foldable split design allows for flexible positioning. You can adjust the angle of projection by tilting the main unit on its base. For optimal viewing, a distance of 5.2 feet from an 80-inch screen is recommended.

Image: The Magcubic HY300GT projector demonstrating its flexible projection capabilities, including projecting onto a ceiling from a bedside table.

4. Engegada inicial

Premeu el botó d'engegada del projector o del comandament a distància per engegar el dispositiu. El projector s'iniciarà i mostrarà la interfície principal.

Instruccions de funcionament

1. Navegació i control remot

Use the provided remote control to navigate the projector's interface. The remote features dedicated buttons for popular apps like YouTube, Netflix, Prime Video, and Google Play for quick access. It also includes navigation arrows, an OK button, volume controls, and a mute button.

2. Adjusting Focus and Keystone Correction

The HY300GT features automatic hardware keystone correction, which adjusts the image in real-time to ensure a uniform and high-quality display, even with side projection. It also supports 80%-100% zoom function for screen size adjustment. For manual focus, use the dedicated focus buttons on the remote control.

Image: The projector automatically correcting a tilted image of a motocross rider, illustrating the hardware keystone correction feature.

3. Connectivitat (Wi-Fi i Bluetooth)

The projector supports 2T2R 802.11a/b/g/n/ac 2.4G&5G WIFI5 for fast and stable internet connectivity. Bluetooth 5.0 allows connection to wireless headphones or external speakers for enhanced audio. You can also effortlessly cast content from your smartphone, tablet, or PC screen.

Image: The projector's dual-band Wi-Fi and Bluetooth 5.0 capabilities are shown, with diagrams illustrating connections to external speakers and screen mirroring from a phone.

4. Using Built-in Android 11 and Voice Assistant

The projector comes with built-in Android 11, providing access to over 10,000 apps directly from the homepage, including YouTube, Prime Video, and Hulu. Use the smart voice assistant by pressing the voice button on the remote and issuing commands like "open YouTube" or "adjust volume."

Image: The projector's screen shows the Android 11 home interface with app icons, while a remote control illustrates how to use voice commands for operation.

Característiques clau

• Seamless Smart Entertainment: Built-in Android 11 with access to over 10,000 apps (YouTube, Prime Video, Hulu).
• Assistent de veu intel·ligent: Control the projector with simple voice commands for easy operation.
• Qualitat d'imatge impressionant: 260 ANSI lumens brightness, native 720P resolution with 2K support, and 10000:1 high contrast for vivid and sharp images.
• Advanced Keystone Correction: Automatic hardware keystone correction maintains 100% original resolution and supports 80%-100% zoom.
• Òptima Viewing: 0.8:1 throw ratio, recommended 5.2 feet distance for an 80-inch screen.
• Rich Audio & Stable Connectivity: Built-in 5W speaker, Bluetooth 5.0, and 2.4G&5G WIFI5 for a seamless audio-visual experience.
• Portable & Foldable Split Design: Detachable main body and base for mobile entertainment or free-form projection.

Especificacions

Manteniment

1. Neteja del projector

Regularly clean the projector vents to prevent dust buildup, which can cause overheating and affect performance. Use a soft, dry cloth to clean the exterior surfaces. Do not use liquid cleaners or harsh chemicals.

2. Cura de les lents

Gently clean the projector lens with a lens cleaning cloth. Avoid touching the lens directly with your fingers to prevent smudges.

Resolució de problemes

1. Sense alimentació / No s'encén

• Assegureu-vos que l'adaptador de corrent estigui connectat correctament tant al projector com a una presa de corrent que funcioni.
• Verifiqueu que la presa de corrent funciona connectant-hi un altre dispositiu.
• Try pressing the power button on the projector unit itself, not just the remote.

2. Blurry Image / Focus Issues

• Allow the automatic keystone correction to complete its cycle.
• Use the dedicated focus buttons on the remote control to manually adjust the focus.
• Assegureu-vos que la superfície de projecció sigui plana i lliure d'obstacles.

3. Sense so

• Comproveu el nivell de volum del projector i del dispositiu font connectat.
• Ensure the projector is not muted (check the mute button on the remote).
• Si feu servir altaveus Bluetooth externs, assegureu-vos que estiguin correctament emparellats i connectats.

Garantia i Suport

• Devolució o canvi en 30 dies: Els productes es poden retornar o canviar en un termini de 30 dies des de la compra.
• Suport tècnic de tota la vida: Magcubic offers lifetime technical support for your projector.
• 24/7 Service Professional: Access to professional service support around the clock.

For any inquiries or assistance, please contact Magcubic customer support.
