Introducció
This manual provides detailed instructions for the installation, operation, and maintenance of your Fortdows 4Core+32G Car Radio. This unit is designed to upgrade the in-dash entertainment system in compatible Dodge Ram 1500 and 2500 models from 2013 to 2018. Please read this manual thoroughly before installation and use to ensure proper function and safety.
Contingut del paquet
Verifiqueu que tots els elements que s'enumeren a continuació s'inclouen al vostre paquet:
- 1 x Unitat principal
- 1 x càmera
- 1 x cable d'alimentació
- 1 x palanca
- 1 x cable USB
- 1 x Antena GPS
- 1 x MIC
- 1 x Cable d'entrada de càmera
- 1 descodificador Canbus
- 1 cable d'entrada/sortida RCA
- 1 x Original USB Cable
Figure 1: Included components in the Fortdows 4Core+32G Car Radio package.
Compatibility & Setup
Compatibilitat de vehicles
This car radio is specifically engineered for Dodge Ram 1500 and 2500 models manufactured between 2013 and 2018. It is compatible only with vehicles equipped with manual AC controls. Please verify your vehicle's AC control type before installation.
Instal·lació
The unit features a plug-and-play design for integration with the original dashboard, requiring no modifications. Professional installation is recommended to ensure correct wiring and functionality. Refer to your vehicle's service manual for specific dashboard removal and reinstallation procedures.
Figure 2: Compatibility guide for Dodge Ram 1500/2500 (2013-2018) with manual AC controls.
Instruccions de funcionament
CarPlay i Android Auto
The unit supports wireless CarPlay and Android Auto for seamless smartphone integration. Connect your compatible smartphone to access navigation, make calls, send messages, and play music through the car radio interface. This feature is designed to enhance driving safety by minimizing distractions.
Figure 3: Wireless CarPlay and Android Auto interface.
Mans lliures Bluetooth
The car radio includes Bluetooth 5.4 for hands-free calling and voice control. Pair your mobile device to make and receive calls, or use voice commands for functions like playing music or initiating GPS navigation, promoting safer driving.
5G WiFi Connectivity & GPS Navigation
Integrated 5G WiFi allows for internet connectivity, enabling real-time GPS navigation, music streaming, and access to online content. The system supports downloading maps for offline use, ensuring navigation functionality even without a network connection.
Figure 4: 5G WiFi connectivity interface.
Càmera de marxa enrere de 1080P
A 170° wide-angle, night vision, waterproof backup camera is included. This camera provides a clear view of the area behind your vehicle when reversing, assisting in avoiding obstacles and blind spots.
9" IPS Display & Audio Experience
The unit features a 9-inch 1280x800 HD IPS touchscreen with a 178° wide viewing angle and an anti-glare coating. This display provides clear image and text representation under various lighting conditions. Audio settings include FM EQ and a 32-band equalizer with presets (Jazz, Rock, Pop) for sound customization.
Figure 5: 9-inch 1280x800 HD IPS Touchscreen clarity comparison.
Comandaments del volant
The car radio supports integration with your vehicle's existing steering wheel controls. This allows for convenient operation of the radio's functions without diverting attention from the road.
Figura 6: Integració del control del volant.
Manteniment
To ensure the longevity and optimal performance of your Fortdows Car Radio, follow these maintenance guidelines:
- Neteja de la pantalla: Feu servir un drap suau i sense borrissol per netejar suaument la pantalla tàctil. Per a taques difícils, fregueu lleugeramentampNetegeu el drap amb aigua o un netejador de pantalles. Eviteu materials abrasius o productes químics agressius.
- Actualitzacions de programari: Periodically check for available software updates to ensure the system operates with the latest features and security patches. Follow the on-screen instructions for any update procedures.
- Condicions ambientals: Eviteu exposar la unitat a temperatures extremes, a la llum solar directa durant períodes prolongats o a una humitat excessiva.
- Connexions de cable: Assegureu-vos que tots els cables estiguin connectats correctament. Les connexions soltes poden provocar un funcionament intermitent.
Resolució de problemes
Si teniu problemes amb la ràdio del cotxe, consulteu els següents problemes i solucions habituals:
- Sense energia:
- Comproveu totes les connexions d'alimentació i els fusibles.
- Assegureu-vos que el contacte del vehicle estigui engegat.
- Sense so:
- Verify volume settings are not muted or set too low.
- Comproveu les connexions dels altaveus.
- Assegureu-vos que s'ha seleccionat la font d'àudio correcta.
- El GPS no funciona/és inexacte:
- Assegureu-vos que l'antena GPS estigui instal·lada correctament i que tingui una vista clara view del cel.
- Check GPS settings within the unit.
- Problemes de connexió Bluetooth:
- Assegureu-vos que el Bluetooth estigui activat tant a la ràdio del cotxe com al dispositiu mòbil.
- Suprimeix els emparellaments anteriors i intenta tornar a emparellar els dispositius.
- Move your mobile device closer to the car radio.
- Pantalla tàctil que no respon:
- Restart the unit by turning off the vehicle's ignition and restarting.
- Assegureu-vos que la pantalla estigui neta i lliure de residus.
Si els problemes persisteixen després d'intentar aquestes solucions, poseu-vos en contacte amb l'atenció al client.
Especificacions
| Característica | Especificació |
|---|---|
| Nom del model | 4Core+32G |
| Sistema operatiu | Android 13 |
| Processador | 4 Nucli |
| RAM | 2 GB |
| ROM (emmagatzematge intern) | 32 GB |
| Mida de la pantalla | 9 polzades |
| Resolució de pantalla | IPS HD de 1280 x 800 |
| Tecnologia de connectivitat | Bluetooth 5.4, 5G WiFi |
| Característiques especials | Wireless CarPlay, Android Auto, GPS Navigation, 1080P AHD Backup Camera, Steering Wheel Control |
| Mode de sortida d'àudio | estèreo |
| Pes de l'article | 3.89 lliures |
| Dimensions del paquet | 12.68 x 11.3 x 4.88 polzades |
Garantia i suport
Informació de la garantia
This Fortdows Car Radio comes with a 1-year manufacturer's warranty from the date of purchase. The warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or improper installation.
Atenció al client
For technical assistance, warranty claims, or any questions regarding your Fortdows Car Radio, please contact our customer support team. Refer to the contact information provided with your purchase documentation or visit the official Fortdows weblloc per obtenir opcions de suport.
