Introducció
The KEF Coda W Wireless HiFi Speaker system offers high-fidelity audio in an accessible, all-in-one package. Designed to deliver detailed and immersive sound, it provides versatile connectivity options for various audio sources. The Coda W combines classic design principles with advanced acoustic technology.
Imatge: Frontal view of the KEF Coda W Wireless HiFi Speakers in Moss Green.
Contingut del paquet
Si us plau, assegureu-vos que tots els elements que s'enumeren a continuació estiguin presents al vostre paquet:
- KEF Coda W Primary Speaker
- KEF Coda W Secondary Speaker
- Cable d'alimentació
- Guia d'inici ràpid
- Control remot
- USB-C Inter-speaker Cable
Guia de configuració
- Col·locació: Position your KEF Coda W speakers in your desired listening area. For optimal stereo imaging, place them equidistant from your listening position and at ear level. Ensure adequate space around the speakers for proper ventilation and sound dispersion.
Image: KEF Coda W speakers positioned on a desk, demonstrating typical placement.
- Connect Primary and Secondary Speakers: Use the provided USB-C inter-speaker cable to connect the Primary speaker to the Secondary speaker. Locate the "TO P/S" port on the Secondary speaker and the corresponding port on the Primary speaker.
Image: Rear panel of the KEF Coda W Primary speaker, highlighting the connectivity options including the USB-C inter-speaker port.
- Connexió d'alimentació: Connect the power cable to the AC input on the Primary speaker, then plug the other end into a wall outlet.
- Encesa inicial: Press the power button on the Primary speaker or use the remote control to turn on the system. The indicator light will illuminate.
- App Setup (Recommended): Download the KEF Connect app from your device's app store. Follow the in-app instructions to connect your Coda W speakers to your Wi-Fi network and configure settings. This enables advanced features and streaming options.
Instruccions de funcionament
Opcions de connectivitat:
- Bluetooth 5.4 with aptX: For wireless streaming from compatible devices. Activate Bluetooth pairing mode on the speakers and select "KEF Coda W" from your device's Bluetooth settings.
- ARC HDMI: Connect your TV using an HDMI cable to the HDMI ARC port on the Primary speaker for high-fidelity TV audio.
- USB-C Audio: For high-resolution audio playback from computers or other USB-C enabled devices. Supports up to 24-bit/192kHz.
- RCA (LINE) Input: Connect analog sources such as CD players or turntables with a built-in phono preamp.
- Entrada fonètica: Directly connect turntables without a built-in phono preamp.
- Entrada òptica: For digital audio sources like game consoles or older TVs.
Comandament a distància:
Use the included remote control to adjust volume, switch input sources, and power the speakers on/off. Ensure batteries are correctly inserted.
Manteniment
- Keep the speakers clean by gently wiping them with a soft, dry cloth. Avoid using abrasive cleaners or solvents.
- Assegureu-vos d'una ventilació adequada al voltant dels altaveus per evitar el sobreescalfament.
- Protect the speakers from direct sunlight, excessive heat, moisture, and dust.
- Do not attempt to open the speaker enclosures, as this may void your warranty and expose you to electrical hazards.
Resolució de problemes
| Problema | Causa possible | Solució |
|---|---|---|
| Sense so | Power cable disconnected, incorrect input selected, volume too low. | Check power connection, verify input source, increase volume. |
| Problemes de vinculació de Bluetooth | Altaveus no en mode d'emparellament, dispositiu massa lluny, interferències. | Ensure speakers are in BT pairing mode, move device closer, restart speakers and device. |
| Àudio distorsionat | Source audio quality, cable issues, volume too high. | Check audio source, replace cables, reduce volume. |
| El comandament a distància no funciona | Piles gastades, obstrucció, comandament a distància fora de l'abast. | Replace batteries, remove obstructions, ensure line of sight to speakers. |
Especificacions
- Nom del model: Coda W
- Tipus d'altaveu: prestatgeria
- Tecnologia de connectivitat: Bluetooth, HDMI, Optical, RCA, USB
- Potència de sortida màxima dels altaveus: 100 watts
- Marca: KEF
- Dimensions del producte: 10.55 "P x 13.2" W x 11.2" H
- Pes de l'article: 33.5 lliures
- Color: Verd molsa
- Característiques especials: Bass Boost, Hi Res Audio, USB Port
- Components inclosos: Power Cable, Quick Start Guide, Remote
- UPC: 637203051777
- Fabricant: KEF
Garantia i Suport
For warranty information and technical support, please refer to the Quick Start Guide included in your package or visit the official KEF weblloc web. Conserveu el comprovant de compra per a reclamacions de garantia.
Online resources and FAQs may also be available on the KEF support pages.
